Parts for 5.7L (2 BBL.) GM 350 V-8 5.7L (350 Cu In) V8 GM MerCruiser Engines - Gas Closed Cooling System

Revise Search: Sterndrive > MerCruiser Engines - Gas > 5.7L (350 Cu In) V8 GM > 5.7L (2 BBL.) GM 350 V-8 > 1998-2001 0L010037 - 0M599999 > Closed Cooling System

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Closed Cooling System

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	774572	HOSE (48.00 INCHES BULK) (1 required per assembly)
		0774572 - L/P 396.35 [ More info ] Unavailable
#-	861246A05	GASKET SET (1 required per assembly) — Replaces: 861246A98
		27-861246A05 - Engine Overhaul Gasket Set [ More info ] $826.99 Available to Order: Shipping delay up to 10 days.
#1	860234A1	EXCHANGER-HEAT (1 required per assembly)
		860234A 1 - Heat Exchanger [ More info ] Unavailable
#2	860326A1	BRACKET ASSY (1 required per assembly)
		860326A 1 - Bracket Assembly [ More info ] $206.49 Available to Order: Shipping delay up to 10 days.
#3	18431	PAD (4.25 X 4.375) (2 required per assembly)
		18431 - Pad [ More info ] $34.99 Available to Order: Shipping delay up to 10 days.
#4	815504388	CLAMP (2 required per assembly)
		54-815504388 - Clamp [ More info ] $26.45 2 In Stock.
#5	71587A10	RECOVERY KIT (See Note) (1 required per assembly)
		71587A10 - Coolant Recovery Kit [ More info ] $97.49 $96.06 In Stock
#6	71587A11	BOTTLE PLASTIC (1 required per assembly)
		71587A11 - Coolant Recovery Bottle [ More info ] $74.99 Available to Order: Shipping delay up to 10 days.
#7	72058	CAP (1 required per assembly)
		72058 - Bottle Cap [ More info ] $11.29 Available to Order: Shipping delay up to 10 days.
#8	861188A1	HSG ASY-THERMOSTA (1 required per assembly)
		861188A 1 - Thermostat Housing Assembly [ More info ] $266.99 Available to Order: Shipping delay up to 10 days.
#9	8071341	SEAL (1 required per assembly)
		25-807134 1 - Thermostat Seal [ More info ] $9.89 4 In Stock.
#10	863874	SLEEVE WATER (1 required per assembly)
		23-863874 - Sleeve [ More info ] $33.11 1 In Stock.
#11	8M0180565	PLUG (1 required per assembly) — Replaces: 32803
		228M0180565 - PLUG [ More info ] $7.99 Available to Order: Shipping delay up to 10 days.
#12	991551	THERMOSTAT (1 required per assembly)
		99155 1 - Thermostat, 160 Degrees [ More info ] $41.49 Available to Order: Shipping delay up to 10 days.
		99155T 1 - Thermostat Kit, 160 Degrees [ More info ] $42.49 Available to Order: Shipping delay up to 10 days.
#13	807075A1	COVER KIT-THERMOS (1 required per assembly)
		807075A 1 - Thermostat Cover Kit [ More info ] $230.49 Available to Order: Shipping delay up to 10 days.
#14	29198	SCREW W/LW @5 (2 required per assembly)
		10-29198 - Screw w/ Lw - Priced Individually [ More info ] Unavailable
#15	8M0113174	SCREW @5 (2 required per assembly) — Replaces: 58640
		10-8M0113174 - Screw, .375-16, Priced Individually [ More info ] $7.29 1 In Stock.
#16	818390	PLUG ASSY (1 required per assembly)
		22-818390 - Plug Assembly [ More info ] $20.39 Available to Order: Shipping delay up to 10 days.
#17	530451	GASKET @5 (2 required per assembly)
		27-53045 1 - Gasket - Priced Individually [ More info ] $5.69 10+ In Stock.
