Parts for 300 HP 4.6L V8 Pro XS 4-Stroke Mercury Outboard Motor Cylinder Head & Camshaft
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 8M0149551 | PWRHD GASKET SET (1 required per assembly) |
  |
|
8M0149551 - Powerhead Gasket Set [ More info ]
|
| #- | 8M0142280 | LONG BLOCK V8 PRO 200/225 HP (See Bulletin 2021-24) (1 required per assembly) |
  |
|
618M0142280 - LONG BLOCK V8 PRO [ More info ] Unavailable |
| #- | 8M0142279 | LONG BLOCK V8 250/300 HP (See Bulletin 2021-24) (1 required per assembly) |
  |
|
618M0142279 - LONG BLOCK V8 [ More info ] Unavailable |
| #1 | 8M0150214 | CYLINDER HEAD ASY Starboard (1 required per assembly) |
  |
9008M0150214 - Cylinder Head ASY [ More info ] Unavailable |
|
  |
|
900-8M0221004 - CYLINDER HEAD ASY [ More info ] Unavailable |
| #1 | 8M0150215 | CYLINDER HEAD ASY Port (1 required per assembly) |
  |
|
9008M0150215 - Cylinder Head ASY [ More info ]
|
| #2 | 8M0142354 | VALVE SEAT, INTAKE (16 required per assembly) |
  |
|
8M0142354 - VALVE SEAT INTAKE [ More info ]
|
| #3 | 8M0142355 | VALVE SEAT, EXHAUST (16 required per assembly) |
  |
|
8M0142355 - SEAT VALVE EXHST [ More info ]
|
| #4 | 8M0142358 | VALVE GUIDE (32 required per assembly) |
  |
|
8M0142358 - Guide VALVE [ More info ]
|
| #5 | NSS | NOT SOLD SEPARATE Cap-Camshaft (18 required per assembly) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #6 | 8M0163131 | SCREW M6 (36 required per assembly) — Replaces: 892454035 |
  |
|
10-8M0163131 - SCREW @2 [ More info ] Unavailable |
| #7 | 8M0142357 | PLUG 21 MM SPECIAL (6 required per assembly) |
  |
|
198M0142357 - PLUG [ More info ]
|
| #8 | 8M0087447 | PLUG (10MM) (12 required per assembly) |
  |
|
198M0087447 - Plug (10MM) [ More info ]
|
| #9 | 8M0087451 | PLUG (18MM) (2 required per assembly) |
  |
|
198M0087451 - PLUG-18MM [ More info ]
|
| #10 | 8M0087453 | PLUG (24 MM) (6 required per assembly) |
  |
|
198M0087453 - PLUG - 24MM [ More info ]
|
| #11 | 8M0087454 | PLUG (30 MM) (2 required per assembly) |
  |
|
198M0087454 - PLUG - 30 MM [ More info ]
|
| #12 | 8M0142364 | VALVE KEY (32 required per assembly) |
  |
|
288M0142364 - KEY VALVE [ More info ]
|
| #13 | 8M0142363 | RETAINER (32 required per assembly) |
  |
|
8M0142363 - Retainer [ More info ]
|
| #14 | 8M0142360 | SPRING (32 required per assembly) |
  |
|
248M0142360 - SPRING VALVE [ More info ]
|
| #15 | 8M0142359 | SEAL VALVE (32 required per assembly) |
  |
|
8M0142359 - Seal VALVE STEM [ More info ]
|
| #16 | 8M0142361 | VALVE INTAKE (16 required per assembly) |
  |
|
8M0142361 - Intake Valve [ More info ]
|
| #17 | 8M0142362 | VALVE EXHAUST (16 required per assembly) |
  |
|
8M0142362 - VALVE Exhaust [ More info ]
|
| #18 | 892454030 | SCREW (M6 X 30) (4 required per assembly) |
  |
|
10-892454030 - Screw - Priced Individually [ More info ]
|
| #19 | 8M0142367 | TENSIONER (2 required per assembly) |
  |
|
8M0142367 - TENSIONER SECOND [ More info ]
|
| #20 | 8M0142366 | CHAIN CAM TO CAM (2 required per assembly) |
  |
|
8M0142366 - CHAIN CAM TO CAM [ More info ]
|
| #21 | 8M0142411 | CAMSHAFT EXHAUST, STARBOARD (1 required per assembly) |
  |
|
4008M0142411 - Camshaft EXHST ST [ More info ]
|
| #21 | 8M0142416 | CAMSHAFT EXHAUST, PORT (1 required per assembly) |
  |
|
