Parts for 377 Mag MPI Bravo Ec 6.2L (377 Cu In) V8 GM MerCruiser Engines - Gas Electrical Components Digital Throttle & Shift

Revise Search: Sterndrive > MerCruiser Engines - Gas > 6.2L (377 Cu In) V8 GM > 377 Mag MPI Bravo Ec > 1A623185 & Up > Electrical Components Digital Throttle & Shift

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Electrical Components Digital Throttle & Shift

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	865480T	BRACKET HARNESS MOUNTING/LIFTING EYE (1 required per assembly)
		865480T - Bracket [ More info ] $62.49 Available to Order: Shipping delay up to 10 days.
#2	889664	NUT (1 required per assembly)
		11-889664 - Nut, (1.500-18) Black Nylon [ More info ] $6.69 Available to Order: Shipping delay up to 10 days.
#3	98261	SCREW (2 required per assembly)
		10-98261 - Screw [ More info ] $1.20 5 In Stock.
#4	8M0072019	ECM 5.0L Bravo, Standard Cooling [1A648622] & Below (1 required per assembly) — Replaces: 8M0047345, 8M0050059
		8M0072019 - ECM [ More info ] Unavailable
#4	8M0059365	ECM 5.0L Bravo, Standard Cooling [1A648623] THRU [2A446466] (1 required per assembly)
		788M0059365 - ECM [ More info ] Unavailable
#4	8M0099859	PCM 5.0L Bravo, Standard Cooling [2A446467] & Up (1 required per assembly)
		788M0099859 - PCM [ More info ] Unavailable
#4	8M0071884	ECM 5.0L Bravo, Closed Cooling [1A648622] & Below (1 required per assembly) — Replaces: 8M0047346
		8M0071884 - ECM [ More info ] Unavailable
#4	8M0059366	ECM 5.0L Bravo, Closed Cooling [1A648623] THRU [2A446466] (1 required per assembly)
		788M0059366 - ECM [ More info ] Unavailable
#4	8M0072020	ECM 350 Bravo, Standard Cooling [1A648622] & Below (1 required per assembly) — Replaces: 8M0047347, 8M0054591
		8M0072020 - ECM [ More info ] Unavailable
#4	8M0059367	ECM 350 Bravo, Standard Cooling [1A648623] THRU [2A446466] (1 required per assembly)
		788M0059367 - ECM [ More info ] Unavailable
#4	8M0099865	PCM 350 Bravo, Standard Cooling [2A446467] & Up (1 required per assembly)
		788M0099865 - PCM [ More info ] Unavailable
#4	8M0071885	ECM 350 Bravo, Closed Cooling [1A648622] & Below (1 required per assembly) — Replaces: 8M0047348
		8M0071885 - ECM [ More info ] Unavailable
#4	8M0059368	ECM 350 Bravo, Closed Cooling [1A648623] THRU [2A446466] (1 required per assembly)
		788M0059368 - ECM [ More info ] Unavailable
#4	8M0099867	PCM 350 Bravo, Closed Cooling [2A446467] & Up (1 required per assembly)
		788M0099867 - PCM [ More info ] Unavailable
#4	8M0052738	ECM 377 Bravo, Standard Cooling [1A648622] & Below (1 required per assembly) — Replaces: 8M0047349, 8M0050061
		8M0052738 - ECM [ More info ] Unavailable
#4	8M0059256	ECM 377 Bravo, Standard Cooling [1A648623] THRU [2A446466] (1 required per assembly)
		788M0059256 - ECM [ More info ] Unavailable
#4	8M0099875	PCM 377 Bravo, Standard Cooling [2A446467] & Up (1 required per assembly)
		788M0099875 - PCM [ More info ] Unavailable
#4	8M0052739	ECM 377 Bravo, Closed Cooling [1A648622] & Below (1 required per assembly) — Replaces: 8M0047350
		8M0052739 - ECM [ More info ] Unavailable
#4	8M0059257	ECM 377 Bravo, Closed Cooling [1A648623] THRU [2A446466] (1 required per assembly)
		788M0059257 - ECM [ More info ] Unavailable
#4	8M0099876	PCM 377 Bravo, Closed Cooling [2A446467] & Up (1 required per assembly)
		788M0099876 - PCM [ More info ] Unavailable
#5	65567	WASHER @2 (3 required per assembly)
		12-65567 - Washer, (.265 X .750 X .048) Stainless Steel [ More info ] $2.89 Available to Order: Shipping delay up to 10 days.
