Parts for Bravo X Two MerCruiser Outdrive Units Universal Joint / Shifter Components (X-Drive)

Revise Search: Sterndrive > MerCruiser Outdrive Units > Bravo X Two > 0M100001 - 0W249999 > Universal Joint / Shifter Components (X-Drive)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Universal Joint / Shifter Components (X-Drive)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	8M0157426	COVER ASSY BACK (1 required per assembly) — Replaces: 12717A1
		8M0157426 - Cover REAR BRAVO D/S HSG ZZ [ More info ] $309.99 $306.14 In Stock
#2	12708	SEAL (1 required per assembly)
		12708 - Seal [ More info ] $15.99 Available to Order: Shipping delay up to 10 days.
		18-1240 - Seal, 12708 [ More info ] $12.77 2 In Stock.
#3	8M0157700	DETENT ASSEMBLY (1 required per assembly) — Replaces: 14497A2, 865711A02
		8M0157700 - Detent Assembly [ More info ] $86.99 $83.49 In Stock
#4	8M0113180	SCREW @2 (2 required per assembly) — Replaces: 98794
		10-8M0113180 - Mouting Screw AL/BRAV TOP Cover, priced individually [ More info ] $5.09 Available to Order: Shipping delay up to 10 days.
#5	87158	SCREW (1 required per assembly)
		10-87158 - Screw [ More info ] $13.49 Available to Order: Shipping delay up to 10 days.
#6	805261A1	WEAR PAD KIT (1 required per assembly)
		805261A 1 - Wear Pad Kit [ More info ] $31.83 4 In Stock.
#7	12711	SHAFT SHIFTER (1 required per assembly)
		12711 - Shaft [ More info ] $83.99 Available to Order: Shipping delay up to 10 days.
#8	806552A1	YOKE & CAM ASSY (1 required per assembly)
		806552A 1 - Yoke & Cam Assembly [ More info ] $293.49 In Stock
#9	806552	YOKE SHIFTER SHIFTER (1 required per assembly)
		806552 - Shifter Yoke [ More info ] $165.49 Available to Order: Shipping delay up to 10 days.
#10	805733	SCREW (.250-28 X 1.00) (2 required per assembly)
		10-805733 - Screw [ More info ] $1.80 1 In Stock.
#11	12706	SPACER (.194 X .375) (2 required per assembly)
		23-12706 - Spacer - .194 X .375 [ More info ] $5.69 7 In Stock.
#12	826709109	NUT (.250-28) STAINLESS STEEL (2 required per assembly)
		11-826709109 - Nut, (.250-28) Stainless Steel [ More info ] $3.59 5 In Stock.
#13	38615	SCREW @5 (1 required per assembly)
		10-38615 - Screw - Priced Individually [ More info ] $3.99 10+ In Stock.
#14	8M0185784	LINKAGE KIT-SHIFT (1 required per assembly) — Replaces: 861175A2
		8M0185784 - Shift Linkage Kit [ More info ] $155.49 $149.49 In Stock
#15	NSS	NOT SOLD SEPARATE LEVER, SHIFT (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#16	20583	WASHER (1 required per assembly)
		12-20583 - Washer - Priced Individually [ More info ] $1.50 10+ In Stock.
#17	26953	COTTER PIN (1 required per assembly)
		18-26953 - Cotter Pin - Priced Individually [ More info ] $4.19 9 In Stock.
#18	86776	LATCH (1 required per assembly)
		86776 - Latch [ More info ] $9.79 Available to Order: Shipping delay up to 10 days.
#19	865425A03	UNIVERSAL JOINT ASSEMBLY BLACK (GKN Assembly) [0M750175] & Up (1 required per assembly) — Replaces: 862129A1
		865425A03 - Universal Joint Assembly [ More info ] $1,256.49 In Stock
#20	NSS	NOT SOLD SEPARATE YOKE ASSEMBLY, COUPLER END (Meritor Assembly) [0M750174] & Below (1 required per assembly)
#20	866133A01	YOKE SPLINED YOKE ASSEMBLY, COUPLER END (GKN Assembly) [0M750175] & Up (1 required per assembly)
		866133A01 - Yoke -Splined [ More info ] $352.99 Available to Order: Shipping delay up to 10 days.
