Parts for 25 HP EFI Jet 3 Cyl 4-Stroke Mercury Outboard Motor Gear Housing Propeller Shaft -1.92:1 Gear Ratio

Revise Search: Outboard > 4-Stroke Mercury Outboard > 25 HP EFI Jet 3 Cyl > 0R165086 - 1R162636 - USA > Gear Housing Propeller Shaft -1.92:1 Gear Ratio

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Gear Housing Propeller Shaft -1.92:1 Gear Ratio

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	8M0057248	GC 25/30 4S SH (1 required per assembly) — Replaces: 825132T22, 825132T35
		1668-8M0057248 - 1668-8M0057248 - GC 25/30 4S SH [ More info ] Unavailable Replaced by 1668-8M0070899
		16688M0070899 - Gear Housing Complete [ More info ] Unavailable
#-	8M0070900	GC 25/30 4S LG (1 required per assembly) — Replaces: 825132T23, 825132T36
		16688M0070900 - Gearcase 25/30 4S LG [ More info ] Unavailable
#-	8M0157393	GC 25/30 4S XL (1 required per assembly)
		1600-8M0157393 - GC 25/30 4S XL [ More info ] Unavailable
#-	8M0149926	GASKET OIL SEAL [0R515497] & Up (1 required per assembly) — Replaces: 804908A01, 8M0089636
		8M0149926 - Oil Seal Gasket [ More info ] $51.99 Available to Order: Shipping delay up to 10 days.
#1	825132T34	GEAR HSG. BASIC (1 required per assembly) — Replaces: 825132T04, 825132T29
		1668-825132T34 - Gear Housing Basic [ More info ] Unavailable
		16688M0057242 - Gearcase Basic 25/30 4S [ More info ] $740.49 Available to Order: Shipping delay up to 10 days.
#2	16128T01	BEARING ASSEMBLY (1 required per assembly)
		30-16128T01 - Bearing [ More info ] $54.99 Available to Order: Shipping delay up to 10 days.
#3	161631	SHIM (0.1) (AR required per assembly)
		[ More info ] Unavailable
#3	8132761	SHIM (0.15) (AR required per assembly)
		15-813276 1 - Shim [ More info ] $8.79 Available to Order: Shipping delay up to 10 days.
#4	812944T01	GEAR FORWARD - 23 TEETH (1 required per assembly)
		43-812944T01 - Forward Gear [ More info ] Unavailable
		43-8M0183179 - FORWARD GEAR [ More info ] Unavailable
#5	161521	FOLLOWER CAM (1 required per assembly)
		0161521 - L/P .25 [ More info ] Unavailable
#6	161322	BALL STEEL (1 required per assembly)
		30-16132 2 - Ball - Steel [ More info ] $4.19 Available to Order: Shipping delay up to 10 days.
#7	853764003	RETAINER (1 required per assembly) — Replaces: 853764
		853764003 - Retainer [ More info ] $33.11 1 In Stock.
#8	8126453	SPRING (1 required per assembly)
		24-812645 3 - Spring [ More info ] $4.79 Available to Order: Shipping delay up to 10 days.
#9	898103T30	CLUTCH (1 required per assembly)
		52-898103T30 - Clutch [ More info ] $136.02 1 In Stock.
#10	161501	PIN (1 required per assembly)
		17-16150 1 - Pin [ More info ] $6.09 Available to Order: Shipping delay up to 10 days.
#11	176672	SPRING (1 required per assembly)
		24-17667 2 - Spring [ More info ] $4.59 Available to Order: Shipping delay up to 10 days.
#12	19513T01	PROPELLER SHAFT (1 required per assembly)
		44-19513T01 - Propeller Shaft [ More info ] $527.49 Available to Order: Shipping delay up to 10 days.
#13	161401	WASHER (1 required per assembly)
		12-16140 1 - Washer [ More info ] $15.59 Available to Order: Shipping delay up to 10 days.
#14	898103T29	GEAR REVERSE - 23 TEETH (1 required per assembly)
		43-898103T29 - Reverse Gear [ More info ] $329.49 Available to Order: Shipping delay up to 10 days.
#15	8M0070880	CARRIER ASSEMBLY BEARING [0R515497] & Up (1 required per assembly) — Replaces: 825119T01
		8M0070880 - Bearing Carrier [ More info ] $241.49 Available to Order: Shipping delay up to 10 days.
#16	161311	O-RING (1 required per assembly)
		25-16131 1 - O-Ring [ More info ] $11.09 1 In Stock.
#17	16132T01	BEARING BALL (1 required per assembly)
		30-16132T01 - Ball Bearing [ More info ] $44.49 Available to Order: Shipping delay up to 10 days.
#18	813048T05	BEARING NEEDLE (1 required per assembly)
		31-813048T05 - Bearing - Needle [ More info ] $35.49 Available to Order: Shipping delay up to 10 days.
#19	161301	SEAL OIL [0R515496] & Below (1 required per assembly)
		26-16130 1 - Oil Seal [ More info ] $22.36 1 In Stock.
#19	8M0079092	SEAL OIL [0R515497] & Up (2 required per assembly)
		268M0079092 - Oil Seal [ More info ] $12.39 Available to Order: Shipping delay up to 10 days.
#20	879194273	BOLT (2 required per assembly) — Replaces: 823042050
		10-879194273 - Bolt [ More info ] $6.89 Available to Order: Shipping delay up to 10 days.
#21	161452	THRUST HUB (1 required per assembly)
		16145 2 - Thrust Hub [ More info ] $38.99 Available to Order: Shipping delay up to 10 days.
#22	896890A10	BLKMAX 10X8 RH (AR required per assembly)
		48-896890A10 - Black Max Prop 10X8 Rh [ More info ] $181.97 Available to Order: Shipping delay up to 10 days.
#22	896892A40	BLKMAX 9.75X9.5RH (AR required per assembly)
		48-896892A40 - Black Max Prop 9.75X9.5RH [ More info ] $181.97 Available to Order: Shipping delay up to 10 days.
#22	896896A40	BLKMAX 9.5X11 RH (AR required per assembly)
		48-896896A40 - Black Max Prop 9.5X11 Rh [ More info ] $181.97 Available to Order: Shipping delay up to 10 days.
#22	896900A40	BKMAX 9.25X12.5RH (AR required per assembly)
		48-896900A40 - Bkmax 9.25X12.5RH [ More info ] $181.97 Available to Order: Shipping delay up to 10 days.
#23	161402	WASHER (1 required per assembly)
		12-16140 2 - Washer [ More info ] $10.29 Available to Order: Shipping delay up to 10 days.
#24	161471	PROP NUT (1 required per assembly)
		11-16147 1 - Prop Nut [ More info ] $12.12 Available to Order: Shipping delay up to 10 days.
#25	8150264	COTTER PIN (1 required per assembly)
		18-815026 4 - Cotter Pin [ More info ] $3.19 Available to Order: Shipping delay up to 10 days.
