Parts for 454 Mag MPI Bravo (Gen VI) GM 454 V-8 7.4L (454 Cu In) V8 GM MerCruiser Engines - Gas Cylinder Head & Rocker Cover

Revise Search: Sterndrive > MerCruiser Engines - Gas > 7.4L (454 Cu In) V8 GM > 454 Mag MPI Bravo (Gen VI) GM 454 V-8 > 1996-1997 0F802350 - 0K999999 > Cylinder Head & Rocker Cover

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Cylinder Head & Rocker Cover

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	811572A94	GASKET SET (454) (1 required per assembly)
		27-811572A94 - Engine Overhaul Gasket Set [ More info ] Unavailable
#-	805396A92	GASKET SET (502) (1 required per assembly)
		27-805396A92 - Engine Overhaul Gasket Set [ More info ] Unavailable
#1	850462	COVER ROCKER (2 required per assembly)
		850462 - Rocker Cover [ More info ] Unavailable
#2	811569	CAP-OIL FILL (2 required per assembly)
		36-811569 - Oil Fill Cap [ More info ] $34.58 Available to Order: Shipping delay up to 10 days.
#3	8M0092920	GASKET (2 required per assembly) — Replaces: 811588
		27-8M0092920 - ROCKER Cover Gasket [ More info ] $126.99 Available to Order: Shipping delay up to 10 days.
#4	811589	BOLT (1/4-20 X 0.875) (1/4-20 X 5/8 IN.) (14 required per assembly)
		10-811589 - Screw [ More info ] $18.19 Available to Order: Shipping delay up to 10 days.
#5	852003	ROD-PUSH (INTAKE) (8 required per assembly)
		852003 - Push Rod [ More info ] $47.99 Available to Order: Shipping delay up to 10 days.
#5	852004	ROD-PUSH (EXHAUST) (8 required per assembly)
		852004 - Push Rod [ More info ] $40.49 Available to Order: Shipping delay up to 10 days.
#6	816962	VALVE-STD-EXHAUST (STANDARD) (8 required per assembly)
		816962 - Exhaust Valve - Std [ More info ] Unavailable
#6	816963T	VALVE-EXH-015 OS (.015 O.S.) (AR required per assembly) — Replaces: 816963
		816963T - Exhaust Valve - 015 OS [ More info ] Unavailable
#7	801877	VALVE-STD-INLET (STANDARD) (8 required per assembly)
		801877 - Intake Valve [ More info ] Unavailable
#7	801878	VALVE-.015-INLET (.015 O.S.) (8 required per assembly)
		801878 - Valve - .015- Inlet, NLA [ More info ] $20.00 4 In Stock.
#8	881686	GUIDE PUSH ROD (8 required per assembly) — Replaces: 811586, 845707
		881686 - Guide [ More info ] $18.39 Available to Order: Shipping delay up to 10 days.
#9	827644A1	CAP/SEAL ASSY (16 required per assembly)
		827644A 1 - Cap/Seal Assembly [ More info ] $92.49 Available to Order: Shipping delay up to 10 days.
#10	827645	SEAL VALVE (16 required per assembly)
		26-827645 - Seal [ More info ] Unavailable
#11	801879T	SPRING (16 required per assembly) — Replaces: 801879
		24-801879T - Spring, Valve [ More info ] $55.99 Available to Order: Shipping delay up to 10 days.
#12	54530	KEY ROCKER (32 required per assembly)
		28-54530 - Key - Priced Individually [ More info ] $6.89 $5.52 5 In Stock.
#13	8M0112788	ROCKER ARM (16 required per assembly) — Replaces: 811591, 811591T
		8M0112788 - ROCKER ARM [ More info ] $158.42 Available to Order: Shipping delay up to 10 days.
#14	8M0112788	ROCKER ARM (16 required per assembly) — Replaces: 850472, 811591T
#15	811593	BOLT (16 required per assembly)
		10-811593 - Bolt [ More info ] $18.09 Available to Order: Shipping delay up to 10 days.
#16	845669	SHIM-.015 @2 (AR required per assembly) — Replaces: 54531
		15-845669 - Shim -.015 - Priced Individually [ More info ] $8.79 Available to Order: Shipping delay up to 10 days.
#17	8M0115141	CYL HEAD-COMPLETE CYLINDER (2 required per assembly) — Replaces: 827495, 827495T
		9388M0115141 - Cylinder Head - Complete [ More info ] Unavailable
#18	879150141	GASKET-CYL HEAD (454 MAGNUM) (2 required per assembly) — Replaces: 850470
		27-879150141 - Cylinder Head Gasket [ More info ] $92.99 In Stock
		18-3887 - Head Gasket 454 [ More info ] $97.00 1 In Stock.
#18	879150139	GASKET-CYL HEAD (502 MAGNUM) (2 required per assembly) — Replaces: 811546
		27-879150139 - Cylinder Head Gasket [ More info ] $120.99 In Stock
#19	845706M2	ORD 8M0102366 (8 required per assembly) — Replaces: 49106, 845706
		10-845706M 2 - SCREW [ More info ] Unavailable
#20	8M0102366	HEAD BOLT KIT (24 required per assembly) — Replaces: 49105, 845705
		8M0102366 - Head Bolt Kit [ More info ] $204.71 1 In Stock.
#21	807081T	BRACKET LIFTING EYE (FRONT) (1 required per assembly)
		807081T - Lifting Eye [ More info ] Unavailable
#22	807131T	TUBE OIL FILL (1 required per assembly)
		36-807131T - Oil Fill Tube, NLA [ More info ] Unavailable
#23	805706	STUD (1 required per assembly)
		16-805706 - Stud [ More info ] $9.99 $8.45 10+ In Stock.
#24	826709109	NUT @5 (1 required per assembly) — Replaces: 35045
		11-826709109 - Nut, (.250-28) Stainless Steel [ More info ] $3.59 5 In Stock.
#25	805622	SEAL (1 required per assembly)
		26-805622 - Seal [ More info ] $38.99 Available to Order: Shipping delay up to 10 days.
#26	811553	GROMMET (2 required per assembly)
		25-811553 - Grommet [ More info ] $85.25 2 In Stock.
#27	806603	VALVE-PCV (1 required per assembly)
		21-806603 - PCV Valve Positive Crankcase Ventilation [ More info ] $17.69 Available to Order: Shipping delay up to 10 days.
#28	8M0062321	HOSE-33 INCH (1 required per assembly) — Replaces: 80617463, 86197763
		32-8M0062321 - Hose -33 Inch [ More info ] $53.49 Available to Order: Shipping delay up to 10 days.
#29	816311T	TIE STRAP @100 (2 required per assembly) — Replaces: 816311
		54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ] $0.60 10+ In Stock.
#30	8M2012906	HOSE (45 INCHES BULK) VENT (USE WITH METAL FLAME ARRESTOR) (1 required per assembly) — Replaces: 807498240, 8M2001709
		32-8M2012906 - Hose [ More info ] Unavailable
		328M0062669 - Hose [ More info ] $28.49 Available to Order: Shipping delay up to 10 days.
#30	8M0086022	HOSE BREATHER VENT (USE WITH PLASTIC FLAME ARRESTOR) (1 required per assembly) — Replaces: 1589418, 1589424
		32-8M0086022 - Tube-20 Inch [ More info ] $36.49 In Stock
#31	807925A2	BAFFLE BREATHER (1 required per assembly)
		807925A 2 - Baffle Assembly, NLA [ More info ] $51.73 9 In Stock.
