Parts for 370 Trs GM 454 V-8 7.4L (454 Cu In) V8 GM MerCruiser Engines - Gas Crankshaft, Pistons & Connecting Rods (460)

Revise Search: Sterndrive > MerCruiser Engines - Gas > 7.4L (454 Cu In) V8 GM > 370 Trs GM 454 V-8 > 1978-1985 4179554 - 6721527 > Crankshaft, Pistons & Connecting Rods (460)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Crankshaft, Pistons & Connecting Rods (460)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	99386A2	GASKET SET (1 required per assembly)
		27-99386A 2 - Gasket Set, NLA [ More info ] Unavailable
#1	41127A1	PISTON ASSEMBLY (STANDARD) (8 required per assembly)
		41127A 1 - Piston,NLA [ More info ] Unavailable
#2	98697	RING SET PISTON (STANDARD) (1 required per assembly)
		39-98697 - Ring Set-.005,NLA [ More info ] Unavailable
#3	842400	BEARING SET MAIN - STANDARD CRANKSHAFT (STANDARD) (1 required per assembly) — Replaces: 61171, 848112
		23-842400 - Bearing Set - Main - Standard [ More info ] Unavailable
		23-8M0051198 - Bearing Kit-STD [ More info ] $406.06 Available to Order: Shipping delay up to 10 days.
#4	843378	PIN DOWEL REAR CRANKSHAFT BEARING CAP (1/4&QUOT; DIA.) (1 required per assembly) — Replaces: 35312
		17-843378 - Pin, Dowel (.250) [ More info ] $15.99 1 In Stock.
#5	98184	SHIM REAL OIL SEAL (AR required per assembly)
		15-98184 - Shim, NLA [ More info ] Unavailable
#6	8M0062773	SEAL REAR - CRANKSHAFT BEARING CAP (2 required per assembly) — Replaces: 75585, 14756
		268M0062773 - Seal [ More info ] $139.49 $133.84 4 In Stock.
#7	81002	FLYWHEEL (1 required per assembly) — Replaces: 8100
		230-8100 2 - Flywheel [ More info ] $1,185.99 $1,004.53 1 In Stock.
#8	845757	SCREW (.437-20 X 1.00) FLYWHEEL TO CRANKSHAFT (6 required per assembly) — Replaces: 49845
		10-845757 - Screw [ More info ] $5.60 4 In Stock.
		10-8M0214958 - Flywheel MOUNTING SCREW ZZ [ More info ] $5.89 Available to Order: Shipping delay up to 10 days.
#9	39131	LOCKWASHER (.437) FLYWHEEL SCREW (6 required per assembly)
		13-39131 - LockWasher [ More info ] $1.00 Available to Order: Shipping delay up to 10 days.
#10	8M0051206	DRIVEPLATE (1 required per assembly) — Replaces: 74816, 816618
		8M0051206 - DrivePlate [ More info ] $1,170.47 Available to Order: Shipping delay up to 10 days.
#11	35091	SCREW (.375-16 X 1.00) DRIVE PLATE (6 required per assembly)
		10-35091 - Screw - Priced Individually [ More info ] $16.59 $7.31 10+ In Stock.
#12	35048	LOCKWASHER (.375) DRIVE PLATE SCREW (6 required per assembly)
		13-35048 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#13	6507	CONNECTING ROD (8 required per assembly)
		622-6507 - CONNECTING,NLA [ More info ] Unavailable
#14	841447A1	BEARING SET CONNECTING ROD - STANDARD CONNECTING ROD (STANDARD) (8 required per assembly) — Replaces: 61170, 848110
		23-841447A 1 - BRG KIT-STD,NLA [ More info ] Unavailable
#15	43504	PIN DOWEL CRANKSHAFT (1 required per assembly)
		17-43504 - Pin, Dowel (.25 Inch) [ More info ] $10.69 Available to Order: Shipping delay up to 10 days.
#16	65621	CRANKSHAFT (1 required per assembly)
		65621 - Crankshaft,NLA [ More info ] Unavailable
#17	34466	KEY CRANKSHAFT (3 required per assembly)
		28-34466 - Key [ More info ] $3.69 6 In Stock.