4008M0142416 - Camshaft EXHST PT [ More info ]
|
| #22 | 8M0142412 | CAMSHAFT INTAKE, STARBOARD (1 required per assembly) |
  |
|
4008M0142412 - Camshaft INTKE ST [ More info ]
|
| #22 | 8M0142415 | CAMSHAFT INTAKE, PORT (1 required per assembly) |
  |
|
4008M0142415 - Camshaft INTK PT [ More info ]
|
| #23 | 8M0142365 | TAPPET (3.000) (32/AR required per assembly) |
  |
|
8M0142365 - Tappet Bucket [ More info ]
|
| #23 | 8M0142431 | TAPPET (3.015) (32/AR required per assembly) |
  |
|
8M0142431 - Tappet Bucket [ More info ]
|
| #23 | 8M0142439 | TAPPET (3.030) (32/AR required per assembly) |
  |
|
8M0142439 - Tappet Bucket [ More info ]
|
| #23 | 8M0142440 | TAPPET (3.045) (32/AR required per assembly) |
  |
|
8M0142440 - Tappet Bucket [ More info ]
|
| #23 | 8M0142441 | TAPPET (3.060) (32/AR required per assembly) |
  |
|
8M0142441 - Tappet Bucket [ More info ]
|
| #23 | 8M0142438 | TAPPET (3.075) (32/AR required per assembly) |
  |
|
8M0142438 - Tappet Bucket [ More info ]
|
| #23 | 8M0142495 | TAPPET (3.090) (32/AR required per assembly) |
  |
|
8M0142495 - Tappet Bucket [ More info ]
|
| #23 | 8M0142492 | TAPPET (3.105) (32/AR required per assembly) |
  |
|
8M0142492 - Tappet Bucket [ More info ]
|
| #23 | 8M0142443 | TAPPET (3.120) (32/AR required per assembly) |
  |
|
8M0142443 - Tappet Bucket [ More info ]
|
| #23 | 8M0142447 | TAPPET (3.135) (32/AR required per assembly) |
  |
|
8M0142447 - Tappet Bucket [ More info ]
|
| #23 | 8M0142464 | TAPPET (3.150) (32/AR required per assembly) |
  |
|
8M0142464 - Tappet Bucket [ More info ]
|
| #23 | 8M0142465 | TAPPET (3.165) (32/AR required per assembly) |
  |
|
8M0142465 - Tappet Bucket [ More info ]
|
| #23 | 8M0142466 | TAPPET (3.180) (32/AR required per assembly) |
  |
|
8M0142466 - Tappet Bucket [ More info ]
|
| #23 | 8M0142487 | TAPPET (3.195) (32/AR required per assembly) |
  |
|
8M0142487 - Tappet Bucket [ More info ]
|
| #23 | 8M0142488 | TAPPET (3.210) (32/AR required per assembly) |
  |
|
8M0142488 - Tappet Bucket [ More info ]
|
| #23 | 8M0142489 | TAPPET (3.225) (32/AR required per assembly) |
  |
|
8M0142489 - Tappet Bucket [ More info ]
|
| #23 | 8M0142490 | TAPPET (3.240) (32/AR required per assembly) |
  |
|
8M0142490 - Tappet Bucket [ More info ]
|
| #23 | 8M0142491 | TAPPET (3.255) (32/AR required per assembly) |
  |
|
8M0142491 - Tappet Bucket [ More info ]
|
| #23 | 8M0142519 | TAPPET (3.270) (32/AR required per assembly) |
  |
|
8M0142519 - Tappet Bucket [ More info ]
|
| #23 | 8M0142520 | TAPPET (3.285) (32/AR required per assembly) |
  |
|
8M0142520 - Tappet Bucket [ More info ]
|
| #23 | 8M0142521 | TAPPET (3.300) (32/AR required per assembly) |
  |
|
8M0142521 - Tappet Bucket [ More info ]
|
| #23 | 8M0142525 | TAPPET (3.315) (32/AR required per assembly) |
  |
|
8M0142525 - Tappet Bucket [ More info ]
|
| #23 | 8M0142527 | TAPPET (3.330) (32/AR required per assembly) |
  |
|
8M0142527 - Tappet Bucket [ More info ]
|
| #23 | 8M0142532 | TAPPET (3.345) (32/AR required per assembly) |
  |
|
8M0142532 - Tappet Bucket [ More info ]
|
| #23 | 8M0142613 | TAPPET (3.360) (32/AR required per assembly) |
  |
|
8M0142613 - Tappet Bucket [ More info ]
|
| #23 | 8M0142252 | TAPPET (3.375) (32/AR required per assembly) |
  |
|
8M0142252 - Tappet Bucket [ More info ]
|
