Parts for 3.0L GM 181 I / L4 3.0L (181 Cu In) L4 GM MerCruiser Engines - Gas Steering Components

Revise Search: Sterndrive > MerCruiser Engines - Gas > 3.0L (181 Cu In) L4 GM > 3.0L GM 181 I / L4 > 1A020544 & Up > Steering Components

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Steering Components

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	866280A04	PUMP PWR STEERING (1 required per assembly)
		866280A04 - Pump Power Steering [ More info ] Unavailable
#2	95805	CAP (1 required per assembly)
		36-95805 - Cap [ More info ] $29.49 Available to Order: Shipping delay up to 10 days.
#3	866106T	PULLEY PWR STRING (1 required per assembly)
		866106T - Pulley Power Steering [ More info ] $123.49 Available to Order: Shipping delay up to 10 days.
#4	866144T	BRACKET (866144) (1 required per assembly)
		866144T - Bracket (866144) [ More info ] $44.99 Available to Order: Shipping delay up to 10 days.
#5	866145T	BRACKET (866145) (1 required per assembly)
		866145T - Bracket (866145) [ More info ] $58.99 Available to Order: Shipping delay up to 10 days.
#6	40001137	SCREW @4 (4 required per assembly)
		10-40001137 - Screw, NLA [ More info ] $3.19 $0.64 10+ In Stock.
#7	65606T	BRACKET (1 required per assembly)
		65606T - Bracket [ More info ] $225.49 Available to Order: Shipping delay up to 10 days.
#8	96818	BUSHING (1 required per assembly)
		23-96818 - Bushing [ More info ] $17.39 2 In Stock.
#9	37612	SCREW @5 (2 required per assembly)
		10-37612 - Screw - Priced Individually [ More info ] $2.49 3 In Stock.
#10	96772A1	BRACE POWER STEERING ADJUSTING (1 required per assembly)
		96772A 1 - Brace Assembly [ More info ] $90.49 Available to Order: Shipping delay up to 10 days.
#11	72057	SPACER (1 required per assembly)
		23-72057 - Spacer - Pump Screw [ More info ] $7.99 Available to Order: Shipping delay up to 10 days.
#12	34714	WASHER (1 required per assembly)
		12-34714 - Washer [ More info ] $2.39 2 In Stock.
#13	32219	NUT @5 (1 required per assembly)
		11-32219 - Nut (3/8-16) [ More info ] $2.79 10+ In Stock.
#14	65607Q	V BELT, 37 LGTH (1 required per assembly)
		57-65607Q - V-Belt, 37 Inch Length [ More info ] $27.69 In Stock
		18-15370 - V-Belt [ More info ] $29.20 1 In Stock.
#15	8M0063021	HOSE-POWER STEER. (1 required per assembly) — Replaces: 866687
		32-8M0063021 - Hose - Power Steering [ More info ] $266.99 Available to Order: Shipping delay up to 10 days.
#16	89879	O RING (1 required per assembly)
		25-89879 - O-ring, (.301 X .064) [ More info ] $1.60 Available to Order: Shipping delay up to 10 days.
#17	865390015	HOSE-HYDRAULIC (1 required per assembly)
		32-865390015 - Hydraulic Hose [ More info ] $63.99 In Stock
#18	8M0062341	HOSE (53.00 INCHES BULK) PUMP TO OIL COOLER (Cut to 37.00 Inch Length) (1 required per assembly) — Replaces: 5251914
		32-8M0062341 - Hose -53 Inch [ More info ] $54.99 In Stock
#19	815504105	CLAMP (3 required per assembly)
		54-815504105 - Clamp [ More info ] Unavailable
		54-8M0188618 - CLAMP [ More info ] Unavailable
#NS	8M0074363	CAP HOSE CLAMP END (AR required per assembly) — Replaces: 8079921
		198M0074363 - Cover-.250 , Priced Individually [ More info ] $3.09 Available to Order: Shipping delay up to 10 days.
