Parts for 3.5 HP Carb JCI 4-Stroke Mercury Outboard Motor Carburetor All Models-Serial # 0R318095 & Below

Revise Search: Outboard > 4-Stroke Mercury Outboard > 3.5 HP Carb JCI > 0R568285 & Up > Carburetor All Models-Serial # 0R318095 & Below

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Carburetor All Models-Serial # 0R318095 & Below

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	898103A68	REPAIR KIT-CARB (1 required per assembly)
		898103A68 - Carburetor Repair Kit [ More info ] $108.49 Available to Order: Shipping delay up to 10 days.
#-	898103A67	GASKET SET-PH (1 required per assembly)
		27-898103A67 - Powerhead Gasket Set [ More info ] $124.49 Available to Order: Shipping delay up to 10 days.
#1	8M0121978	CARBURETOR 3.5 Horsepower EU [0R221251] & Up (1 required per assembly) — Replaces: 898103T51, 853720T25
		13008M0121978 - Carburetor [ More info ] Unavailable
#1	853720T25	ORD 8M0121978 3.5 Horsepower EU [0R221250] & Below (1 required per assembly) — Replaces: 889246T10, 898103T51
		3303-853720T25 - Carburetor [ More info ] Unavailable
#1	853720T24	CARBURETOR 2.5 Horsepower EU [0R222472] & Up (1 required per assembly) — Replaces: 898103T52, 889246T09
		3303-853720T24 - Carburetor [ More info ] $410.99 Available to Order: Shipping delay up to 10 days.
#1	853720T23	CARBURETOR 2 Horsepower-Complete Only (1 required per assembly) — Replaces: 889246T68
		3303-853720T23 - Carburetor [ More info ] $362.99 Available to Order: Shipping delay up to 10 days.
#2	898101407	SCREW STOP (1 required per assembly)
		10-898101407 - Screw-Stop [ More info ] $14.59 Available to Order: Shipping delay up to 10 days.
#3	803554	SPRING (1 required per assembly)
		24-803554 - Spring, NLA [ More info ] $6.39 $5.12 10+ In Stock.
#4	8035243	JET PILOT (#38) 2.5 Horsepower (1 required per assembly)
		803524 3 - Pilot Jet [ More info ] $20.69 Available to Order: Shipping delay up to 10 days.
#4	803524004	JET PILOT (#35) 3.5 Horsepower (1 required per assembly)
		803524004 - Pilot Jet [ More info ] $18.99 Available to Order: Shipping delay up to 10 days.
#5	898101289	SET SCREW PILOT 2.5 Horsepower (1 required per assembly)
		10-898101289 - Screw Set -Pilot [ More info ] $20.89 Available to Order: Shipping delay up to 10 days.
#5	898101800	SET SCREW PILOT 3.5 Horsepower (1 required per assembly)
		10-898101800 - Screw Set -Pilot [ More info ] $17.49 Available to Order: Shipping delay up to 10 days.
#6	898101801	SET SCREW PILOT 2.5 Horsepower EU [0R222471] & Below (1 required per assembly)
		10-898101801 - SET SCREW Pilot [ More info ] Unavailable
#6	898101802	SET SCREW PILOT 3.5 Horsepower EU [0R221250] & Below (1 required per assembly)
		10-898101802 - SET SCREW Pilot [ More info ] Unavailable
#7	898101286	MAIN NOZZLE 3.5 Horsepower (1 required per assembly)
		898101286 - Main Nozzle [ More info ] $25.49 Available to Order: Shipping delay up to 10 days.
#7	898101287	MAIN NOZZLE 2.5 Horsepower (1 required per assembly)
		898101287 - Main Nozzle [ More info ] $28.08 1 In Stock.
#8	16250011	JET MAIN (#68) 3.5 Horsepower (1 required per assembly)
		16250011 - Main Jet [ More info ] $18.95 1 In Stock.
#8	898101364	JET MAIN (#62) 2.5 Horsepower (1 required per assembly)
		898101364 - #62 Main Jet - [ More info ] $21.49 Available to Order: Shipping delay up to 10 days.
#9	162543	FLOAT VALVE BRASS (1 required per assembly)
		16254 3 - Float Valve [ More info ] $28.99 1 In Stock.
#10	803525	CLIP STAINLESS STEEL (1 required per assembly)
		54-803525 - Clip [ More info ] $7.99 1 In Stock.
