Parts for 5.7L (2 BBL.) GM 350 V-8 5.7L (350 Cu In) V8 GM MerCruiser Engines - Gas Cylinder Block & Camshaft (5.7L Alpha / Bravo)

Revise Search: Sterndrive > MerCruiser Engines - Gas > 5.7L (350 Cu In) V8 GM > 5.7L (2 BBL.) GM 350 V-8 > 1996 0F601000 - 0K001526 > Cylinder Block & Camshaft (5.7L Alpha / Bravo)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Cylinder Block & Camshaft (5.7L Alpha / Bravo)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	883944R50	LB 5.7L-RM 87-95 (2 BBL CARBURETOR) (1 required per assembly) — Replaces: 807315A1, 883944R5
		883944R50 - Lb 5.7L-RM 87-95 [ More info ] Unavailable
#-	809825	RTV SILICONE (3 OUNCE TUBE) METALLIC BLUE (WHERE APPLICABLE) (1 required per assembly)
		92-809825 - Rtv Silicone-Blue [ More info ] Unavailable
#-	8M0170149	SEALING COMPOUND (WHERE APPLICABLE) (1 required per assembly) — Replaces: 342271, 34227Q02
		92-8M0170149 - SEALANT-PINT CAN [ More info ] Unavailable
#1	NSS	NOT SOLD SEPARATE CYLINDER BLOCK ASSEMBLY (ORDER LONG BLOCK 807315A1) (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#2	8M0204652	PLUG @2 (3 required per assembly) — Replaces: 48340, 32561
		22-8M0204652 - PLUG @2 [ More info ] Unavailable
#3	816565	PLUG CUP (.468) (5 required per assembly)
		19-816565 - Plug [ More info ] $10.69 $8.56 9 In Stock.
#4	48556	BUSHING REDUCER (.250 TO .125) (2 required per assembly)
		22-48556 - Reducer Bushing [ More info ] $7.99 Available to Order: Shipping delay up to 10 days.
#5	328022	PLUG PIPE (.125-27) BRASS (2 required per assembly) — Replaces: 328021
		22-32802 2 - Brass Pipe Plug, Priced Individually [ More info ] $7.59 1 In Stock.
		18-4263 - Pipe Plug, 1/8-27 NPT, Brass [ More info ] $5.30 10+ In Stock.
#6	34270	EXPANSION PLUG (1.625) (8 required per assembly)
		19-34270 - Freeze Plug, 1-5/8 Inch [ More info ] $9.79 10+ In Stock.
#7	35465	PIN DOWEL (.312) (4 required per assembly)
		17-35465 - Dowel Pin (5/16, Dia.) [ More info ] $6.99 Available to Order: Shipping delay up to 10 days.
#8	72640	PLUG EXPANSION (1 required per assembly)
		22-72640 - Plug [ More info ] $14.19 Available to Order: Shipping delay up to 10 days.
#9	85674	BEARING SET (5) (1 required per assembly)
		23-85674 - Bearing Unit - Camshaft [ More info ] $91.49 Available to Order: Shipping delay up to 10 days.
#10	8M0160608	LIFTER (16 required per assembly) — Replaces: 72638
		8M0160608 - LIFTER [ More info ] $38.49 Available to Order: Shipping delay up to 10 days.
#11	5943	CAMSHAFT (1 required per assembly)
		431-5943 - CamShaft [ More info ] $361.99 Available to Order: Shipping delay up to 10 days.
#12	8M0187687	CHAIN (1 required per assembly) — Replaces: 17161, 17161T
		8M0187687 - CHAIN [ More info ] Unavailable
#13	17159	SPROCKET (1 required per assembly)
		43-17159 - Sprocket,NLA [ More info ] Unavailable
#14	8M0184208	SPROCKET CRANKSHAFT (1 required per assembly) — Replaces: 17160
		43-8M0184208 - SPROCKET [ More info ] Unavailable
#15	8M0043993	SCREW (3 required per assembly) — Replaces: 35339, 845942
		10-8M0043993 - Screw [ More info ] $1.70 Available to Order: Shipping delay up to 10 days.
#16	848136	WASHER (3 required per assembly)
		12-848136 - Washer, (.328 X .680 X .190) [ More info ] $24.79 Available to Order: Shipping delay up to 10 days.
#17	843378	PIN-DOWEL (1 required per assembly) — Replaces: 35312
		17-843378 - Pin, Dowel (.250) [ More info ] $15.99 1 In Stock.
