Steering Actuator, Axius (Gen II)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	8M0189606	KIT-STEER CYL (2 required per assembly) — Replaces: 8M8025732
		8M0189606 - 8M0189606 - KIT-STEER CYL [ More info ] Unavailable Replaced by -8M0228799
		8M0228799 - KIT-STEER CYL [ More info ] Unavailable
#1	8M0047043	STEERING ACTUATOR ASSEMBLY (1 required per assembly)
		8M0047043 - Steering Actuator [ More info ] Unavailable
		8M0228798 - STEERING ACTUATOR [ More info ] Unavailable
#2	8M2018451	BRACKET TVM CLAMP (1 required per assembly)
		8M2018451 - Bracket [ More info ] $21.59 Available to Order: Shipping delay up to 10 days.
#3	8M2020078	PAD ISOLATION (1 required per assembly)
		8M2020078 - PAD Isolation [ More info ] $5.39 Available to Order: Shipping delay up to 10 days.
#4	401366	NUT (M6) STAINLESS STEEL (4 required per assembly)
		11-40136 6 - Nut - Priced Individually [ More info ] $3.59 2 In Stock.
#5	4002316	WASHER (6.60 X 17.0 X 1.5SS) (4 required per assembly)
		12-40023 16 - Washer - Priced Individually [ More info ] $1.17 2 In Stock.
		128M0214930 - WASHER Note: Must be ordered in multiples of 5 [ More info ] $1.00 1 In Stock.
#6	865414001	FITTING (1 required per assembly)
		22-865414001 - Fitting -q/C [ More info ] $10.99 Available to Order: Shipping delay up to 10 days.
#7	865415	FITTING (1 required per assembly)
		22-865415 - Fitting -q/C [ More info ] $33.99 Available to Order: Shipping delay up to 10 days.
#8	8M2020077	PAD ISOLATION (1 required per assembly)
		8M2020077 - PAD Isolation [ More info ] $4.49 Available to Order: Shipping delay up to 10 days.
#9	8M2019104	GROMMET (.285 INSIDE DIAMETER) (1 required per assembly)
		25-8M2019104 - Grommet [ More info ] $0.50 Available to Order: Shipping delay up to 10 days.
#10	8M0047525	BRACKET TVM MOUNTING (1 required per assembly)
		8M0047525 - Bracket [ More info ] $112.99 Available to Order: Shipping delay up to 10 days.
#11	889664	NUT (1.500-18) BLACK NYLON (1 required per assembly)
		11-889664 - Nut, (1.500-18) Black Nylon [ More info ] $6.69 Available to Order: Shipping delay up to 10 days.
#12	8M0047524	MODULE - TVM (1 required per assembly)
		8M0047524 - Module-TVM [ More info ] $1,199.99 Available to Order: Shipping delay up to 10 days.
#13	856954	BUSHING (3 required per assembly)
		23-856954 - Bushing [ More info ] $6.99 Available to Order: Shipping delay up to 10 days.
#14	834985	GROMMET (3 required per assembly)
		25-834985 - Grommet [ More info ] $3.00 2 In Stock.
		25-8M0190980 - GROMMET Note: Must be ordered in multiples of 5 [ More info ] $3.89 Available to Order: Shipping delay up to 10 days.
#15	65567	WASHER (.265 X .750 X .048) STAINLESS STEEL (3 required per assembly)
		12-65567 - Washer, (.265 X .750 X .048) Stainless Steel [ More info ] $2.89 Available to Order: Shipping delay up to 10 days.
#16	401366	NUT (M6) STAINLESS STEEL (1 required per assembly)
#17	82130025	SCREW (M6 X 25) (2 required per assembly)
		10-821300 25 - Screw [ More info ] $4.09 Available to Order: Shipping delay up to 10 days.
#18	899145	CLIP TIE STRAP (4 required per assembly)
		54-899145 - Clip [ More info ] $3.39 Available to Order: Shipping delay up to 10 days.
#19	822392	SPACER (2 required per assembly)
		23-822392 - Spacer - Handle Rest [ More info ] $19.89 Available to Order: Shipping delay up to 10 days.
#20	879150A34	WASHER ASSEMBLY (1 required per assembly)
		14-879150A34 - Tab Washer [ More info ] $75.49 Available to Order: Shipping delay up to 10 days.
#21	8M2010068	WASHER (.78 X 1.25 X .05) STAINLESS STEEL (1 required per assembly)
		12-8M2010068 - Washer, (.78 X 1.25 X .05) Stainless Steel, Pivot (bottom) [ More info ] $15.29 Available to Order: Shipping delay up to 10 days.
#22	8M0109446	HARNESS TVM THRUST VECTOR MODULE (1 required per assembly) — Replaces: 8M0047044