#11	898101288	FLOAT (1 required per assembly)
		898101288 - Float [ More info ] Unavailable
#12	162562	PIN FLOAT - STAINLESS STEEL (1 required per assembly)
		17-16256 2 - Carburetor Float Pin [ More info ] $6.89 Available to Order: Shipping delay up to 10 days.
#13	16258T5	FLOAT BOWL (1 required per assembly)
		16258T 5 - Float Bowl [ More info ] $91.99 Available to Order: Shipping delay up to 10 days.
#14	8035084	GASKET RUBBER (1 required per assembly)
		27-803508 4 - Gasket [ More info ] $16.99 4 In Stock.
#15	8035093	SCREW DRAIN (M5 X 6) (1 required per assembly)
		10-803509 3 - Drain Screw [ More info ] $11.79 Available to Order: Shipping delay up to 10 days.
#16	8035131	O-RING RUBBER (1 required per assembly)
		25-803513 1 - O-Ring [ More info ] $4.69 Available to Order: Shipping delay up to 10 days.
#17	16260	SCREW (M4 X 12) (2 required per assembly)
		10-16260 - Screw [ More info ] $4.99 Available to Order: Shipping delay up to 10 days.
#18	8M0057112	HOSE (2 required per assembly) — Replaces: 898101365, 8129404
		328M0057112 - Hose [ More info ] $22.49 Available to Order: Shipping delay up to 10 days.
#19	879147T98	MANIFOLD-INTAKE (1 required per assembly) — Replaces: 898103T53
		879147T98 - Intake Manifold [ More info ] $158.99 Available to Order: Shipping delay up to 10 days.
#20	16830A1	SCREW KIT (2 required per assembly)
		10-16830A 1 - Screw Kit [ More info ] $5.09 Available to Order: Shipping delay up to 10 days.
#21	898101291	GASKET (1 required per assembly)
		27-898101291 - Intake Manifold Gasket [ More info ] Unavailable
#22	803508013	GASKET @4 (2 required per assembly) — Replaces: 898101290
		27-803508013 - Carburetor Gasket [ More info ] $5.09 2 In Stock.
#23	80350810	GASKET (1 required per assembly)
		27-803508 10 - Insulator Gasket [ More info ] Unavailable
#24	16832	BOLT (1 required per assembly)
		10-16832 - Bolt [ More info ] $4.49 Available to Order: Shipping delay up to 10 days.
#25	803528	BRACKET (1 required per assembly)
		803528 - Bracket [ More info ] $4.59 4 In Stock.
#26	898101293	CABLE (1 required per assembly)
		898101293 - Choke Link Cable [ More info ] $19.09 Available to Order: Shipping delay up to 10 days.
#27	804371001	COLLAR (1 required per assembly) — Replaces: 804371
		23-804371001 - Collar [ More info ] Unavailable
#28	8M0121984	SILENCER - AIR (1 required per assembly) — Replaces: 803526T
		8M0121984 - SILENCER - AIR [ More info ] Unavailable
#29	400212	NUT (1 required per assembly) — Replaces: 853722022
		11-40021 2 - Nut [ More info ] $2.89 2 In Stock.
#30	952868	COLLAR (2 required per assembly)
		23-95286 8 - Collar [ More info ] $3.69 Available to Order: Shipping delay up to 10 days.
#31	803527	TRAP-FLAME (1 required per assembly)
		803527 - Flame Trap [ More info ] $8.79 Available to Order: Shipping delay up to 10 days.
#32	16826	WASHER (2 required per assembly) — Replaces: 895106, 879194338
		12-16826 - Washer, Stainless Steel [ More info ] $3.29 1 In Stock.
#33	898103229	BOLT @2 (2 required per assembly) — Replaces: 898101292
		10-898103229 - Bolt [ More info ] $11.19 1 In Stock.
#34	879194248	BOLT (1 required per assembly) — Replaces: 823042038
		10-879194248 - Bolt [ More info ] $6.09 Available to Order: Shipping delay up to 10 days.
#35	161404	WASHER (1 required per assembly)
		12-16140 4 - Washer [ More info ] $4.29 2 In Stock.
#36	8M0155131	ROD CHOKE (1 required per assembly) — Replaces: 804646
		8M0155131 - Choke Rod [ More info ] $15.69 Available to Order: Shipping delay up to 10 days.
