Parts for 200 HP 4.6L V8 Pro XS 4-Stroke Mercury Outboard Motor Gear Housing, Driveshaft - 5.44 Torpedo

Revise Search: Outboard > 4-Stroke Mercury Outboard > 200 HP 4.6L V8 Pro XS > 2B529482 & Up - USA > Gear Housing, Driveshaft - 5.44 Torpedo

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Gear Housing, Driveshaft - 5.44 Torpedo

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	8M0142309	GC XL SILV (1 required per assembly)
		16008M0142309 - GC XL SILV [ More info ] Unavailable
		1600-8M0228016 - 1600-8M0228016 - GC XL SILV [ More info ] Unavailable Replaced by -8M0235820
		1600-8M0235820 - GC XL SILV [ More info ] Unavailable
#-	8M0142311	GC CXL SILV (1 required per assembly)
		16008M0142311 - GC CXL SILV [ More info ] Unavailable
		1600-8M0228017 - 1600-8M0228017 - GC CXL SILV [ More info ] Unavailable Replaced by -8M0235822
		1600-8M0235822 - GC CXL SILV [ More info ] Unavailable
#-	8M0142980	WATER PUMP KIT (1 required per assembly)
		98-8M0142980 - 98-8M0142980 - WATER PUMP KIT [ More info ] Unavailable Replaced by -8M0205803
		47-8M0205803 - A V6/V8 WTR PUMP KT [ More info ] $69.49 $68.41 In Stock
#-	8M0142979	GEARCASE SEAL KIT (1 required per assembly)
		98-8M0142979 - GEARCASE SEAL KIT [ More info ] Unavailable
#1	8M0142888	GEAR HOUSING ASSEMBLY BASIC, SILVER (1 required per assembly)
		16008M0142888 - GC BASIC SILVER [ More info ] Unavailable
		1600-8M0228040 - GC BASIC SILVER [ More info ] Unavailable
#2	8M0137814	ANODE ANTIVENT PLATE (ALUMINUM) (1 required per assembly)
		978M0137814 - Anode - Priced Individually [ More info ] $26.49 Available to Order: Shipping delay up to 10 days.
#2	8M0200103	ANODE ANTIVENT PLATE (MAGNESIUM) Not Included in Gear Housing Assembly (1 required per assembly)
		97-8M0200103 - ANODE(MAG) @2 [ More info ] Unavailable
#3	8M0142850	SCREW (M10 X 25) (2 required per assembly)
		108M0142850 - Screw [ More info ] $6.69 1 In Stock.
#4	8M0142878	PLUG SCREW (2 required per assembly)
		198M0142878 - Plug Screw [ More info ] $0.60 Available to Order: Shipping delay up to 10 days.
#5	8M0146648	GEAR SET FORWARD GEAR PINION 12/21 (1.75:1) (1 required per assembly)
		438M0146648 - Gear Set 12/21 [ More info ] $781.49 Available to Order: Shipping delay up to 10 days.
#6	8M0046636	NUT (1 required per assembly)
		11-8M0046636 - Nut [ More info ] $29.49 Available to Order: Shipping delay up to 10 days.
#7	8M0062703	WASHER (2 required per assembly)
		128M0062703 - Washer [ More info ] $1.00 Available to Order: Shipping delay up to 10 days.
#8	8M0045676	BEARING ROLLER (1 required per assembly)
		31-8M0045676 - Roller Bearing [ More info ] $69.99 Available to Order: Shipping delay up to 10 days.
#9	8M0168204	DRIVESHAFT KIT LONG (1 required per assembly) — Replaces: 8M0146065
		45-8M0168204 - DRIVESHAFT L KIT [ More info ] Unavailable
#9	8M0168208	DRIVESHAFT KIT X-LONG (1 required per assembly) — Replaces: 8M0146066
		45-8M0168208 - DRIVESHAFT XL KIT [ More info ] Unavailable
#10	8M0063268	SHIM SET (1 required per assembly)
		15-8M0063268 - Shim Set [ More info ] $31.57 4 In Stock.
#11	8M0146553	BEARING ASSEMBLY CUP/CONE (1 required per assembly)
		318M0146553 - Bearing ASSY [ More info ] $27.23 1 In Stock.
#12	8M0063267	SHIM SET (1 required per assembly)
		15-8M0063267 - Shim Set [ More info ] $28.41 10+ In Stock.
#13	8M0146566	BEARING ASSEMBLY CUP/CONE (1 required per assembly)
		318M0146566 - Bearing CUP Cone [ More info ] $74.99 $74.83 Available to Order: Shipping delay up to 10 days.
		31-02194 - Bearing Kit 31-36387A 1 [ More info ] $52.49 $41.29 In Stock
#14	8245191	RETAINER (1 required per assembly)
		824519 1 - Retainer [ More info ] $6.99 1 In Stock.
		18-2346 - Retainer, 824519 1 [ More info ] $5.25 Available to Order: Shipping delay up to 10 days.
#15	8M0142854	O RING (2.175 X .103) (1 required per assembly)
		25-8M0142854 - O-Ring [ More info ] $1.10 1 In Stock.
#16	880719	RING RETAINING (1 required per assembly)
		53-880719 - Ring - Retaining [ More info ] $1.50 Available to Order: Shipping delay up to 10 days.
#17	8M0046297	OIL SEAL CARRIER ASSEMBLY (1 required per assembly)
		8M0046297 - Seal Carrier Assembly [ More info ] $58.99 Available to Order: Shipping delay up to 10 days.
#18	8M0146938	GASKET WATER PUMP BASE (1 required per assembly)
