Parts for Bravo XR Sportmaster MerCruiser Outdrive Units Steering Cylinder (Integrated Transom)
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 845760T3 | CYLINDER ASSEMBLY STEERING STARBOARD (1 required per assembly) |
  |
|
845760T 3 - Hydraulic Cylinder Assembly - Stbd [ More info ]
|
| #1 | 845760T6 | CYLINDER ASSEMBLY STEERING PORT (1 required per assembly) |
  |
|
845760T 6 - Hydraulic Cylinder Assembly - Port [ More info ]
|
| #2 | 8159501 | BUSHING (3 required per assembly) |
  |
23-815950 1 - Bushing - Priced Individually [ More info ] Unavailable |
|
  |
|
18-2341-1-9 - Power Trim Bushings, Pack of 8 [ More info ]
|
  |
|
23-8M0214952 - Trim Cylinder Bushing - GEN II Note: Priced Individually [ More info ]
|
| #3 | NSS | NOT SOLD SEPARATE PLUG (1 required per assembly) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #4 | NSS | NOT SOLD SEPARATE PLUG (1 required per assembly) |
| #5 | 847062A1 | BONDING KIT (2 required per assembly) |
  |
|
847062A 1 - Cable Bonding Kit [ More info ]
|
| #6 | 68513 | SCREW (#10-32 X .375) STAINLESS STEEL (1 required per assembly) |
  |
|
10-68513 - Screw [ More info ]
|
| #7 | 69432 | LOCKWASHER EXTERNAL (#10) (3 required per assembly) |
  |
|
13-69432 - LockWasher - Priced Individually [ More info ]
|
| #8 | 35871 | SCREW (.375-24 X 1.500) (1 required per assembly) |
  |
|
10-35871 - Screw [ More info ]
|
| #9 | 27880 | WASHER (1 required per assembly) |
  |
|
12-27880 - Washer, Lower Shift Shaft And Crank [ More info ]
|
| #10 | NSS | NOT SOLD SEPARATE O-RING, COMPONENT OF SEAL KIT (1 required per assembly) |
| #11 | NSS | NOT SOLD SEPARATE PISTON (1 required per assembly) |
| #12 | NSS | NOT SOLD SEPARATE O-RING, COMPONENT OF SEAL KIT (3 required per assembly) |
| #13 | NSS | NOT SOLD SEPARATE PISTON ROD (1 required per assembly) |
| #14 | 845997 | NUT (.625-18) (1 required per assembly) |
  |
|
11-845997 - Nut, (.625-18) [ More info ]
|
| #15 | NSS | NOT SOLD SEPARATE ROD END (1 required per assembly) |
| #16 | NSS | NOT SOLD SEPARATE O-RING, COMPONENT OF SEAL KIT (1 required per assembly) |
| #17 | 8M0050236 | END CAP (1 required per assembly) — Replaces: 840768T, 840768 |
  |
|
8M0050236 - End Cap [ More info ]
|
| #18 | NSS | NOT SOLD SEPARATE ROD SCRAPER, COMPONENT OF SEAL KIT (1 required per assembly) |
| #19 | NSS | NOT SOLD SEPARATE WASHER, COMPONENT OF SEAL KIT (1 required per assembly) |
| #20 | NSS | NOT SOLD SEPARATE RETAINING RING, COMPONENT OF SEAL KIT (1 required per assembly) |
| #21 | 840854 | STUD (#10-32 X 1.22) (2 required per assembly) |
  |
|
16-840854 - Stud - Priced Individually [ More info ]
|
| #22 | 806189Q1 | ANODE (1 required per assembly) |
  |
|
97-806189Q 1 - Anode Kit Trim Cylinder GEN II - Priced Individually [ More info ]
|
  |
|
18-6114 - Anode, Magnesium, 806189 [ More info ]
|
  |
|
97-806189T 1 - Anode Kit - Priced Individually [ More info ]
|
| #23 | 840853 | NUT (#10-32) STAINLESS STEEL (1 required per assembly) |
  |
|
11-840853 - Nut, (#10-32) Stainless Steel [ More info ]
|
| #24 | 859124 | NUT (#10-32) STAINLESS STEEL (2 required per assembly) |
  |
|
11-859124 - Nut, (#10-32) Stainless Steel, Nylon Insert [ More info ]
|
| #NS | 87298A1 | SEAL KIT STEERING CYLINDER (1 required per assembly) |
  |
|
25-87298A 1 - Seal Kit [ More info ]
|