#21	8M0204650	O-RING (2 required per assembly) — Replaces: 29845
		25-8M0204650 - O RING @3 Q=T [ More info ] Unavailable
#22	8M0204654	O RING @10 (1 required per assembly) — Replaces: 35027
		25-8M0204654 - O RING @10 [ More info ] Unavailable
#23	NSS	NOT SOLD SEPARATE SOCKET, CENTER (Meritor Assembly) [0M750174] & Below (1 required per assembly)
#23	866137T	SOCKET CENTER SOCKET, CENTER (GKN Assembly) [0M750175] & Up (1 required per assembly)
		866137T - Center Socket [ More info ] $223.49 Available to Order: Shipping delay up to 10 days.
#24	865425A03	UNIVERSAL JOINT ASSEMBLY (Meritor Assembly) [0M750174] & Below (2 required per assembly) — Replaces: 862132T
#24	866136A01	CROSS AND BEARING (GKN Assembly) [0M750175] & Up (2 required per assembly)
		866136A01 - Cross And Bearing [ More info ] $379.99 In Stock
#25	NSS	NOT SOLD SEPARATE YOKE, GEAR END (Meritor Assembly) [0M750174] & Below (1 required per assembly)
#25	866134T	YOKE YOKE, GEAR END (GKN Assembly) [0M750175] & Up (1 required per assembly)
		866134T - Yoke -stub [ More info ] Unavailable
#26	8M0205246	RETAINER/SEAL KIT (1 required per assembly) — Replaces: 862118A2, 841026A2
		53-8M0205246 - RETAINER/SEAL KIT [ More info ] In Stock
#27	861844	O-RING (1 required per assembly)
		25-861844 - O-Ring [ More info ] Unavailable
		18-7961 - O-Ring 25-97386 [ More info ] $4.41 6 In Stock.
		25-8M0214974 - O-Ring [ More info ] $8.19 2 In Stock.
#28	807006	SEAL OIL 2.254&QUOT; DIAMETER (1 required per assembly)
		26-807006 - Seal [ More info ] $31.79 2 In Stock.
#28	43993	SEAL OIL 2.132&QUOT; DIAMETER (1 required per assembly)
		26-43993 - Seal [ More info ] Unavailable
		18-0523 - Seal, 26-43993 [ More info ] $22.99 $22.17 2 In Stock.
		26-8M0214932 - Crankshaft OIL SEAL O/B [ More info ] $26.09 In Stock
#29	8M0173219	WASHER (1 required per assembly) — Replaces: 862134
		12-8M0173219 - Washer [ More info ] $50.99 In Stock
#30	8M0104357	BEARING ASSY TAPERED [0M198372] & Below (1 required per assembly) — Replaces: 86763A3
		31-8M0104357 - Bearing Assembly [ More info ] $256.85 1 In Stock.
#30	8M0104358	BEARING ASSEMBLY [0M198373] & Up (1 required per assembly) — Replaces: 86763A04
		31-8M0104358 - Bearing Assembly [ More info ] $346.49 In Stock
#31	887906A1	GEAR SET (1 required per assembly) — Replaces: 883476A1
		43-887906A 1 - Gear Set [ More info ] $1,953.99 Available to Order: Shipping delay up to 10 days.
#31	887903A1	GEAR SET (1 required per assembly) — Replaces: 883473A1
		43-887903A 1 - Gear Set 32/27 [ More info ] $2,070.99 In Stock
#31	887909A1	GEAR SET (30/23) (23 TOOTH) (Bravo One X 1.65:1 Ratio) (1 required per assembly) — Replaces: 883479A1, 858334T
		43-887909A 1 - Gear Set [ More info ] $2,470.99 Available to Order: Shipping delay up to 10 days.
#32	861832	WASHER (1 required per assembly)
		12-861832 - Washer [ More info ] $6.99 Available to Order: Shipping delay up to 10 days.
