Parts for 4.5L MPI 200 Alpha / Bravo 4.5L (274 Cu In) V6 Mercury MerCruiser Engines - Gas Cylinder Block, Camshaft, Crankshaft, & Balanceshaft

Revise Search: Sterndrive > MerCruiser Engines - Gas > 4.5L (274 Cu In) V6 Mercury > 4.5L MPI 200 Alpha / Bravo > 2A441953 - 2A530777 > Cylinder Block, Camshaft, Crankshaft, & Balanceshaft

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Cylinder Block, Camshaft, Crankshaft, & Balanceshaft

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	8M0114790	NEW QUICKSILVER LONG BLOCK 4.5L 2014-UP (1 required per assembly) — Replaces: 8M0095517
		8M0114790 - LB 4.5L 2014-UP [ More info ] Unavailable
#1	NSS	NOT SOLD SEPARATE CYLINDER BLOCK (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#2	8M0087447	PLUG (10MM) (6 required per assembly) — Replaces: 8M0048146
		198M0087447 - Plug (10MM) [ More info ] $5.89 Available to Order: Shipping delay up to 10 days.
#3	8M0087451	PLUG (18MM) (5 required per assembly) — Replaces: 8M0047995
		198M0087451 - PLUG-18MM [ More info ] $7.79 Available to Order: Shipping delay up to 10 days.
#4	8M6002412	PLUG (1.64) (3 required per assembly)
		198M6002412 - PLUG [ More info ] $3.29 Available to Order: Shipping delay up to 10 days.
#5	8M6002413	PLUG (2.14) (4 required per assembly)
		198M6002413 - PLUG [ More info ] $3.79 Available to Order: Shipping delay up to 10 days.
#6	8M6002001	BEARING (1 required per assembly)
		238M6002001 - Bushing [ More info ] $18.29 Available to Order: Shipping delay up to 10 days.
#7	8M0087453	PLUG (24 MM) (2 required per assembly) — Replaces: 8M0047996
		198M0087453 - PLUG - 24MM [ More info ] $7.99 Available to Order: Shipping delay up to 10 days.
#8	8M6003344	VALVE ASSEMBLY OIL BYPASS OIL BYPASS VALVE (1 required per assembly)
		8M6003344 - OIL BYPASS VALVE [ More info ] $10.59 Available to Order: Shipping delay up to 10 days.
#9	8M0095939	SHAFT ASSEMBLY (1 required per assembly)
		8M0095939 - Shaft ASSEMBLY [ More info ] $184.99 Available to Order: Shipping delay up to 10 days.
#10	8M0076339	DOWEL PIN (1 required per assembly)
		178M0076339 - DOWEL PIN [ More info ] $8.59 Available to Order: Shipping delay up to 10 days.
#11	8M6002000	BEARING (1 required per assembly)
		308M6002000 - Bearing [ More info ] $40.49 Available to Order: Shipping delay up to 10 days.
#12	8M0076338	RETAINER (1 required per assembly)
		8M0076338 - Retainer [ More info ] $1.90 Available to Order: Shipping delay up to 10 days.
#13	8M0085530	SCREW (2 required per assembly)
		108M0085530 - Screw [ More info ] $1.40 Available to Order: Shipping delay up to 10 days.
#14	8M0095940	GEAR (1 required per assembly)
		438M0095940 - GEAR [ More info ] Unavailable
#14	8M0173289	GEAR SET (1 required per assembly)
		43-8M0173289 - GEAR SET [ More info ] Unavailable
#15	NSS	NOT SOLD SEPARATE CAMSHAFT GEAR Included in 8M0173289 (1 required per assembly)
#16	8M0080292	SCREW (1 required per assembly)
		108M0080292 - Screw [ More info ] $11.69 Available to Order: Shipping delay up to 10 days.
#17	8M0087229	SCREW (6 required per assembly)
		108M0087229 - Screw [ More info ] $1.99 Available to Order: Shipping delay up to 10 days.
#18	8M0074181	LIFTER GUIDE [2A506005] & Below (2 required per assembly)
		8M0074181 - LIFTER Guide [ More info ] $11.39 Available to Order: Shipping delay up to 10 days.
#18	8M0113651	LIFTER GUIDE [2A506006] & Up (2 required per assembly)
		8M0113651 - LIFTER Guide [ More info ] $10.59 Available to Order: Shipping delay up to 10 days.
#19	849947T01	LIFTER [2A506006] & Below (12 required per assembly)
		849947T01 - Lifter [ More info ] $183.49 Available to Order: Shipping delay up to 10 days.
#19	8M0117000	LIFTER ASSEMBLY [2A506006] & Up (12 required per assembly)
		8M0117000 - LIFTER ASSEMBLY [ More info ] $24.99 Available to Order: Shipping delay up to 10 days.
#20	8M0095922	CAMSHAFT ASSEMBLY (1 required per assembly)
		4008M0095922 - Camshaft ASSEMBLY [ More info ] Unavailable
		8M0153976 - CAMSHAFT ASSEMBLY [ More info ] Unavailable
#21	8M0068763	PIN DOWEL (1 required per assembly)
		178M0068763 - PIN-DOWEL [ More info ] $0.50 Available to Order: Shipping delay up to 10 days.
#22	8M0079045	RETAINER (1 required per assembly)
		238M0079045 - Retainer [ More info ] $8.19 Available to Order: Shipping delay up to 10 days.
#23	8M0079046	BOLT (2 required per assembly)
		108M0079046 - Bolt [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#24	8M0127097	BEARING SET (1 required per assembly) — Replaces: 8M0096749
		238M0127097 - Bearing Set [ More info ] Unavailable
#25	8M6002624	SEAL (1 required per assembly)
		268M6002624 - Seal [ More info ] $27.69 Available to Order: Shipping delay up to 10 days.
#26	8M0095918	CRANKSHAFT ASSY (1 required per assembly)
		4008M0095918 - CrankShaft [ More info ] $2,785.99 Available to Order: Shipping delay up to 10 days.
#27	8M0068619	PIN DOWEL (1 required per assembly)
		178M0068619 - DOWEL PIN [ More info ] $2.49 Available to Order: Shipping delay up to 10 days.
#28	8M0068620	KEY (1 required per assembly)
		288M0068620 - KEY [ More info ] $1.20 Available to Order: Shipping delay up to 10 days.
#29	8M0095916	BEARING SET (3 required per assembly)
		238M0095916 - Bearing Set [ More info ] $30.49 Available to Order: Shipping delay up to 10 days.
#30	8M0095917	BEARING SET (1 required per assembly)
		238M0095917 - Bearing Set [ More info ] $81.99 Available to Order: Shipping delay up to 10 days.
#31	8M0079283	SCREW (M10 X 1.50 X 86) (10.9 GRADE) [2A528820] & Below (8 required per assembly)
		108M0079283 - Screw [ More info ] $2.19 Available to Order: Shipping delay up to 10 days.
#31	8M0114263	SCREW (M10 X 1.50 X 86) (12.9 GRADE) [2A528821] & Up (8 required per assembly)
		108M0114263 - Screw [ More info ] $3.79 Available to Order: Shipping delay up to 10 days.
#32	8M0058586	DOWEL PIN (4 required per assembly)
		178M0058586 - Dowel Pin [ More info ] $5.99 Available to Order: Shipping delay up to 10 days.
