Parts for 2.5 HP Carb 4-Stroke Mercury Outboard Motor Carburetor Non-epa Models-Serial # 0R448033 & Up

Revise Search: Outboard > 4-Stroke Mercury Outboard > 2.5 HP Carb > 0R131842 & Up > Carburetor Non-epa Models-Serial # 0R448033 & Up

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Carburetor Non-epa Models-Serial # 0R448033 & Up

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	8M0090764	REPAIR KIT-CARB (1 required per assembly) — Replaces: 855546A05
		8M0090764 - Carburetor Repair Kit [ More info ] $116.99 Available to Order: Shipping delay up to 10 days.
#-	898103A67	GASKET SET-PH (1 required per assembly)
		27-898103A67 - Powerhead Gasket Set [ More info ] $124.49 Available to Order: Shipping delay up to 10 days.
#1	853720T23	CARBURETOR 2 Horsepower (1 required per assembly)
		3303-853720T23 - Carburetor [ More info ] $362.99 Available to Order: Shipping delay up to 10 days.
#1	853720T24	CARBURETOR 2.5 Horsepower (1 required per assembly)
		3303-853720T24 - Carburetor [ More info ] $410.99 Available to Order: Shipping delay up to 10 days.
#1	8M0167269	CARBURETOR 3.5 Horsepower [0R736591] & Up (1 required per assembly) — Replaces: 853720T25, 8M0121978
		13008M0167269 - Carburetor [ More info ] $370.99 Available to Order: Shipping delay up to 10 days.
#2	898101407	SCREW STOP (1 required per assembly)
		10-898101407 - Screw-Stop [ More info ] $14.59 Available to Order: Shipping delay up to 10 days.
#3	803554	SPRING (1 required per assembly)
		24-803554 - Spring, NLA [ More info ] $6.39 $5.12 10+ In Stock.
#4	898103244	JET SLOW AIR (#115) 2/3.5 Horsepower (1 required per assembly)
		898103244 - #115 Slow Air Jet [ More info ] $20.83 1 In Stock.
#4	NSS	NOT SOLD SEPARATE 2.5 Horsepower (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#4	8M0121980	JET SLOW AIR (#130) 3.5 Horsepower [0R736591] & Up (1 required per assembly)
		8M0121980 - JET-SLOW AIR #130 [ More info ] $15.49 Available to Order: Shipping delay up to 10 days.
#5	898101289	SET SCREW PILOT (1 required per assembly)
		10-898101289 - Screw Set -Pilot [ More info ] $20.89 Available to Order: Shipping delay up to 10 days.
#6	8M0060417	PLUG RUBBER (1 required per assembly)
		198M0060417 - Rubber Plug [ More info ] $13.39 Available to Order: Shipping delay up to 10 days.
#7	898103238	MAIN NOZZLE 2 Horsepower (1 required per assembly)
		898103238 - Main Nozzle [ More info ] $19.79 Available to Order: Shipping delay up to 10 days.
#7	898103239	MAIN NOZZLE 2.5 Horsepower (1 required per assembly)
		898103239 - Main Nozzle [ More info ] $26.09 Available to Order: Shipping delay up to 10 days.
#7	8126506	MAIN NOZZLE 3.5 Horsepower (1 required per assembly)
		812650 6 - Main Nozzle [ More info ] $27.89 Available to Order: Shipping delay up to 10 days.
#8	16250012	JET MAIN (#58) 2 Horsepower (1 required per assembly)
		16250012 - JET Main (#58) [ More info ] Unavailable
#8	162508	JET MAIN (#65) 2.5 Horsepower (1 required per assembly)
		16250 8 - Main Jet [ More info ] $20.99 Available to Order: Shipping delay up to 10 days.
#8	16250011	JET MAIN (#68) 3.5 Horsepower (1 required per assembly)
		16250011 - Main Jet [ More info ] $18.95 1 In Stock.
#9	162543	VALVE-FLOAT (1 required per assembly)
		16254 3 - Float Valve [ More info ] $28.99 Available to Order: Shipping delay up to 10 days.
#10	803525	CLIP STAINLESS STEEL (1 required per assembly)
		54-803525 - Clip [ More info ] $7.99 1 In Stock.
#11	898103245	FLOAT (1 required per assembly)
		898103245 - Float [ More info ] $56.99 Available to Order: Shipping delay up to 10 days.