#33	22339	NUT @5 (1 required per assembly) — Replaces: 97522
		11-22339 - Nut (5/8x18) [ More info ] Unavailable
		18-3713 - Nut, 11-22339 [ More info ] $5.98 5 In Stock.
		11-8M0214915 - NUT Note: Priced Individually [ More info ] $11.69 9 In Stock.
		11-01817 - Nut 11-22339 [ More info ] $5.99 $4.59 Available to Order: Shipping delay up to 10 days.
#34	821630Q1	ANODE KIT(ALUM) (1 required per assembly)
		97-821630Q 1 - Anode Kit -Drive Shaft Housing Bravo [ More info ] $45.49 10+ In Stock.
		18-6240 - Anode, Magnesium, 821630 [ More info ] $27.99 $27.82 In Stock
		18-6094 - Anode, Zinc, 821630A1 [ More info ] $35.69 $32.77 In Stock
		97-821630T 1 - Aluminun Anode-Drive Shaft Housing Bravo [ More info ] $49.99 $49.58 Available to Order: Shipping delay up to 10 days.
#35	35479	LOCKWASHER (.375) (2 required per assembly)
		13-35479 - LockWasher - Priced Individually [ More info ] $1.80 $1.01 10+ In Stock.
#36	65210	SCREW (.375-16 X 1.00) (2 required per assembly)
		10-65210 - Screw - Priced Individually [ More info ] $2.89 3 In Stock.
#37	888927028	SHIM [0M198373] & Up (AR required per assembly)
		15-888927028 - Shim [ More info ] $5.59 1 In Stock.
#37	888927029	SHIM [0M198373] & Up (AR required per assembly)
		15-888927029 - Shim [ More info ] $5.99 3 In Stock.
#37	888927030	SHIM [0M198373] & Up (AR required per assembly)
		15-888927030 - Shim [ More info ] $5.19 Available to Order: Shipping delay up to 10 days.
#37	888927031	SHIM [0M198373] & Up (AR required per assembly)
		15-888927031 - Shim [ More info ] $5.09 Available to Order: Shipping delay up to 10 days.
#37	888927032	SHIM [0M198373] & Up (AR required per assembly)
		15-888927032 - Shim [ More info ] $5.19 Available to Order: Shipping delay up to 10 days.
#37	888927033	SHIM [0M198373] & Up (AR required per assembly)
		15-888927033 - Shim [ More info ] $7.99 Available to Order: Shipping delay up to 10 days.
#37	888927034	SHIM [0M198373] & Up (AR required per assembly)
		15-888927034 - Shim [ More info ] $5.49 Available to Order: Shipping delay up to 10 days.
#37	888927035	SHIM [0M198373] & Up (AR required per assembly)
		15-888927035 - Shim [ More info ] $5.19 Available to Order: Shipping delay up to 10 days.
#37	888927036	SHIM [0M198373] & Up (AR required per assembly)
		15-888927036 - Shim [ More info ] $5.49 Available to Order: Shipping delay up to 10 days.
#37	888927037	SHIM [0M198373] & Up (AR required per assembly)
		15-888927037 - Shim [ More info ] $6.79 1 In Stock.
#37	888927038	SHIM [0M198373] & Up (AR required per assembly)
		15-888927038 - Shim [ More info ] $6.79 Available to Order: Shipping delay up to 10 days.
#37	888927039	SHIM [0M198373] & Up (AR required per assembly)
		15-888927039 - Shim [ More info ] $6.09 $1.22 3 In Stock.
#37	888927040	SHIM [0M198373] & Up (AR required per assembly)
		15-888927040 - Shim [ More info ] $5.09 Available to Order: Shipping delay up to 10 days.
#NS	16709A2	SEAL KIT DRIVESHAFT HOUSING (1 required per assembly)
		26-16709A 2 - Seal Kit [ More info ] $140.49 $138.46 In Stock
		18-2643 - Seal Kit, 26-16709A2 [ More info ] $120.02 9 In Stock.
		26-02388 - Seal Kit 26-16709A 2 [ More info ] $94.99 $85.01 2 In Stock.
