Parts for 225 HP 3.4L V6 4-Stroke Mercury Outboard Motor Gear Housing Driveshaft, 4.80 Torpedo

Revise Search: Outboard > 4-Stroke Mercury Outboard > 225 HP 3.4L V6 > 2B529482 & Up - USA > Gear Housing Driveshaft, 4.80 Torpedo

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Gear Housing Driveshaft, 4.80 Torpedo

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	8M0142293	GC L BLK (1 required per assembly)
		16008M0142293 - GC L BLK [ More info ] Unavailable
		1600-8M0235804 - GC L BLK [ More info ] Unavailable
#-	8M0142295	GC XL BLK (1 required per assembly)
		16008M0142295 - GC XL BLK [ More info ] Unavailable
		1600-8M0235806 - GC XL BLK [ More info ] Unavailable
#-	8M0142300	GC XXL BLK (1 required per assembly)
		16008M0142300 - GC XXL BLK [ More info ] Unavailable
		1600-8M0235810 - GC XXL BLK [ More info ] Unavailable
#-	8M0142294	GC L SIL (1 required per assembly)
		16008M0142294 - GC L SIL [ More info ] Unavailable
		1600-8M0228010 - 1600-8M0228010 - GC L SIL [ More info ] Unavailable Replaced by -8M0235805
		1600-8M0235805 - GC L SIL [ More info ] Unavailable
#-	8M0142296	GC XL SIL (1 required per assembly)
		16008M0142296 - GC XL SIL [ More info ] Unavailable
		1600-8M0228011 - 1600-8M0228011 - GC XL SIL [ More info ] Unavailable Replaced by -8M0235807
		1600-8M0235807 - GC XL SIL [ More info ] Unavailable
#-	8M0142299	GC XXL SIL (1 required per assembly)
		16008M0142299 - GC XXL SIL [ More info ] Unavailable
		1600-8M0228013 - GC XXL SIL [ More info ] Unavailable
#-	8M0142297	GC CXL BLK (1 required per assembly)
		16008M0142297 - GC CXL BLK [ More info ] Unavailable
		1600-8M0235808 - GC CXL BLK [ More info ] Unavailable
#-	8M0142301	GC CXXL BLK (1 required per assembly)
		16008M0142301 - GC CXXL BLK [ More info ] Unavailable
#-	8M0142298	GC CXL SIL (1 required per assembly)
		16008M0142298 - GC CXL SIL [ More info ] Unavailable
		1600-8M0228012 - 1600-8M0228012 - GC CXL SIL [ More info ] Unavailable Replaced by -8M0235809
		1600-8M0235809 - GC CXL SIL [ More info ] Unavailable
#-	8M0142302	GC CXXL SIL (1 required per assembly)
		16008M0142302 - GC CXXL SIL [ More info ] Unavailable
		1600-8M0228014 - 1600-8M0228014 - GC CXXL SIL [ More info ] Unavailable Replaced by -8M0235813
		1600-8M0235813 - GC CXXL SIL [ More info ] Unavailable
#-	8M0142980	WATER PUMP KIT (1 required per assembly)
		98-8M0142980 - 98-8M0142980 - WATER PUMP KIT [ More info ] Unavailable Replaced by -8M0205803
		47-8M0205803 - A V6/V8 WTR PUMP KT [ More info ] $69.49 $68.41 In Stock
#-	8M0142979	GEARCASE SEAL KIT (1 required per assembly)
		98-8M0142979 - GEARCASE SEAL KIT [ More info ] Unavailable
#1	8M0142886	GEAR HOUSING ASSEMBLY BASIC, BLACK (4.8) (1 required per assembly)
		16008M0142886 - GC BASIC BLACK [ More info ] Unavailable
#1	8M0145768	GEAR HOUSING ASSEMBLY BASIC, SILVER (4.8) (1 required per assembly)
		16008M0145768 - GC BASIC SILVR [ More info ] Unavailable
		1600-8M0228041 - GC BASIC SILVR [ More info ] Unavailable
#2	8M0137814	ANODE ANTIVENT PLATE (ALUMINUM) (1 required per assembly)
		978M0137814 - Anode - Priced Individually [ More info ] $26.49 Available to Order: Shipping delay up to 10 days.
#2	8M0200103	ANODE ANTIVENT PLATE (MAGNESIUM) Not included in gear housing assembly (1 required per assembly)
		97-8M0200103 - ANODE(MAG) @2 [ More info ] Unavailable
#3	8M0142850	SCREW (M10 X 25) (2 required per assembly)
		108M0142850 - Screw [ More info ] $6.69 1 In Stock.