		18-2917-9 - Gasket 27-530451 2-Pack [ More info ] $8.83 Available to Order: Shipping delay up to 10 days.
		27-53045Q01 - Gasket [ More info ] $5.89 7 In Stock.
#18	8M0062634	HOSE-44 INCH (Cut to 6.00 Inch Length) (1 required per assembly) — Replaces: 4285069
		32-8M0062634 - Transom to Thermostat Housing Hose -44I [ More info ] $40.99 In Stock
#19	861058	HOSE-WATER (Alpha - Starboard) [0L618999] & Below (1 required per assembly)
		32-861058 - Water Hose [ More info ] $55.99 Available to Order: Shipping delay up to 10 days.
#19	861057	HOSE-WATER (Bravo - Starboard) [0L618999] & Below (1 required per assembly)
		32-861057 - Water Hose [ More info ] $51.99 $49.92 6 In Stock.
#19	860421	HOSE-WATER (Alpha/Bravo Starboard) [0L619000] & Up (1 required per assembly)
		32-860421 - Water Hose [ More info ] $60.99 Available to Order: Shipping delay up to 10 days.
#20	860421	HOSE-WATER (Port) [0L618999] & Below (1 required per assembly)
#20	862125	HOSE-MOLDED (Port) [0L619000] & Up (1 required per assembly)
		32-862125 - Molded Hose [ More info ] $61.99 Available to Order: Shipping delay up to 10 days.
#21	815504220	CLAMP (4 required per assembly)
		54-815504220 - Clamp [ More info ] $7.59 Available to Order: Shipping delay up to 10 days.
#22	860485	HOSE-WATER [0L618999] & Below (1 required per assembly)
		32-860485 - Water Hose [ More info ] $57.99 Available to Order: Shipping delay up to 10 days.
#22	860331	HOSE-WATER [0L619000] & Up (1 required per assembly)
		32-860331 - Water Hose [ More info ] $35.99 Available to Order: Shipping delay up to 10 days.
#23	860419	HOSE-WATER (1 required per assembly)
		32-860419 - Water Hose [ More info ] $47.99 Available to Order: Shipping delay up to 10 days.
#24	860332	HOSE-WATER (1 required per assembly)
		32-860332 - Water Hose [ More info ] $55.99 $55.15 Available to Order: Shipping delay up to 10 days.
#25	815504222	CLAMP @5 (6 required per assembly)
		54-815504222 - Clamp - See Note On Detail Page [ More info ] Unavailable
		54-8M0188622 - CLAMP [ More info ] Unavailable
#26	861059	HOSE-WATER (1 required per assembly)
		32-861059 - Water Hose [ More info ] $76.49 Available to Order: Shipping delay up to 10 days.
#27	815504232	CLAMP (2 required per assembly)
		54-815504232 - Clamp [ More info ] $8.89 10+ In Stock.
#28	99520	HOSE-MOLDED (1 required per assembly) — Replaces: 860482
		32-99520 - Molded Hose [ More info ] $27.39 In Stock
#29	815504212	CLAMP (4 required per assembly)
		54-815504212 - Clamp [ More info ] Unavailable
#30	860346	ELBOW (1 required per assembly)
		22-860346 - Elbow [ More info ] $44.99 Available to Order: Shipping delay up to 10 days.
#31	808042	CONNECTOR (1 required per assembly)
		22-808042 - Connector [ More info ] $29.99 Available to Order: Shipping delay up to 10 days.
#32	8600891	HOSE-WATER [0L618999] & Below (1 required per assembly)
		32-860089 1 - Water Hose [ More info ] $86.99 Available to Order: Shipping delay up to 10 days.
#32	808045	HOSE FUEL COOLER TO TRANSMISSION OIL COOLER [0L619000] & Up (1 required per assembly)
		32-808045 - Molded Hose [ More info ] $61.99 Available to Order: Shipping delay up to 10 days.
#33	8080441	HOSE-MOLDED (1 required per assembly)
		32-808044 1 - Molded Hose [ More info ] $92.49 Available to Order: Shipping delay up to 10 days.
