Parts for 20 HP EFI 2 Cyl 4-Stroke Mercury Outboard Motor Clamp Brackets / Swivel Bracket Manual Tilt

Revise Search: Outboard > 4-Stroke Mercury Outboard > 20 HP EFI 2 Cyl > 0R833820 - 1R162636 > Clamp Brackets / Swivel Bracket Manual Tilt

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Clamp Brackets / Swivel Bracket Manual Tilt

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	8M0140877	CO PILOT KIT (1 required per assembly)
		988M0140877 - CO PILOT KIT [ More info ] $63.49 Available to Order: Shipping delay up to 10 days.
#-	8M0134438	POWERHEAD GASKET (1 required per assembly)
		278M0134438 - Powerhead Gasket [ More info ] $107.49 Available to Order: Shipping delay up to 10 days.
#1	8M0134662	SWIVEL BRACKET (1 required per assembly)
		14008M0134662 - Swivel Bracket [ More info ] $169.49 Available to Order: Shipping delay up to 10 days.
#1	8M0134663	SWIVEL BRACKET (1 required per assembly)
		14008M0134663 - Swivel Bracket [ More info ] $202.99 Available to Order: Shipping delay up to 10 days.
#2	8M0137356	PIN (2 required per assembly)
		178M0137356 - PIN [ More info ] $8.79 Available to Order: Shipping delay up to 10 days.
#3	824969	FITTING (3 required per assembly)
		22-824969 - Fitting [ More info ] $8.99 3 In Stock.
#4	898101091	WIRE-GROUND (1 required per assembly)
		84-898101091 - Wire - Ground [ More info ] $14.19 Available to Order: Shipping delay up to 10 days.
#5	8M0149915	TILT STOPPER (1 required per assembly) — Replaces: 8M0135835
		8M0149915 - TILT STOPPER [ More info ] Unavailable
#6	898103104	PIN SPRING (1 required per assembly)
		17-898103104 - Pin, Spring [ More info ] $2.49 Available to Order: Shipping delay up to 10 days.
#7	163364	BUSHING (1 required per assembly)
		23-16336 4 - Bushing [ More info ] $3.59 Available to Order: Shipping delay up to 10 days.
#8	853774	STOP (1 required per assembly)
		853774 - Stop [ More info ] $10.39 Available to Order: Shipping delay up to 10 days.
#9	953832	SPRING (1 required per assembly)
		24-95383 2 - Spring [ More info ] $5.69 Available to Order: Shipping delay up to 10 days.
#10	8M0157137	SET PLATE (1 required per assembly) — Replaces: 8M0140496
		8M0157137 - SET PLATE [ More info ] Unavailable
#11	8M0106739	BOLT (2 required per assembly)
		108M0106739 - BOLT [ More info ] $4.60 Available to Order: Shipping delay up to 10 days.
#12	8M0134504	REVERSE LOCK (1 required per assembly)
		8M0134504 - REVERSE LOCK [ More info ] $33.99 Available to Order: Shipping delay up to 10 days.
#13	8M0135840	SPRING REV LOCK (2 required per assembly)
		248M0135840 - SPRING REV LOCK [ More info ] $3.79 Available to Order: Shipping delay up to 10 days.
#14	8M0135839	LINK REV LOCK (1 required per assembly)
		8M0135839 - LINK REV LOCK [ More info ] $11.89 Available to Order: Shipping delay up to 10 days.
#15	8037841	ROD-REV. LOCL (1 required per assembly)
		17-803784 1 - ROD-REV. LOCL [ More info ] $11.29 Available to Order: Shipping delay up to 10 days.
#16	8150261	PIN-COTTER (2 required per assembly)
		18-815026 1 - Cotter Pin [ More info ] $2.99 2 In Stock.
#17	8037461	SPRING (1 required per assembly)
		24-803746 1 - Spring [ More info ] $4.59 Available to Order: Shipping delay up to 10 days.
#18	8M0135837	ARM REVERSE LOCK (1 required per assembly)
		8M0135837 - ARM REVERSE LOCK [ More info ] $23.89 Available to Order: Shipping delay up to 10 days.
#19	8M0135838	SHAFT REVERSE LOC (1 required per assembly)
		8M0135838 - Shaft REVERSE LOC [ More info ] $6.99 Available to Order: Shipping delay up to 10 days.
#20	160572	E RING (2 required per assembly)
		53-16057 2 - E Ring [ More info ] $5.49 1 In Stock.
#21	8M0163137	LEVER REV LOCK (1 required per assembly) — Replaces: 8M0135836
		8M0163137 - 8M0163137 - LEVER REV LOCK [ More info ] Unavailable Replaced by -8M0242569
		8M0242569 - LEVER REV LOCK [ More info ] Unavailable
#22	898103106	GRIP (1 required per assembly)
		898103106 - Grip [ More info ] $9.79 Available to Order: Shipping delay up to 10 days.
#23	8M0051399	STOPPER (1 required per assembly)
		8M0051399 - Stopper [ More info ] $6.69 Available to Order: Shipping delay up to 10 days.
		17-8M0245322 - STOPPER [ More info ] Unavailable
#24	803790001	BOLT-SHOULDER (1 required per assembly)
		10-803790001 - Bolt -Shoulder [ More info ] $20.39 Available to Order: Shipping delay up to 10 days.
#25	16192	WASHER (1 required per assembly)
		12-16192 - Washer [ More info ] $3.59 3 In Stock.
#26	898103107	BUSHING (1 required per assembly)
		23-898103107 - Bushing [ More info ] $6.89 Available to Order: Shipping delay up to 10 days.