		278M0146938 - Gasket [ More info ] $6.69 Available to Order: Shipping delay up to 10 days.
#19	8M0174560	COVER HOUSING GEARCASE (1 required per assembly) — Replaces: 8M0142869
		8M0174560 - COVER Housing GC [ More info ] $30.49 Available to Order: Shipping delay up to 10 days.
#20	8M0142659	SEAL (2 required per assembly)
		258M0142659 - Seal FORMED [ More info ] $1.50 Available to Order: Shipping delay up to 10 days.
#21	8M0142616	GASKET FACE PLATE TO GEARCASE (1 required per assembly) — Replaces: 8M0112903
		27-8M0142616 - Gasket LOWER [ More info ] $9.59 Available to Order: Shipping delay up to 10 days.
#22	8172771	GASKET (1 required per assembly)
		27-817277 1 - Gasket -Sold each [ More info ] $5.69 10+ In Stock.
		18-2566-9 - Gasket 27-817277 2-Pack [ More info ] $8.67 10+ In Stock.
#23	8M0204709	FACEPLATE-W/P (1 required per assembly) — Replaces: 8172761
		8M0204709 - Water Pump Faceplate, Outboard [ More info ] $14.59 Available to Order: Shipping delay up to 10 days.
#24	8M0204723	KEY @2 (1 required per assembly) — Replaces: 8M0032833
		288M0204723 - KEY Note: Priced Individually [ More info ] $4.39 2 In Stock.
#25	43026T2	IMPELLER (1 required per assembly)
		47-43026T 2 - Water Pump Impeller [ More info ] $36.49 6 In Stock.
		18-3056 - Impeller 47-43026-2 [ More info ] $26.99 $26.12 10+ In Stock.
		47-43026Q02 - Water Pump Impeller [ More info ] $36.49 Available to Order: Shipping delay up to 10 days.
#26	817275A1	HOUSING KIT WATER PUMP (1 required per assembly)
		817275A 1 - Housing for Water Pump [ More info ] $102.99 $101.34 In Stock
		18-3570 - Water Pump Kit 817275A1, A2 [ More info ] $90.99 $85.66 10+ In Stock.
#27	8M0142435	COUPLING WATER PUMP (1 required per assembly)
		8M0142435 - Water Pump CPLING [ More info ] $25.89 Available to Order: Shipping delay up to 10 days.
#28	8M0204645	O RING (1 required per assembly) — Replaces: 21836
		25-8M0204645 - O RING [ More info ] $2.39 5 In Stock.
#29	8M0142851	VRING FACE SEAL (1 required per assembly)
		268M0142851 - FACE SEAL VRING [ More info ] $0.30 Available to Order: Shipping delay up to 10 days.
#30	8M0142712	O-RING (0.796 X 0.139) (1 required per assembly)
		258M0142712 - O-Ring [ More info ] $0.80 Available to Order: Shipping delay up to 10 days.
#31	8M0204706	SCREW @2 (4 required per assembly) — Replaces: 1993720
		108M0204706 - SCREW Note: Must be ordered in multiples of 2 [ More info ] $1.20 3 In Stock.
#32	8M0142866	RING RETAINING (1 required per assembly)
		538M0142866 - RING RETAINING [ More info ] $0.50 Available to Order: Shipping delay up to 10 days.
#33	8M0142859	BUSHING SHIFT SHAFT Design I (1 required per assembly)
		238M0142859 - Bushing SHIFT SHA [ More info ] $36.49 Available to Order: Shipping delay up to 10 days.
#33	8M0164967	BUSHING SHIFT SHAFT Design II (1 required per assembly)
		23-8M0164967 - BUSHING SHFT SHFT [ More info ] Unavailable
#34	8M0142860	O-RING (1 required per assembly)
		258M0142860 - O-Ring [ More info ] $0.50 Available to Order: Shipping delay up to 10 days.
#35	8M0046563	RETAINING RING (1 required per assembly)
		53-8M0046563 - Retainer Ring [ More info ] $4.29 Available to Order: Shipping delay up to 10 days.
#36	8M0204708	SEAL (1 required per assembly) — Replaces: 8164641
		26-8M0204708 - Shift Shaft Oil Seal-O/B [ More info ] $16.99 Available to Order: Shipping delay up to 10 days.
		26-8M0246145 - SHIFT SHAFT OIL SEAL O/B [ More info ] $16.99 10 In Stock.
#37	77674	WASHER (1 required per assembly)
		12-77674 - Washer, Rubber [ More info ] $1.80 4 In Stock.
		18-2316-9 - Washer, 12-77674, 5PK [ More info ] $4.69 $4.68 Available to Order: Shipping delay up to 10 days.
#38	8M0084244	PIN DOWEL (2 required per assembly)
		178M0084244 - Pin - Dowel [ More info ] $3.29 Available to Order: Shipping delay up to 10 days.
#39	8M0164968	SHIFT SHAFT LONG INCLUDES BUSHING DESIGN II Design II (1 required per assembly) — Replaces: 8M0142858
		8M0164968 - SHAFT SHIFT LONG [ More info ] Unavailable
#39	8M0164969	SHIFT SHAFT X-LONG INCLUDES BUSHING DESIGN II Design II (1 required per assembly) — Replaces: 8M0142865
		8M0164969 - SHAFT SHIFT XL [ More info ] Unavailable
#40	8M0142587	PLUG (1 required per assembly)
		198M0142587 - PLUG [ More info ] $16.29 Available to Order: Shipping delay up to 10 days.
