Parts for 496 Mag (H.o. Model) 8.1L (496 Cu In) V8 GM MerCruiser Engines - Gas Intake Manifold

Revise Search: Sterndrive > MerCruiser Engines - Gas > 8.1L (496 Cu In) V8 GM > 496 Mag (H.o. Model) > 0W060000 - 0W309999 > Intake Manifold

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Intake Manifold

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	8M0064079	MANIFOLD-REMAN INTAKE (1 required per assembly) — Replaces: 881690001
		8M0064079 - Manifold - Remanufactured [ More info ] Unavailable
#2	805223T	SENSOR MANIFOLD AIR TEMPERATURE (1 required per assembly)
		805223T - Intake Air Temperature IAT Sensor [ More info ] $160.99 $158.97 In Stock
		1300-13604 - Air Charge Temperature Sensor / Sender [ More info ] $53.99 $41.29 3 In Stock.
#3	881734	HOSE FUEL PRESSURE REGULATOR (1 required per assembly)
		32-881734 - Hose - Fuel Pressure Regulator [ More info ] $16.69 Available to Order: Shipping delay up to 10 days.
#4	881633T01	GASKET SET INTAKE MANIFOLD AND VALLEY (1 required per assembly) — Replaces: 895235
		27-881633T01 - Gasket [ More info ] $324.49 In Stock
#5	881689	SHIELD OIL SPLASH (1 required per assembly)
		881689 - Shield [ More info ] Unavailable
#6	8M0050807	RETAINER VALVE LIFTER GUIDE (1 required per assembly) — Replaces: 845755
		8M0050807 - Lifter Retainer [ More info ] $54.99 Available to Order: Shipping delay up to 10 days.
#7	881570	BOLT (7 required per assembly)
		10-881570 - Bolt [ More info ] $3.49 2 In Stock.
#8	8M0186195	SENSOR MANIFOLD AIR PRESSURE (1 required per assembly) — Replaces: 881731, 8M0054726
		8M0186195 - MAP Sensor [ More info ] $317.49 In Stock
		18-7660 - Map Sensor, 881731 [ More info ] $223.92 1 In Stock.
		1300-36036 - Map Sensor [ More info ] $149.99 $100.35 3 In Stock.
#9	881733	SEAL M.A.P. SENSOR (1 required per assembly)
		25-881733 - Seal [ More info ] $20.99 Available to Order: Shipping delay up to 10 days.
#10	881646	BOLT (1 required per assembly)
		10-881646 - Bolt [ More info ] $42.99 Available to Order: Shipping delay up to 10 days.
#11	864996	TUBE OIL FILL (1 required per assembly)
		864996 - Oil Fill Tube [ More info ] Unavailable
#12	864997	CAP OIL FILL TUBE (1 required per assembly)
		864997 - Oil Fill Cap [ More info ] $39.33 1 In Stock.
#13	NSS	NOT SOLD SEPARATE SEAL-OIL FILL CAP (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#14	881645	BOLT (M6 X 20) OIL FILL TUBE (1 required per assembly)
		10-881645 - Bolt [ More info ] $6.39 Available to Order: Shipping delay up to 10 days.
#15	895234001	SCREW (10 required per assembly) — Replaces: 895234
		10-895234001 - Screw [ More info ] $16.79 Available to Order: Shipping delay up to 10 days.
#16	881691001	FUEL RAIL FUEL INJECTION Use with Design-I Regulator (1 required per assembly)
		881691001 - Fuel Rail [ More info ] Unavailable
#16	8M0132702	FUEL RAIL REMAN FUEL INJECTION Use with Design-II Regulator (1 required per assembly) — Replaces: 881691002
		8M0132702 - Fuel Rail [ More info ] Unavailable
#17	802631	VALVE AND CAP KIT FUEL PRESSURE SERVICE (1 required per assembly)
		22-802631 - Valve And Cap [ More info ] $121.99 Available to Order: Shipping delay up to 10 days.
#18	8M0069803	REGULATOR-FUEL FUEL PRESSURE Design-I (1 required per assembly) — Replaces: 881692001, 802630T01
		8M0069803 - Fuel Regulator [ More info ] $541.99 Available to Order: Shipping delay up to 10 days.
#18	8M0046753	REGULATOR KIT FUEL PRESSURE Design-II (1 required per assembly)
		8M0046753 - Dampener Kit [ More info ] $219.49 Available to Order: Shipping delay up to 10 days.
#19	881696	SEAL KIT FUEL PRESSURE REGULATOR Use with Design-I Regulator (1 required per assembly)
		25-881696 - Seal Kit [ More info ] Unavailable
#20	881693002	INJECTOR Use with 496/8.1L HO Engines (8 required per assembly) — Replaces: 881693
		881693002 - Injector [ More info ] Unavailable
		8M0221353 - INJECTOR [ More info ] Unavailable
#20	881693001	INJECTOR Use with 496/8.1L Base Engine (8 required per assembly)
		881693001 - Injector [ More info ] $623.36 Available to Order: Shipping delay up to 10 days.
#21	881694	SEAL KIT Use with Design-I Regulator (1 required per assembly)
		25-881694 - Seal Kit [ More info ] $52.99 Available to Order: Shipping delay up to 10 days.
#21	881694001	SEAL KIT Use with Design-II Regulator (1 required per assembly)
		25-881694001 - Seal Kit [ More info ] $86.99 $83.12 4 In Stock.
#22	881695001	RETAINER KIT FUEL INJECTOR (1 required per assembly) — Replaces: 881695
		881695001 - Retainer Kit [ More info ] $89.49 Available to Order: Shipping delay up to 10 days.
#23	881968001	STUD FUEL INJECTION RAIL (2 required per assembly) — Replaces: 881968
		16-881968001 - Stud [ More info ] $8.99 Available to Order: Shipping delay up to 10 days.
#24	8M0127600	HARNESS ASSEMBLY FUEL INJECTION WIRING (1 required per assembly) — Replaces: 889503
		84-8M0127600 - Harness [ More info ] Unavailable
#25	8M0077391	STUD THROTTLE BODY (3 required per assembly) — Replaces: 802561
		168M0077391 - Stud [ More info ] $46.99 Available to Order: Shipping delay up to 10 days.
#26	8623601	PLUG FUEL RAIL OUTLET Use with Design-I Regulator (1 required per assembly)
		22-862360 1 - Plug [ More info ] $27.91 1 In Stock.
#27	881725	PLATE BLOCK OFF (Digital Throttle Shift) (1 required per assembly)
		881725 - PLATE NLA [ More info ] Unavailable
#28	863285	GASKET (Digital Throttle Shift) (1 required per assembly)
		27-863285 - Air Valve Gasket [ More info ] $17.99 Available to Order: Shipping delay up to 10 days.
#29	898101392	BOLT @2 (Digital Throttle Shift) (2 required per assembly) — Replaces: 881586
		10-898101392 - Bolt [ More info ] $4.59 Available to Order: Shipping delay up to 10 days.