#27	953925	WASHER (1 required per assembly)
		12-95392 5 - Washer [ More info ] $6.89 Available to Order: Shipping delay up to 10 days.
#28	953921	WASHER (1 required per assembly)
		12-95392 1 - Washer [ More info ] $5.59 Available to Order: Shipping delay up to 10 days.
#29	8M0137358	BOLT (1 required per assembly)
		108M0137358 - Bolt [ More info ] $8.89 Available to Order: Shipping delay up to 10 days.
#30	168231	O-RING (1 required per assembly)
		25-16823 1 - O-Ring [ More info ] $3.59 Available to Order: Shipping delay up to 10 days.
#31	8M0145395	DISC (2 required per assembly) — Replaces: 895173
		8M0145395 - DISC - Priced Individually [ More info ] $19.79 Available to Order: Shipping delay up to 10 days.
#32	8M0137359	WASHER SPACER (1 required per assembly)
		128M0137359 - Washer [ More info ] Unavailable
		12-8M0145397 - WASHER [ More info ] Unavailable
#33	8M0135834	PLATE (1 required per assembly)
		8M0135834 - Plate [ More info ] $9.89 Available to Order: Shipping delay up to 10 days.
#34	8230427	BOLT ASSEMBLY (M6 X 12) (2 required per assembly)
		10-823042 7 - Bolt [ More info ] $4.09 $2.30 10+ In Stock.
#35	8M0135833	HANDLE (1 required per assembly)
		8M0135833 - Handle [ More info ] $15.99 Available to Order: Shipping delay up to 10 days.
#36	895146001	WASHER (1 required per assembly)
		12-895146001 - Washer - Priced Individually [ More info ] $4.19 2 In Stock.
#37	8M0137357	WASHER (1 required per assembly)
		12-8M0137357 - WASHER [ More info ] Unavailable
#38	95374001	NUT NYLON (1 required per assembly)
		11-95374001 - Nut, Nylon [ More info ] $13.89 Available to Order: Shipping delay up to 10 days.
#39	8M0134502	CLAMP BRACKET (1 required per assembly)
		14008M0134502 - Clamp Bracket [ More info ] $97.49 Available to Order: Shipping delay up to 10 days.
#40	8M0134503	CLAMP BRACKET (1 required per assembly)
		14008M0134503 - Clamp Bracket [ More info ] $100.49 Available to Order: Shipping delay up to 10 days.
#41	823701004	DECAL CO-PILOT (1 required per assembly)
		37-823701004 - Decal Co-Pilot [ More info ] $2.69 Available to Order: Shipping delay up to 10 days.
#42	823913Q	ANODE(ALUM) @2 (2 required per assembly)
		97-823913Q - Anode, Aluminum [ More info ] $20.49 Available to Order: Shipping delay up to 10 days.
#43	167051	BOLT (2 required per assembly)
		10-16705 1 - Bolt [ More info ] $6.09 Available to Order: Shipping delay up to 10 days.
#44	8M0135830	DISTANCE PIECE (1 required per assembly)
		8M0135830 - DISTANCE PIECE [ More info ] $18.99 Available to Order: Shipping delay up to 10 days.
#45	16826	WASHER (4 required per assembly)
		12-16826 - Washer, Stainless Steel [ More info ] $3.29 Available to Order: Shipping delay up to 10 days.
#46	400212	NUT (2 required per assembly)
		11-40021 2 - Nut [ More info ] $2.89 2 In Stock.
#47	898101191	TILT TUBE (1 required per assembly)
		898101191 - Tilt Tube [ More info ] $103.49 Available to Order: Shipping delay up to 10 days.
#48	853722029	NUT (1 required per assembly)
		11-853722029 - Nut, Nylon [ More info ] $23.09 Available to Order: Shipping delay up to 10 days.
#49	8537435	BUSHING (2 required per assembly)
		23-853743 5 - Bushing [ More info ] $13.59 Available to Order: Shipping delay up to 10 days.
#50	85372214	CAP NUT (2 required per assembly)
		11-853722 14 - Cap Nut [ More info ] $5.59 Available to Order: Shipping delay up to 10 days.
#51	8M0135832	THRUST ROD ASSY (1 required per assembly)
		8M0135832 - Thrust Rod [ More info ] $37.49 Available to Order: Shipping delay up to 10 days.
#52	815093003	SPRING (1 required per assembly)
		24-815093003 - Spring [ More info ] $4.69 Available to Order: Shipping delay up to 10 days.
#53	815082002	HANDLE-CARRYING (1 required per assembly)
		815082002 - Carrying Handle A [ More info ] $34.49 Available to Order: Shipping delay up to 10 days.
#54	8M0161541	CLAMP SCREW KIT (2 required per assembly) — Replaces: 8M0060117, 8M0156644
		8M0161541 - Clamp Screw Kit, One side only as shown [ More info ] Unavailable
		108M0176078 - Clamp Screw Kit [ More info ] $87.49 Available to Order: Shipping delay up to 10 days.
#55	8M0137367	DECAL SECURE (1 required per assembly)
		378M0137367 - Decal SECURE [ More info ] Unavailable
		37-8M0191657 - DECAL SECURE ENGN [ More info ] Unavailable
#56	8M0094877	SCREW (2 required per assembly)
		108M0094877 - Screw [ More info ] $3.69 Available to Order: Shipping delay up to 10 days.
#57	16192	WASHER (4 required per assembly)
#58	95374	NUT (2 required per assembly)
		11-95374 - Nut, Nylon, Clamp Bracket Screw [ More info ] $9.59 Available to Order: Shipping delay up to 10 days.
