Parts for 225 HP EFI 4-Stroke Mercury Outboard Motor Gear Housing Propeller Shaft - Standard

Revise Search: Outboard > 4-Stroke Mercury Outboard > 225 HP EFI > 0T653945 & Up - USA > Gear Housing Propeller Shaft - Standard

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Gear Housing Propeller Shaft - Standard

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	888680T06	GC 225 4ST XL (X-Long) [1B227000] & Up (1 required per assembly) — Replaces: 888680T2
		1623-888680T06 - Gear Housing Assembly [ More info ] Unavailable
#-	888680T07	GC 225 4ST XXL (XX-Long) [1B227000] & Up (1 required per assembly) — Replaces: 888680T3
		1623-888680T07 - Gear Housing Assembly [ More info ] Unavailable
#-	888658A03	GASKET SET [0T807875] & Below (1 required per assembly)
		27-888658A03 - Gasket Set [ More info ] Unavailable
#-	888658A04	GASKET SET [0T807876] & Up (1 required per assembly)
		27-888658A04 - Lower Unit Gasket Set [ More info ] Unavailable
#1	888680T1	GEAR HOUSING ASSEMBLY BASIC (BASIC) (1 required per assembly)
		1623-888680T 1 - Basic Gear Housing [ More info ] Unavailable
#2	888700	SHIFTER (1 required per assembly)
		888700 - Shifter [ More info ] Unavailable
#3	888713A1	SHIM SET (AR required per assembly)
		15-888713A 1 - Shim Set [ More info ] $11.89 Available to Order: Shipping delay up to 10 days.
#4	8886811	BEARING (1 required per assembly)
		31-888681 1 - Bearing [ More info ] Unavailable
#5	888698T	GEAR FORWARD [1B226999] & Below (1 required per assembly)
		43-888698T - Forward Gear [ More info ] Unavailable
#5	8M0095244	GEAR-FORWARD [1B227000] & Up (1 required per assembly) — Replaces: 888698T02
		438M0095244 - GEAR-FORWARD [ More info ] $480.99 Available to Order: Shipping delay up to 10 days.
#6	888701	SHIFT SLIDE (1 required per assembly)
		888701 - Slide- Shift [ More info ] $59.78 $50.64 3 In Stock.
#7	82346M	BALL (2 required per assembly)
		82346M - Ball [ More info ] $1.00 $0.85 4 In Stock.
#8	8813142	NUT (2 required per assembly)
		11-881314 2 - Nut - Priced Individually [ More info ] Unavailable
#9	888704	SHAFT (1 required per assembly)
		888704 - Shaft [ More info ] $1.99 $1.68 5 In Stock.
#10	888705	PLUNGER (2 required per assembly)
		888705 - Plunger [ More info ] $3.99 $3.37 10+ In Stock.
#11	8887031	SPRING (1 required per assembly)
		24-888703 1 - Spring [ More info ] $2.99 $2.53 6 In Stock.
#12	8043051	WASHER (1 required per assembly)
		12-804305 1 - Washer [ More info ] $2.90 1 In Stock.
#13	888702	CLUTCH (1 required per assembly)
		52-888702 - Clutch [ More info ] $204.71 4 In Stock.
#14	8886331	PIN (1 required per assembly)
		17-888633 1 - Pin -cross [ More info ] $6.00 $5.08 10 In Stock.
#15	888703	SPRING (1 required per assembly)
		24-888703 - Spring [ More info ] $1.50 $1.28 10+ In Stock.
#16	888699	PROPELLER SHAFT (1 required per assembly)
		44-888699 - Shaft - Prop [ More info ] Unavailable
#17	8043052	WASHER (1 required per assembly)
		12-804305 2 - Washer [ More info ] $2.00 $1.69 10+ In Stock.
#18	888707T	GEAR REVERSE [1B226999] & Below (1 required per assembly)
		43-888707T - Reverse Gear [ More info ] $177.99 Available to Order: Shipping delay up to 10 days.
#18	888707T02	GEAR REVERSE [1B227000] & Up (1 required per assembly)
		43-888707T02 - Reverse Gear [ More info ] Unavailable
#19	888714A1	SHIM SET (AR required per assembly)
		15-888714A 1 - Shim Set [ More info ] $11.89 $2.38 3 In Stock.
#20	8886814	BEARING (1 required per assembly)
		31-888681 4 - Bearing [ More info ] $55.00 $46.58 6 In Stock.
#21	8814373	O-RING (2 required per assembly)
		25-881437 3 - O-Ring - Priced Individually [ More info ] $9.39 Available to Order: Shipping delay up to 10 days.
#22	888706T	CARRIER BEARING (1 required per assembly)
		888706T - Bearing Carrier [ More info ] $285.99 $68.58 3 In Stock.
#23	8883741	FITTING GREASE (1 required per assembly)
		22-888374 1 - Grease Fitting [ More info ] Unavailable
#24	8M0086362	BOLT @2 (2 required per assembly) — Replaces: 8813111
		108M0086362 - Bolt [ More info ] Unavailable
#25	8043053	WASHER (2 required per assembly)
		12-804305 3 - Washer - Priced Individually [ More info ] $6.00 $5.08 2 In Stock.
#26	8886815	BEARING (1 required per assembly)
		31-888681 5 - Bearing [ More info ] Unavailable
#27	8886941	SEAL OIL (2 required per assembly)
		26-888694 1 - Oil Seal [ More info ] Unavailable
#28	888708	CAP (1 required per assembly)
		888708 - Cap [ More info ] $65.00 $55.06 5 In Stock.
#29	881816	BOLT (M8 X 20) (2 required per assembly)
		10-881816 - Bolt [ More info ] $2.50 $2.13 9 In Stock.
#30	887974	PIN-COTTER (1 required per assembly)
		18-887974 - Cotter Pin [ More info ] Unavailable
#31	8539481	THRUST WASHER (1 required per assembly)
		12-853948 1 - Thrust Washer [ More info ] $45.40 Available to Order: Shipping delay up to 10 days.
#32	887972	WASHER @2 (1 required per assembly)
		12-887972 - Washer - Priced Individually [ More info ] $3.59 1 In Stock.
#33	859939	PROP NUT (1 required per assembly) — Replaces: 887973
		859939 - Prop Nut [ More info ] Unavailable
		8M0214972 - PROP NUT [ More info ] Unavailable
