Parts for 200 HP 4.6L V8 Pro XS 4-Stroke Mercury Outboard Motor Cylinder Block
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 8M0142280 | LONG BLOCK V8 PRO 200/225 HP (See Bulletin 2021-24) (1 required per assembly) |
  |
|
618M0142280 - LONG BLOCK V8 PRO [ More info ] Unavailable |
| #- | 8M0142279 | LONG BLOCK V8 250/300 HP (See Bulletin 2021-24) (1 required per assembly) |
  |
|
618M0142279 - LONG BLOCK V8 [ More info ] Unavailable |
| #- | 8M0149551 | PWRHD GASKET SET (1 required per assembly) |
  |
|
8M0149551 - Powerhead Gasket Set [ More info ]
|
| #1 | 8M0142344 | CYLINDER BLOCK (1 required per assembly) |
  |
8008M0142344 - Cylinder Block [ More info ] Unavailable |
|
  |
|
800-8M0208898 - CYLINDER BLOCK [ More info ] Unavailable |
| #2 | NSS | NOT SOLD SEPARATE Bedplate-Crankcase Cover (1 required per assembly) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #3 | 8M0142349 | COVER (1 required per assembly) |
  |
|
10008M0142349 - Cover CYLDR BLK [ More info ]
|
| #4 | 8M0080651 | SCREW (M6 X 20) (5 required per assembly) |
  |
|
108M0080651 - Screw [ More info ]
|
| #5 | 8M0142352 | PLUG 18 MM (1 required per assembly) |
  |
|
198M0142352 - PLUG 18 MM [ More info ]
|
| #6 | 8M0142353 | O-RING (0.614 X 0.070) (1 required per assembly) |
  |
|
258M0142353 - ORING [ More info ]
|
| #7 | 893540 | PIN DOWEL, 8X12 LONG (6 required per assembly) |
  |
|
17-893540 - Dowel Pin [ More info ]
|
| #8 | 8M0087447 | PLUG (10MM) (2 required per assembly) |
  |
|
198M0087447 - Plug (10MM) [ More info ]
|
| #9 | 8M0142348 | GASKET COVER PLATE (1 required per assembly) |
  |
|
278M0142348 - Gasket Cover PLT [ More info ]
|
| #10 | 8M0103809 | SCREW (M6 X 40 MM) STAINLESS STEEL (10 required per assembly) |
  |
|
108M0103809 - Screw - Priced Individually [ More info ]
|
| #11 | 8M0168893 | SCREW M10 X 96 (10 required per assembly) — Replaces: 8M0142347 |
  |
|
10-8M0168893 - SCREW [ More info ] Unavailable |
| #12 | 8M0142346 | SCREW (M11 X 107 MM) 12 POINT HEX HEAD (10 required per assembly) |
  |
|
108M0142346 - Screw [ More info ]
|
| #13 | 8M0087454 | PLUG (30 MM) (1 required per assembly) |
  |
|
198M0087454 - PLUG - 30 MM [ More info ]
|
| #14 | 8M0142409 | PLUG BALANCER (1 required per assembly) |
  |
|
198M0142409 - BALANCER PLUG [ More info ]
|
| #15 | 8M0142421 | BALANCE SHAFT (1 required per assembly) |
  |
|
8M0142421 - BALANCE Shaft [ More info ]
|
| #16 | 8M0142429 | BEARING BALL (1 required per assembly) |
  |
|
308M0142429 - Bearing BALL [ More info ]
|
| #17 | 8M0142427 | PLATE RETAINER (1 required per assembly) |
  |
|
8M0142427 - Plate Retainer [ More info ]
|
| #18 | 8M0142428 | SCREW (M5 X 12) HEX FLG (2 required per assembly) |
  |
|
108M0142428 - Screw [ More info ]
|
| #19 | 8M0142426 | PIN DOWEL (1 required per assembly) |
  |
|
178M0142426 - PIN [ More info ]
|
| #20 | 8M0142423 | SCREW (M8 X 1.25) HEX FL SEMS (1 required per assembly) |
  |
|
108M0142423 - Screw M8 X 1.25 [ More info ]
|
| #21 | 8M0142422 | SPROCKET (1 required per assembly) |
  |
|
8M0142422 - Sprocket BALANCER [ More info ]
|
| #22 | 8M0142410 | BALANCER COVER (1 required per assembly) |
  |
|
10008M0142410 - BALANCER Cover [ More info ]
|
| #23 | 40011106 | SCREW (10 required per assembly) |
  |
|
10-40011106 - Screw [ More info ]
|
| #24 | 8M0103807 | SCREW @2 (2 required per assembly) |
  |
|
108M0103807 - Screw (M6 x 25 MM) Stainless Steel [ More info ]
|
| #25 | 8M0064752 | END CAP, CAM TENS (1 required per assembly) |
  |
|
11008M0064752 - End Cap, Cam TENS [ More info ]
|
| #26 | 898836 | O-RING BROWN (1 required per assembly) |
  |
|
25-898836 - O-ring, Brown, Tensioner Cap [ More info ]
|
  |
|
25-8M0237361 - O-RING [ More info ] Unavailable |
| #27 | 8M0142394 | TENSIONER (1 required per assembly) |
  |
8M0142394 - TENSIONER [ More info ] Unavailable |
|
  |
|
8M0220226 - 8M0220226 - TENSIONER ASSY [ More info ] Unavailable Replaced by -8M0231253 |
  |
|
8M0231253 - TENSIONER ASSY [ More info ] Unavailable |
| #28 | 8M0142399 | CHAIN CAM DRIVE (1 required per assembly) |
  |
|
108M0142399 - CHAIN CAM DRIVE [ More info ] Unavailable |
| #29 | 8M0142395 | BOLT M12 (2 required per assembly) |
  |
|
108M0142395 - Bolt M12 [ More info ]
|
| #30 | 8M0142390 | SPROKET CAMSHAFT (2 required per assembly) |
  |
|
8M0142390 - SPROKET Camshaft [ More info ]
|
| #31 | 8M0142400 | GUIDE SHORT SPAN (2 required per assembly) |
  |
|
108M0142400 - Guide SHORT SPAN [ More info ] Unavailable |
| #32 | 8M0086569 | SCREW (2 required per assembly) |
  |
|
108M0086569 - Screw [ More info ]
|
| #33 | 8M0142393 | GUIDE CAM DRIVE (1 required per assembly) |
  |
|
8M0142393 - Guide CAM DRIVE [ More info ]
|
| #34 | 8M0142392 | GUIDE MOVEABLE (1 required per assembly) |
  |
|
8M0142392 - Guide MOVEABLE [ More info ]
|
| #35 | 8M0103821 | SCREW (4 required per assembly) |
  |
|
108M0103821 - Screw [ More info ]
|
| #36 | 8M0142459 | LIFTING EYE PORT (1 required per assembly) |
  |
|
8M0142459 - LIFTING EYE PORT [ More info ]
|
| #37 | 8M0142448 | LIFTING EYE STBD (1 required per assembly) |
  |
|
8M0142448 - LIFTING EYE STBD [ More info ]
|
