Parts for 5.7Lx Bravo EFI (Gen+) GM 350 V-8 5.7L (350 Cu In) V8 GM MerCruiser Engines - Gas Cylinder Head & Rocker Cover

Revise Search: Sterndrive > MerCruiser Engines - Gas > 5.7L (350 Cu In) V8 GM > 5.7Lx Bravo EFI (Gen+) GM 350 V-8 > 1996 0F800300 - 0K001508 - Belgium > Cylinder Head & Rocker Cover

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Cylinder Head & Rocker Cover

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	75611A96	GASKET SET (1 required per assembly)
		27-75611A96 - Engine Overhaul Gasket Set [ More info ] $673.49 Available to Order: Shipping delay up to 10 days.
#1	809995	COVER-ROCKER-STBD (STARBOARD) (1 required per assembly)
		809995 - Rocker Cover - Stbd [ More info ] $247.99 In Stock
#1	809996	COVER-ROCKER-PORT (PORT) (1 required per assembly)
		809996 - Rocker Cover - Port [ More info ] Unavailable
#2	18710002	CAP OIL FILL (1 required per assembly) — Replaces: 187101
		36-18710002 - Oil Fill Cap [ More info ] $39.85 1 In Stock.
#3	8M0084557	SCREW (8 required per assembly) — Replaces: 17344
		10-8M0084557 - Screw [ More info ] $34.73 4 In Stock.
#4	8M0150306	GASKET ROCKER COVER (2 required per assembly) — Replaces: 17467
		27-8M0150306 - Gasket [ More info ] $112.49 Available to Order: Shipping delay up to 10 days.
#5	173391	PUSH ROD (16 required per assembly)
		0173391 - L/P 128.15 [ More info ] Unavailable
#6	8243171	VALVE EXHAUST (STANDARD) (8 required per assembly)
		824317 1 - Exhaust Valve - Std [ More info ] Unavailable
		8M0231307 - VALVE EXHST STBD [ More info ] Unavailable
#6	8243181	VALVE EXHAUST (.5MM O.S.) (AR required per assembly)
		824318 1 - Exhaust Valve -.030 [ More info ] Unavailable
#7	8M0146076	INTAKE VALVE INTAKE (STANDARD) (8 required per assembly) — Replaces: 809992
		8M0146076 - VALVE-INT 5.7L BX [ More info ] Unavailable
#8	8M0050563	SEAL (16 required per assembly) — Replaces: 976641
		26-8M0050563 - Seal [ More info ] $11.79 10+ In Stock.
#9	483471	SPRING (16 required per assembly)
		24-48347 1 - Spring [ More info ] $44.99 Available to Order: Shipping delay up to 10 days.
#10	483481	CAP (16 required per assembly)
		48348 1 - Cap [ More info ] $19.59 6 In Stock.
#11	547971	KEY @2 (32 required per assembly)
		28-54797 1 - Valve Stem Keeper Key - Priced Individually [ More info ] $17.09 10+ In Stock.
#12	8M0173156	ROCKER ARM KIT ROCKER (16 required per assembly) — Replaces: 35329
		8M0173156 - ROCKER ARM KIT [ More info ] $73.99 Available to Order: Shipping delay up to 10 days.
#13	35331	BALL-ROCKER ARM (16 required per assembly)
		35331 - Ball - Rocker Arm [ More info ] $2.50 $2.13 10+ In Stock.
#14	34516	NUT @2 (16 required per assembly)
		11-34516 - Nut - Priced Individually [ More info ] $23.29 $22.32 10+ In Stock.
#15	97181	CYLINDER HEAD ASSEMBLY (2 required per assembly)
		97181 - CYLINDER HEAD ASSEMBLY NLA [ More info ] Unavailable
#16	34522	STUD (.003 O.S.) (AR required per assembly)
		16-34522 - Stud [ More info ] $15.09 2 In Stock.
#16	34521	STUD (.013 O.S.) (AR required per assembly)
		16-34521 - Stud [ More info ] Unavailable
#17	75611001	GASKET (2 required per assembly) — Replaces: 75611
		27-75611001 - Gasket [ More info ] $65.99 $64.94 In Stock
		18-3876 - Head Gasket 27-75611, 914971 [ More info ] $51.99 $51.48 10+ In Stock.
#18	11968	SCREW (.437-14 X 1.750) (1-3/4&QUOT;) (16 required per assembly)
		10-11968 - Screw [ More info ] $16.29 $7.17 10+ In Stock.
#19	119671	SCREW (.437-14 X 3.00) (3&QUOT;) (4 required per assembly)
		10-11967 1 - Screw [ More info ] $17.89 3 In Stock.
#20	11966	SCREW (.437-14 X 3.750) (3-3/4&QUOT;) (14 required per assembly)
		10-11966 - Screw [ More info ] $17.89 10+ In Stock.
#21	806815T	LIFTING EYE (1 required per assembly)
		806815T - Lifting Eye, NLA [ More info ] $16.00 $13.55 10+ In Stock.