#4	8M0142878	PLUG SCREW (2 required per assembly)
		198M0142878 - Plug Screw [ More info ] $0.60 Available to Order: Shipping delay up to 10 days.
#5	8M0146697	GEAR SET FORWARD PINION 13/24 (1.85:1) (1 required per assembly)
		438M0146697 - Gear Set 13/24 [ More info ] $637.99 Available to Order: Shipping delay up to 10 days.
#6	8M0071654	NUT (.625-18 HX) Pinion (1 required per assembly)
		118M0071654 - NUT-.625-18 HX [ More info ] $4.49 Available to Order: Shipping delay up to 10 days.
#7	92721	WASHER (1 required per assembly)
		12-92721 - Washer, Pinion Gear [ More info ] $1.50 $0.85 10+ In Stock.
		18-2359 - Nut Kit [ More info ] $5.19 $3.51 Available to Order: Shipping delay up to 10 days.
#8	42647A1	BEARING ASSEMBLY ROLLER (1 required per assembly)
		31-42647A 1 - Roller Bearing - Drive Shaft [ More info ] $65.99 Available to Order: Shipping delay up to 10 days.
		18-1117 - Bearing, 387817, 31-42647A1 [ More info ] $56.09 1 In Stock.
		31-02762 - Bearing, 31-42647A1, 387817 [ More info ] $47.99 $42.20 Available to Order: Shipping delay up to 10 days.
#9	8M0168203	DRIVESHAFT KIT LONG (1 required per assembly) — Replaces: 8M0146062
		45-8M0168203 - DRIVESHAFT L KIT [ More info ] Unavailable
#9	8M0168206	DRIVESHAFT KIT X-LONG (1 required per assembly) — Replaces: 8M0146063
		45-8M0168206 - DRIVESHAFT XL KIT [ More info ] Unavailable
#9	8M0168209	DRIVESHAFT KIT XX-LONG (1 required per assembly) — Replaces: 8M0146064
		45-8M0168209 - DRIVESHAFT XXL KT [ More info ] Unavailable
#10	8M0063268	SHIM SET (1 required per assembly)
		15-8M0063268 - Shim Set [ More info ] $31.57 4 In Stock.
#11	8M0146553	BEARING ASSEMBLY CUP/CONE (1 required per assembly)
		318M0146553 - Bearing ASSY [ More info ] $27.23 1 In Stock.
#12	8M0063267	SHIM SET (1 required per assembly)
		15-8M0063267 - Shim Set [ More info ] $28.41 10+ In Stock.
#13	8M0146566	BEARING ASSEMBLY CUP/CONE (1 required per assembly)
		318M0146566 - Upper Driveshaft Bearing [ More info ] $74.99 $74.83 Available to Order: Shipping delay up to 10 days.
		31-02194 - Bearing Kit 31-36387A 1 [ More info ] $52.49 $41.29 In Stock
#14	8245191	RETAINER (1 required per assembly)
		824519 1 - Retainer [ More info ] $6.99 1 In Stock.
		18-2346 - Retainer, 824519 1 [ More info ] $5.25 Available to Order: Shipping delay up to 10 days.
#15	8M0142854	O RING (2.175 X .103) (1 required per assembly)
		25-8M0142854 - O-Ring [ More info ] $1.10 5 In Stock.
#16	880719	RING RETAINING (1 required per assembly)
		53-880719 - Ring - Retaining [ More info ] $1.50 Available to Order: Shipping delay up to 10 days.
#17	8M0046297	OIL SEAL CARRIER ASSEMBLY (1 required per assembly)
		8M0046297 - Seal Carrier Assembly [ More info ] $58.99 Available to Order: Shipping delay up to 10 days.
#18	8M0146938	GASKET WATER PUMP BASE (1 required per assembly)
		278M0146938 - Gasket [ More info ] $6.69 Available to Order: Shipping delay up to 10 days.
#19	8M0174560	COVER HOUSING GEARCASE (1 required per assembly) — Replaces: 8M0142869
		8M0174560 - COVER Housing GC [ More info ] $30.49 Available to Order: Shipping delay up to 10 days.
#20	8M0142659	SEAL (2 required per assembly)
		258M0142659 - Seal FORMED [ More info ] $1.50 Available to Order: Shipping delay up to 10 days.
#21	8M0142616	GASKET FACE PLATE TO GEARCASE (1 required per assembly) — Replaces: 8M0112903
		27-8M0142616 - Gasket LOWER [ More info ] $9.59 Available to Order: Shipping delay up to 10 days.
#22	8172771	GASKET (1 required per assembly)
		27-817277 1 - Gasket -Sold each [ More info ] $5.69 9 In Stock.
		18-2566-9 - Gasket 27-817277 2-Pack [ More info ] $8.67 10+ In Stock.