#6	834985	GROMMET @5 (3 required per assembly)
		25-834985 - Grommet [ More info ] $3.00 2 In Stock.
		25-8M0190980 - GROMMET Note: Must be ordered in multiples of 5 [ More info ] $3.89 Available to Order: Shipping delay up to 10 days.
#7	856954	BUSHING (3 required per assembly)
		23-856954 - Bushing [ More info ] $6.99 Available to Order: Shipping delay up to 10 days.
#8	879288T32	BRACKET PCM (1 required per assembly)
		879288T32 - Bracket - PCM [ More info ] $76.99 Available to Order: Shipping delay up to 10 days.
#9	82130025	SCREW @5 (3 required per assembly)
		10-821300 25 - Screw [ More info ] $4.09 Available to Order: Shipping delay up to 10 days.
#10	8M0050325	HARNESS ASSEMBLY MAIN ENGINE Digital Throttle and Shift (1 required per assembly)
		84-8M0050325 - Harness [ More info ] $2,069.49 Available to Order: Shipping delay up to 10 days.
#11	8M0055652	TERMINATOR ASSEMBLY 10 PIN (CAN P AND H) (1 required per assembly)
		8M0055652 - Terminator AssemblyB [ More info ] $25.23 Available to Order: Shipping delay up to 10 days.
#12	804352	CLIP FUSE BLOCK MOUNTING (1 required per assembly)
		54-804352 - Clip- Fuse Block [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#13	883562	COVER FUSE (1 required per assembly)
		883562 - Fuse Block Cover [ More info ] $15.59 5 In Stock.
		831960 - Fuse Cover [ More info ] $7.09 1 In Stock.
#14	8M0207772	RELAY-TRIM (5 required per assembly) — Replaces: 882751
		8M0207772 - RELAY-TRIM [ More info ] $17.99 6 In Stock.
		8M0219830 - RELAY-TRIM (8M0219830) [ More info ] $18.69 $18.67 In Stock
#15	832969T20	FUSE-20 AMP @5 (3 required per assembly)
		88-832969T20 - Fuse - Yellow - 20 Amp [ More info ] $7.09 10+ In Stock.
#16	879288T31	BRACKET RELAY (1 required per assembly)
		879288T31 - Bracket - Relay [ More info ] $34.99 Available to Order: Shipping delay up to 10 days.
#17	11178A01	BREAKER CIRCUIT - 50 AMPERE BUTTON RESET [2A054618] & Up (1 required per assembly) — Replaces: 865827T
		88-11178A01 - Circuit Breaker [ More info ] $121.49 $119.78 In Stock
#18	8M0204718	NUT [2A054617] & Below (2 required per assembly) — Replaces: 826709106
		11-8M0204718 - NUT [ More info ] $4.69 Available to Order: Shipping delay up to 10 days.
#18	68219	NUT (#10-32) STAINLESS STEEL [2A054618 ] & Up (2 required per assembly)
		11-68219 - Nut (#10-32) [ More info ] $2.99 10+ In Stock.
#19	830861	SCREW @5 [2A054617] & Below (2 required per assembly)
		10-830861 - Screw - Priced Individually [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#19	45862	SCREW @5 [2A054618 ] & Up (2 required per assembly)
		10-45862 - Screw - Priced Individually [ More info ] $1.40 $1.12 10+ In Stock.
#20	401366	NUT @5 (3 required per assembly)
		11-40136 6 - Nut - Priced Individually [ More info ] $3.59 2 In Stock.
#21	863439	STUD (1 required per assembly)
		16-863439 - Stud [ More info ] $6.59 Available to Order: Shipping delay up to 10 days.
#22	865983T01	HARNESS ASSEMBLY INJECTORS (1 required per assembly)
		84-865983T01 - Injector Harness [ More info ] $380.99 Available to Order: Shipping delay up to 10 days.