#12	162562	PIN FLOAT - STAINLESS STEEL (1 required per assembly)
		17-16256 2 - Carburetor Float Pin [ More info ] $6.89 Available to Order: Shipping delay up to 10 days.
#13	898103240	FLOAT BOWL (1 required per assembly)
		898103240 - Float Bowl [ More info ] $37.99 Available to Order: Shipping delay up to 10 days.
#14	8035084	GASKET RUBBER (1 required per assembly)
		27-803508 4 - Gasket [ More info ] $16.99 4 In Stock.
#15	8035093	SCREW DRAIN (M5 X 6) (1 required per assembly)
		10-803509 3 - Drain Screw [ More info ] $11.79 Available to Order: Shipping delay up to 10 days.
#16	8035131	O-RING RUBBER (1 required per assembly)
		25-803513 1 - O-Ring [ More info ] $4.69 Available to Order: Shipping delay up to 10 days.
#17	16260	SCREW (M4 X 12) (2 required per assembly)
		10-16260 - Screw [ More info ] $4.99 Available to Order: Shipping delay up to 10 days.
#18	8M0057112	HOSE (2 required per assembly) — Replaces: 898101365, 8129404
		328M0057112 - Hose [ More info ] $22.49 Available to Order: Shipping delay up to 10 days.
#19	879147T98	MANIFOLD-INTAKE (1 required per assembly)
		879147T98 - Intake Manifold [ More info ] $158.99 Available to Order: Shipping delay up to 10 days.
#20	16830A1	SCREW KIT (2 required per assembly)
		10-16830A 1 - Screw Kit [ More info ] $5.09 Available to Order: Shipping delay up to 10 days.
#21	898101291	GASKET (1 required per assembly)
		27-898101291 - Intake Manifold Gasket [ More info ] Unavailable
#22	803508013	GASKET @4 (2 required per assembly)
		27-803508013 - Carburetor Gasket [ More info ] $5.09 2 In Stock.
#23	80350810	GASKET (1 required per assembly)
		27-803508 10 - Insulator Gasket [ More info ] Unavailable
#24	16832	BOLT (1 required per assembly)
		10-16832 - Bolt [ More info ] $4.49 Available to Order: Shipping delay up to 10 days.
#25	803528	BRACKET (1 required per assembly)
		803528 - Bracket [ More info ] $4.59 4 In Stock.
#26	898101293	CABLE [0R758225] & Below (1 required per assembly)
		898101293 - Choke Link Cable [ More info ] $19.09 Available to Order: Shipping delay up to 10 days.
#26	8M0130963	CABLE [0R758226] & Up (1 required per assembly)
		8M0130963 - Cable [ More info ] $6.09 Available to Order: Shipping delay up to 10 days.
#27	804371001	COLLAR (1 required per assembly)
		23-804371001 - Collar [ More info ] Unavailable
#28	8M0121984	SILENCER - AIR (1 required per assembly) — Replaces: 803526T
		8M0121984 - SILENCER - AIR [ More info ] Unavailable
#29	400212	NUT (1 required per assembly) — Replaces: 879194336, 16825
		11-40021 2 - Nut [ More info ] $2.89 2 In Stock.
#30	952868	COLLAR (2 required per assembly)
		23-95286 8 - Collar [ More info ] $3.69 Available to Order: Shipping delay up to 10 days.
#31	803527	TRAP-FLAME (1 required per assembly)
		803527 - Flame Trap [ More info ] $8.79 Available to Order: Shipping delay up to 10 days.
#32	16826	WASHER (2 required per assembly) — Replaces: 879194338
		12-16826 - Washer, Stainless Steel [ More info ] $3.29 Available to Order: Shipping delay up to 10 days.
#33	898103229	BOLT @2 (2 required per assembly) — Replaces: 898101292
		10-898103229 - Bolt [ More info ] $11.19 1 In Stock.
#34	879194248	BOLT (1 required per assembly)
		10-879194248 - Bolt [ More info ] $6.09 Available to Order: Shipping delay up to 10 days.
#35	161404	WASHER (1 required per assembly)
		12-16140 4 - Washer [ More info ] $4.29 2 In Stock.
#36	8M0155131	ROD CHOKE (1 required per assembly) — Replaces: 804646
		8M0155131 - Choke Rod [ More info ] $15.69 Available to Order: Shipping delay up to 10 days.
