Parts for 150 HP EFI Seapro 4-Stroke Mercury Outboard Motor Electrical
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | NSS | NOT SOLD SEPARATE DECAL, MAINTENANCE SCHEDULE ANZP 135 HP 4 S (1 required per assembly) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #1 | 8M0069690 | SCREW (2 required per assembly) — Replaces: 8M0047948 |
  |
|
108M0069690 - Screw [ More info ]
|
| #2 | 8M0065239 | ALTERNATOR (1 required per assembly) — Replaces: 8M0057693 |
  |
|
8M0065239 - Alternator [ More info ]
|
  |
|
20851 - ALT F/OUTBOARD MERCURY ENGINES [ More info ]
|
| #3 | 401386 | NUT @5 (1 required per assembly) |
  |
|
11-40138 6 - Nut - Priced Individually [ More info ]
|
| #4 | 8M0031641 | BELT,4RIB POLY V (1 required per assembly) |
  |
57-8M0031641 - Serpentine Belt, 4 Rib Poly V [ More info ] Unavailable |
|
  |
|
57-8M0235013 - Serpentine Belt [ More info ]
|
| #5 | 8M0103807 | SCREW @2 (6 required per assembly) — Replaces: 88552525 |
  |
|
108M0103807 - Screw (M6 x 25 MM) Stainless Steel [ More info ]
|
| #6 | 65567 | WASHER @2 (6 required per assembly) |
  |
|
12-65567 - Washer, (.265 X .750 X .048) Stainless Steel [ More info ]
|
| #7 | 834985 | GROMMET @5 (6 required per assembly) |
  |
|
25-834985 - Grommet [ More info ]
|
  |
|
25-8M0190980 - GROMMET Note: Must be ordered in multiples of 5 [ More info ]
|
| #8 | 856954 | BUSHING (6 required per assembly) |
  |
|
23-856954 - Bushing [ More info ]
|
| #9 | 8M0101551 | COVER-PWR CENTER Non SeaPro (1 required per assembly) — Replaces: 8M0057700 |
  |
|
8M0101551 - Cover-PWR CENTER [ More info ]
|
| #9 | 8M0099169 | COVER-PWR CENTER SeaPro (1 required per assembly) |
  |
|
8M0099169 - Cover-PWR CENTER [ More info ]
|
| #10 | 8M0057697 | CUBE RELAY (4 required per assembly) |
  |
8M0057697 - CUBE Relay [ More info ] Unavailable |
|
  |
|
8M0219829 - RELAY-CUBE [ More info ] Unavailable |
| #11 | 832969T15 | FUSE-15 AMP @5 (1 required per assembly) |
  |
|
88-832969T15 - Fuse -Blue-15AMP [ More info ]
|
| #11 | 832969T20 | FUSE-20 AMP @5 (2 required per assembly) |
  |
|
88-832969T20 - Fuse - Yellow - 20 Amp [ More info ]
|
| #11 | 8M0207797 | FUSE-GRAY-2 AMP (1 required per assembly) — Replaces: 8329692 |
  |
|
888M0207797 - FUSE-GRAY-2 AMP [ More info ]
|
| #12 | 8M0047885 | FUSE COVER W/SPAC (1 required per assembly) |
  |
|
8M0047885 - Fuse Cover W/SPAC [ More info ]
|
| #13 | 899145 | CLIP (10 required per assembly) |
  |
|
54-899145 - Clip [ More info ]
|
| #14 | 859376 | CLIP (2 required per assembly) |
  |
|
54-859376 - Clip [ More info ]
|
| #15 | 8M0079206 | ECM 150 4S (1 required per assembly) — Replaces: 8M0057694, 8M0076650 |
  |
8M0079206 - ECM 150 4S [ More info ] Unavailable |
|
  |
|
778M0168123 - ECM-150 HP FS [ More info ] Unavailable |
| #15 | 8M0168124 | ECM-150HP FS SP SEAPRO/ ANZP 135HP 4S (1 required per assembly) — Replaces: 8M0098625 |
  |
|
778M0168124 - ECM-150HP FS SP [ More info ] Unavailable |
| #16 | 8M0057698 | HARNESS ASY-FUSED (1 required per assembly) |
  |
|
848M0057698 - Harness Assembly, Fused [ More info ] Unavailable |
| #17 | 8M0033589 | CABLE ASSY-START (1 required per assembly) |
  |
|
848M0033589 - Cable Assembly -START [ More info ]
|
| #18 | 88439A35 | CABLE-BATTERY POS (1 required per assembly) |
  |
|
8488439A35 - Battery Cable POS [ More info ]
|
| #19 | 88439A26 | CABLE ASSY-NEG (1 required per assembly) |
  |
|
84-88439A26 - Cable Assembly -neg [ More info ]
|
| #20 | 8M0057696 | HARNESS ASSY, ENG (1 required per assembly) |
  |
|
848M0057696 - Engine Harness Assembly [ More info ]
|
| #21 | 816311T | TIE STRAP @100 (2 required per assembly) |
  |
|
54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ]
|
| #22 | 8M0094687 | DECAL-M. SCHEDULE SeaPro (1 required per assembly) |
  |
|
378M0094687 - Decal-M. SCHEDULE [ More info ]
|
| #23 | 8M0098217 | DECAL-PWR CENTER Non SeaPro (1 required per assembly) |
  |
|
378M0098217 - Decal-PWR CENTER [ More info ]
|
| #24 | 40011145 | SCREW @2 For Use with Battery Isolator (AR required per assembly) |
  |
|
10-40011145 - Screw - Priced Individually [ More info ]
|
