Parts for 6.2L MPI 350 Ec 6.2L (377 Cu In) V8 Mercury MerCruiser Engines - Gas Flywheel & Coupler
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 8M0104915 | FLY HSG. ASSEMBLY (1 required per assembly) |
  |
|
8M0104915 - Flywheel Housing [ More info ]
|
| #2 | 8M0097266 | RUBBER MOUNT (2 required per assembly) |
  |
|
8M0097266 - Rubber Mount [ More info ]
|
| #3 | 8M0087147 | SPACER (2 required per assembly) |
  |
|
8M0087147 - Spacer-MOUNT [ More info ]
|
| #4 | 40125100 | NUT (3 required per assembly) |
  |
|
11-40125100 - Nut (M10) [ More info ]
|
| #5 | 400248 | LOCKWASHER @2 (2 required per assembly) |
  |
|
13-40024 8 - LockWasher [ More info ]
|
| #6 | 861577 | STUD (2 required per assembly) |
  |
|
16-861577 - Stud [ More info ]
|
| #7 | 40001197 | SCREW (4 required per assembly) |
  |
|
10-40001197 - Screw [ More info ]
|
| #8 | 8M0092110 | DOWEL (2 required per assembly) |
  |
|
178M0092110 - DOWEL [ More info ]
|
| #9 | 76596 | SCREW (2 required per assembly) |
  |
|
10-76596 - Screw [ More info ]
|
| #10 | 8M0098795 | COUPLER ASSY (1 required per assembly) |
  |
|
8M0098795 - Coupler Assembly [ More info ]
|
| #11 | 8M0204643 | SCREW (6 required per assembly) — Replaces: 14883 |
  |
|
10-8M0204643 - SCREW [ More info ] Unavailable |
| #12 | 8M0130051 | SCREW (6 required per assembly) — Replaces: 8M0076509 |
  |
|
108M0130051 - Screw [ More info ]
|
| #13 | 8M0123130 | FLYWHEEL ASSEMBLY (1 required per assembly) |
  |
|
2008M0123130 - Flywheel [ More info ]
|
| #14 | 807260A2 | COVER ASSY (1 required per assembly) |
  |
|
807260A 2 - Cover Assembly [ More info ]
|
| #15 | NSS | NOT SOLD SEPARATE PIN (1 required per assembly) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #NS | 8M0169590 | FITTING (2 required per assembly) — Replaces: 49099 |
  |
|
22-8M0169590 - FITTING [ More info ] Unavailable |