#34	32877	COVER-PLUG (1 required per assembly)
		32877 - Cover [ More info ] $7.99 $4.48 10+ In Stock.
#35	8M0062666	HOSE-WATER BULK (Cut to 36.00 Inch Length) (1 required per assembly) — Replaces: 86334379, 865672079
		32-8M0062666 - Water Hose Bulk -96" [ More info ] $220.99 $218.15 Available to Order: Shipping delay up to 10 days.
#36	815504228	CLAMP (2 required per assembly)
		54-815504228 - Clamp [ More info ] $17.29 Available to Order: Shipping delay up to 10 days.
		54-8M0232395 - CLAMP HOSE [ More info ] Unavailable
#37	8M0125855	COOLER POWER STEERING (1 required per assembly) — Replaces: 861554T, 861554T01
		8M0125855 - Power Steering Cooler [ More info ] $212.99 In Stock
#38	860315A1	TUBE HOSE EXTENDER (Compact Hydralic Steering) (Cut to 10.50 Inch Length) (1 required per assembly)
		860315A 1 - Tube - Hose Extender [ More info ] $41.49 Available to Order: Shipping delay up to 10 days.
#39	860315A1	TUBE HOSE EXTENDER (Thermostat House To Power Steering Cooler) (1 required per assembly)
#40	8M0119211	PLUG ASSEMBLY (.500-13) BLUE FITTING (1 required per assembly) — Replaces: 806608A1, 806608A02
		22-8M0119211 - Drain Plug, Priced Individually, .5 inch x 13 [ More info ] $10.19 10+ In Stock.
#41	62706	O-RING (.426 X .070) (1 required per assembly)
		25-62706 - O-ring, (.426 X .070) [ More info ] $2.39 10+ In Stock.
#42	860418T	BRACKET (1 required per assembly)
		860418T - Bracket [ More info ] $16.89 Available to Order: Shipping delay up to 10 days.
#43	860417T	CLAMP (1 required per assembly)
		860417T - Clamp [ More info ] $19.09 Available to Order: Shipping delay up to 10 days.
#44	35462	WASHER @2 (1 required per assembly)
		12-35462 - Washer, (.2656 X .625 X .0625) Stainless Steel [ More info ] $1.80 10+ In Stock.
#45	8267088	NUT @5 (1 required per assembly)
		11-826708 8 - Nut [ More info ] $1.70 Available to Order: Shipping delay up to 10 days.
#46	806616	CLAMP @5 (1 required per assembly)
		54-806616 - Clamp [ More info ] $3.09 Available to Order: Shipping delay up to 10 days.
#NS	8M0036623	END CAP (4 INCH) (2 required per assembly) — Replaces: 814875
		8M0036623 - Cap -end [ More info ] $104.99 Available to Order: Shipping delay up to 10 days.
#NS	8M0036987	GASKET (2 required per assembly) — Replaces: 803644
		27-8M0036987 - Heat Exchanger End Gasket [ More info ] $21.99 In Stock
#NS	94247	SCREW (.375-16 X .750) STAINLESS STEEL (2 required per assembly) — Replaces: 814877
		10-94247 - Screw - Priced Individually [ More info ] $1.50 $0.30 6 In Stock.
#NS	8M0039163	O-RING (3/8 X 1/8) (2 required per assembly) — Replaces: 814878
		25-8M0039163 - O-ring, (3/8 X 1/8) [ More info ] $8.79 2 In Stock.
#NS	8148791	CAP (1 required per assembly)
		36-814879 1 - Pressure Cap [ More info ] $60.49 Available to Order: Shipping delay up to 10 days.
#NS	8M0074364	CAP HOSE CLAMP END (AR required per assembly) — Replaces: 8079923, 8M6500037
		198M0074364 - Cover-Clamp - Priced Individually [ More info ] $3.29 $2.64 10+ In Stock.