#23	8M0204709	FACEPLATE-W/P (1 required per assembly) — Replaces: 8172761
		8M0204709 - Water Pump Faceplate, Outboard [ More info ] $14.59 Available to Order: Shipping delay up to 10 days.
#24	8M0204723	KEY @2 (1 required per assembly) — Replaces: 8M0032833
		288M0204723 - KEY Note: Priced Individually [ More info ] $4.39 2 In Stock.
#25	43026T2	IMPELLER (1 required per assembly)
		47-43026T 2 - Water Pump Impeller [ More info ] $36.49 6 In Stock.
		18-3056 - Impeller 47-43026-2 [ More info ] $26.99 $26.12 10+ In Stock.
		47-43026Q02 - Water Pump Impeller [ More info ] $36.49 Available to Order: Shipping delay up to 10 days.
#26	817275A1	HOUSING KIT WATER PUMP (1 required per assembly)
		817275A 1 - Housing for Water Pump [ More info ] $102.99 $101.34 In Stock
		18-3570 - Water Pump Kit 817275A1, A2 [ More info ] $90.99 $85.66 10+ In Stock.
#27	8M0142435	COUPLING WATER PUMP (1 required per assembly)
		8M0142435 - Water Pump CPLING [ More info ] $25.89 Available to Order: Shipping delay up to 10 days.
#28	8M0204645	O RING (1 required per assembly) — Replaces: 21836
		25-8M0204645 - O RING [ More info ] $2.39 5 In Stock.
#29	8M0142851	VRING FACE SEAL (1 required per assembly)
		268M0142851 - FACE SEAL VRING [ More info ] $0.30 Available to Order: Shipping delay up to 10 days.
#30	8M0142712	O-RING (0.796 X 0.139) (1 required per assembly)
		258M0142712 - O-Ring [ More info ] $0.80 Available to Order: Shipping delay up to 10 days.
#31	8M0204706	SCREW @2 (4 required per assembly) — Replaces: 1993720
		108M0204706 - SCREW Note: Must be ordered in multiples of 2 [ More info ] $1.20 3 In Stock.
#32	8M0142866	RING RETAINING (1 required per assembly)
		538M0142866 - RING RETAINING [ More info ] $0.50 Available to Order: Shipping delay up to 10 days.
#33	8M0142859	BUSHING SHIFT SHAFT Design I (1 required per assembly)
		238M0142859 - Bushing SHIFT SHA [ More info ] $36.49 Available to Order: Shipping delay up to 10 days.
#33	8M0164967	BUSHING SHIFT SHAFT Design II (1 required per assembly)
		23-8M0164967 - BUSHING SHFT SHFT [ More info ] Unavailable
#34	8M0142860	O-RING (1 required per assembly)
		258M0142860 - O-Ring [ More info ] $0.50 Available to Order: Shipping delay up to 10 days.
#35	8M0046563	RETAINING RING (1 required per assembly)
		53-8M0046563 - Retainer Ring [ More info ] $4.29 Available to Order: Shipping delay up to 10 days.
#36	8M0204708	SEAL (1 required per assembly) — Replaces: 8164641
		26-8M0204708 - Shift Shaft Oil Seal-O/B [ More info ] $16.99 Available to Order: Shipping delay up to 10 days.
		26-8M0246145 - SHIFT SHAFT OIL SEAL O/B [ More info ] $16.99 10 In Stock.
#37	77674	WASHER (1 required per assembly)
		12-77674 - Washer, Rubber [ More info ] $1.80 4 In Stock.
		18-2316-9 - Washer, 12-77674, 5PK [ More info ] $4.69 $4.68 Available to Order: Shipping delay up to 10 days.
#38	8M0084244	PIN DOWEL (2 required per assembly)
		178M0084244 - Pin - Dowel [ More info ] $3.29 Available to Order: Shipping delay up to 10 days.
#39	8M0164968	SHIFT SHAFT LONG INCLUDES BUSHING DESIGN II Design II (1 required per assembly) — Replaces: 8M0142858
		8M0164968 - SHAFT SHIFT LONG [ More info ] Unavailable
#39	8M0164969	SHIFT SHAFT X-LONG INCLUDES BUSHING DESIGN II Design II (1 required per assembly) — Replaces: 8M0142865
		8M0164969 - SHAFT SHIFT XL [ More info ] Unavailable
#39	8M0164970	SHIFT SHAFT XX-LONG INCLUDES BUSHING DESIGN II Design II (1 required per assembly) — Replaces: 8M0142885
		8M0164970 - SHAFT SHIFT XXL [ More info ] $89.49 Available to Order: Shipping delay up to 10 days.