| #23 | 8M0142255 | TAPPET (3.390) (32/AR required per assembly) |
  |
|
8M0142255 - Tappet Bucket [ More info ]
|
| #23 | 8M0142256 | TAPPET (3.405) (32/AR required per assembly) |
  |
|
8M0142256 - Tappet Bucket [ More info ]
|
| #23 | 8M0142257 | TAPPET (3.420) (32/AR required per assembly) |
  |
|
8M0142257 - Tappet Bucket [ More info ]
|
| #23 | 8M0142258 | TAPPET (3.435) (32/AR required per assembly) |
  |
|
8M0142258 - Tappet Bucket [ More info ]
|
| #23 | 8M0142261 | TAPPET (3.450) (32/AR required per assembly) |
  |
|
8M0142261 - Tappet Bucket [ More info ]
|
| #23 | 8M0142263 | TAPPET (3.465) (32/AR required per assembly) |
  |
|
8M0142263 - Tappet Bucket [ More info ]
|
| #23 | 8M0142277 | TAPPET (3.480) (32/AR required per assembly) |
  |
|
8M0142277 - Tappet Bucket [ More info ]
|
| #23 | 8M0142291 | TAPPET (3.495) (32/AR required per assembly) |
  |
|
8M0142291 - Tappet Bucket [ More info ]
|
| #23 | 8M0142292 | TAPPET (3.510) (32/AR required per assembly) |
  |
|
8M0142292 - Tappet Bucket [ More info ]
|
| #23 | 8M0142666 | TAPPET (3.525) (32/AR required per assembly) |
  |
|
8M0142666 - Tappet Bucket [ More info ]
|
| #23 | 8M0142667 | TAPPET (3.540) (32/AR required per assembly) |
  |
|
8M0142667 - Tappet Bucket [ More info ]
|
| #23 | 8M0142668 | TAPPET (3.555) (32/AR required per assembly) |
  |
|
8M0142668 - Tappet Bucket [ More info ]
|
| #23 | 8M0142669 | TAPPET (3.570) (32/AR required per assembly) |
  |
|
8M0142669 - Tappet Bucket [ More info ]
|
| #23 | 8M0142670 | TAPPET (3.585) (32/AR required per assembly) |
  |
|
8M0142670 - Tappet Bucket [ More info ]
|
| #23 | 8M0142698 | TAPPET (3.600) (32/AR required per assembly) |
  |
|
8M0142698 - Tappet Bucket [ More info ]
|
| #23 | 8M0142699 | TAPPET (3.615) (32/AR required per assembly) |
  |
|
8M0142699 - Tappet Bucket [ More info ]
|
| #23 | 8M0142700 | TAPPET (3.630) (32/AR required per assembly) |
  |
|
8M0142700 - Tappet Bucket [ More info ]
|
| #23 | 8M0142701 | TAPPET (3.645) (32/AR required per assembly) |
  |
|
8M0142701 - Tappet Bucket [ More info ]
|
| #23 | 8M0142702 | TAPPET (3.660) (32/AR required per assembly) |
  |
|
8M0142702 - Tappet Bucket [ More info ]
|
| #23 | 8M0142703 | TAPPET (3.675) (32/AR required per assembly) |
  |
|
8M0142703 - Tappet Bucket [ More info ]
|
| #23 | 8M0142704 | TAPPET (3.690) (32/AR required per assembly) |
  |
|
8M0142704 - Tappet Bucket [ More info ]
|
| #24 | 8M0142369 | SCREW (M10 X 107) TORX FLG HD (20 required per assembly) |
  |
|
108M0142369 - Screw [ More info ]
|
| #25 | 893754035 | SCREW (M6 X 35) (4 required per assembly) |
  |
10893754035 - Screw [ More info ] Unavailable |
|
  |
|
10-8M0168894 - 10-8M0168894 - SCREW [ More info ] Unavailable Replaced by -8M0205943 |
  |
|
10-8M0205943 - SCREW [ More info ] Unavailable |
| #26 | 8M0142273 | GASKET CYLINDER HEAD Starboard (1 required per assembly) |
  |
|
278M0142273 - Head Gasket, Stbd [ More info ]
|
| #26 | 8M0142272 | GASKET CYLINDER HEAD Port (1 required per assembly) |
  |
|
278M0142272 - Head Gasket, Port [ More info ]
|
| #27 | 8M0142368 | ORING (1 required per assembly) |
  |
|
258M0142368 - ORING [ More info ]
|
| #28 | 8M0142537 | GASKET MANIFOLD (1 required per assembly) |
  |
|
278M0142537 - Gasket Manifold [ More info ]
|
