Parts for 300 HP 4.6L V8 Verado 4-Stroke Mercury Outboard Motor Driveshaft Housing
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 8M0163108 | DSH SILVER (1 required per assembly) — Replaces: 8M0142776, 8M0153949 |
  |
15008M0163108 - DSH SILVER [ More info ] Unavailable |
|
  |
|
1500-8M0208361 - ORD1500 8M0200077 NLA [ More info ] Unavailable |
| #2 | 8M0142782 | BRACKET (1 required per assembly) |
  |
|
8M0142782 - Bracket [ More info ]
|
| #3 | 88552514 | SCREW (1 required per assembly) |
  |
|
10-885525 14 - Screw [ More info ]
|
| #4 | 85944975 | TUBING-72 INCHES (1 required per assembly) |
  |
|
32-859449 75 - Tubing - 72 Inches [ More info ]
|
| #5 | 816311T | TIE STRAP @100 (2 required per assembly) |
  |
|
54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ]
|
| #6 | 8M0142714 | FITTING (1 required per assembly) |
  |
|
228M0142714 - Fitting [ More info ]
|
| #7 | 8M0142778 | WASHER (4 required per assembly) |
  |
|
128M0142778 - Washer [ More info ]
|
| #8 | 8M0112869 | OIL PLUG ASSEMBLY (1 required per assembly) |
  |
|
198M0112869 - OIL Plug Assembly [ More info ]
|
| #9 | 85045 | O-RING (.551 X .070) (1 required per assembly) |
  |
|
25-85045 - O-ring, (.551 X .070) [ More info ]
|
| #10 | 863006 | O-RING (10.82 X 1.78) (1 required per assembly) |
  |
|
25-863006 - O-ring, Throttle Body [ More info ]
|
| #11 | 8M0036228 | O-RING (8.1 X 1.6) (1 required per assembly) |
  |
|
258M0036228 - O-Ring [ More info ]
|
| #12 | 8M0154653 | BRACKET MOUNT (2 required per assembly) — Replaces: 8M0142777, 8M0153941 |
  |
|
8M0154653 - BRACKET MOUNT [ More info ] Unavailable |
| #13 | 8M0084475 | SCREW (6 required per assembly) — Replaces: 8M0142580 |
  |
|
108M0084475 - Screw [ More info ]
|
| #14 | 821327 | PIN-DOWEL (2 required per assembly) |
  |
|
17-821327 - Pin -Dowel [ More info ]
|
| #15 | 8M0142784 | BRACKET SHIFT (1 required per assembly) |
  |
|
8M0142784 - Bracket SHIFT [ More info ]
|
| #16 | 8M0142785 | BRACKET SHIFT (1 required per assembly) |
  |
|
8M0142785 - Bracket SHIFT [ More info ]
|
| #17 | 8M0142829 | SCREW (4 required per assembly) |
  |
|
108M0142829 - Screw [ More info ]
|
| #18 | 8M0177404 | SHIFT ACTUATOR (1 required per assembly) — Replaces: 8M0142253 |
  |
8M0177404 - Shift Actuator [ More info ] Unavailable |
|
  |
|
8M0188834 - 8M0188834 - SHIFT ACTUATOR [ More info ] Unavailable Replaced by -8M0204944 |
  |
|
8M0204944 - SHIFT ACTUATOR [ More info ]
|
| #19 | 8M0147857 | SHAFT COUPLING (1 required per assembly) |
  |
|
8M0147857 - Shaft COUPLING [ More info ]
|
| #20 | 8M0142978 | SEAL ACTUATOR (1 required per assembly) |
  |
|
258M0142978 - SEAL Actuator [ More info ]
|
| #21 | 69355 | TIE STRAP @100 (1 required per assembly) |
  |
|
69355 - Tie Strap - Priced Individually [ More info ]
|
  |
|
8M0214940 - TIE STRAP [ More info ]
|
| #22 | 8M0147674 | BOOT SHIFT (1 required per assembly) |
  |
|
858M0147674 - BOOT SHIFT [ More info ]
|
| #23 | 8M0147675 | CLIP (1 required per assembly) |
  |
|
548M0147675 - Clip [ More info ]
|
| #24 | 8M0008031 | STUD Long (5 required per assembly) |
  |
|
16-8M0008031 - Stud [ More info ]
|
| #24 | 8M0142781 | STUD XLong (5 required per assembly) |
  |
|
168M0142781 - Stud [ More info ]
|
| #24 | 8M0142788 | STUD XXLong (5 required per assembly) |
  |
|
168M0142788 - Stud [ More info ]
|
| #25 | 856982 | WASHER @4 (5 required per assembly) |
  |
|
12-856982 - Washer, (.500 X .810 X .090) Stainless Steel [ More info ]
|
| #26 | 896895 | NUT @4 (5 required per assembly) |
  |
|
11-896895 - Nut, (M12) [ More info ]
|