#23	865677T01	HARNESS ASSEMBLY TRANSOM (1 required per assembly)
		84-865677T01 - Harness - Transom [ More info ] $124.49 Available to Order: Shipping delay up to 10 days.
#24	8M0113732	HARNESS ASSEMBLY DTS, CLEAN POWER, 14 FEET CLEAN POWER (1 required per assembly) — Replaces: 888416T04
		848M0113732 - Harness, Clean Power [ More info ] $105.85 Available to Order: Shipping delay up to 10 days.
#25	862646	FUSE 5 AMP @5 (1 required per assembly)
		862646 - Fuse, Tan, 5 Amp [ More info ] $4.09 Available to Order: Shipping delay up to 10 days.
#26	828054	COVER-FUSE (1 required per assembly)
		828054 - Fuse Cover [ More info ] $5.89 Available to Order: Shipping delay up to 10 days.
#27	95084A10	CABLE ASSY Bravo (1 required per assembly)
		84-95084A10 - Cable Assembly [ More info ] Unavailable
		84-8M0207788 - CABLE ASSY [ More info ] Unavailable
#28	8M0207796	FUSE-20 AMP @5 Bravo (1 required per assembly) — Replaces: 79091
		888M0207796 - FUSE-20 AMP Note: Priced Individually [ More info ] $9.09 Available to Order: Shipping delay up to 10 days.
#29	95084A9	CABLE ASSY Bravo (1 required per assembly)
		84-95084A 9 - Cable Assembly [ More info ] $30.49 Available to Order: Shipping delay up to 10 days.
#30	8M0157742	SENSOR WATER PRESSURE PRESSURE Power Steering Cooler (1 required per assembly) — Replaces: 881879010, 8M6000623
		71-8M0157742 - Water Pressure Sensor 50PSI [ More info ] $209.99 In Stock
#30	881879T11	SENSOR PRESSURE (0 - 100 PSI) OIL (1 required per assembly)
		881879T11 - Pressure Sensor [ More info ] $196.99 $189.49 In Stock
#31	8M6003194	SENSOR-KNOCK 350/377 Mag (2 required per assembly) — Replaces: 878187
		8M6003194 - Knock Sensor [ More info ] $77.99 In Stock
#32	864337A1	CONNECTOR BLACK JUMPER (1 required per assembly)
		864337A 1 - Connector [ More info ] $17.99 Available to Order: Shipping delay up to 10 days.
#33	816492A15	ALARM KIT (1 required per assembly)
		816492A15 - Alarm Kit [ More info ] $102.32 4 In Stock.
#34	8M2003959	SENSOR-O2 (4 required per assembly)
		8M2003959 - Oxygen Sensor [ More info ] $133.99 $128.99 In Stock
#35	865774T01	HARNESS ASSEMBLY TRIM PUMP (1 required per assembly)
		84-865774T01 - Harness [ More info ] $71.49 Available to Order: Shipping delay up to 10 days.
#36	8M0054509	BRACKET KIT FLUSH (.312 INCH PEM NUT) (1 required per assembly) — Replaces: 8M2003304
		8M0054509 - Bracket Kit-Flush [ More info ] $51.99 Available to Order: Shipping delay up to 10 days.
#37	824941	SCREW (.312-18 X .750) (2 required per assembly)
		10-824941 - Screw [ More info ] $14.99 1 In Stock.
#37	98261	SCREW (.375-16 X .750) (2 required per assembly)
#38	865205	CLIP RELAY MOUNTING (2 required per assembly)
		86-865205 - Clip - Priced Individually [ More info ] $2.99 Available to Order: Shipping delay up to 10 days.
#39	8M0068784	SENDER ASSY (1 required per assembly) — Replaces: 815425T
		8M0068784 - Sender Assembly [ More info ] $133.49 $131.62 In Stock
		18-5899 - Sender, 982650, 815425T [ More info ] $42.99 $41.78 10+ In Stock.
		75-24301 - Mercruiser and OMC Oil Pressure Sender [ More info ] $42.49 $34.16 3 In Stock.
