Parts for V-220 Laser 2-Stroke EFI Mercury Outboard Motor Gear Housing (Propeller Shaft)

Revise Search: Outboard > 2-Stroke EFI Mercury Outboard > V-220 Laser > 0B117316 & Up - USA > Gear Housing (Propeller Shaft)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Gear Housing (Propeller Shaft)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	9148A84	GEAR HOUSING ASSEMBLY (LONG) (BLACK) (1 required per assembly) — Replaces: 9148A8, 9148A69
		1647-9148A84 - Gear Housing Assembly [ More info ] Unavailable
		1647-9148T84 - Gear Housing Assembly [ More info ] Unavailable
		90-206-A20 - SE206 Lower Unit Mercury 2.0, 2.4, 2.5L, 1.87 to 1, 20 Inch [ More info ] $1195.00 $1195.00 Available to Order
#-	9148A85	GEAR HOUSING ASSEMBLY (X-LONG) (BLACK) (1 required per assembly) — Replaces: 9148A9, 9148A72
		1647-9148A85 - Gear Housing Assembly [ More info ] Unavailable
		1647-9148T85 - Gear Housing Assembly [ More info ] Unavailable
		90-206-A25 - SE206 Lower Unit Mercury 2.0, 2.4, 2.5L, 1.87 to 1, 25 Inch [ More info ] $1195.00 $1195.00 Available to Order
#-	9148A90	GEAR HOUSING ASSEMBLY (LONG) (GRAY) (1 required per assembly) — Replaces: 9148A10, 9148A70
		1647-9148A90 - Gear Housing Assembly [ More info ] Unavailable
		1647-9148T90 - GEAR HSG-L-GRAY [ More info ] Unavailable
#-	9148A91	GEAR HOUSING ASSEMBLY (X-LONG) (GRAY) (1 required per assembly) — Replaces: 9148A13, 9148A73
		1647-9148A91 - Gear Housing Assembly [ More info ] Unavailable
		1647-9148T91 - Ord 1647-9148T85, NLA [ More info ] Unavailable
#-	89238A2	SEAL KIT (1 required per assembly)
		26-89238A 2 - Seal Kit [ More info ] $97.49 In Stock
		18-2655 - Seal Kit, 26-89238A2 [ More info ] $75.40 10+ In Stock.
		26-00288-1 - Lower Gearcase Seal Kit Mercury Mariner V6 [ More info ] $74.99 $57.34 2 In Stock.
#-	14697A87	GASKET SET (1 required per assembly)
		27-14697A87 - Engine Gasket Set [ More info ] $161.68 1 In Stock.
#1	9148T47	GEAR HSG-BASIC-BL (BLACK) (1 required per assembly) — Replaces: 9148A11, 9148A47
		1647-9148T47 - Gear Housing - Basic, Black [ More info ] $1,782.99 Available to Order: Shipping delay up to 10 days.
		1647-9148T49 - Gear Housing - Basic, NLA [ More info ] $600.00 $508.20 2 In Stock.
#1	9148T48	GEAR HSG-BASIC-GR (GRAY) (1 required per assembly) — Replaces: 9148A12, 9148A48
		1647-9148T48 - Gear Housing-BASIC-GR [ More info ] Unavailable
#48	789562	SHIFT CAM (1 required per assembly) — Replaces: 78956
		78956 2 - Shift Cam [ More info ] $11.49 3 In Stock.
#49	89594A1	FOLLOWER ASSEMBLY CAM (1 required per assembly)
		89594A 1 - Cam/Follower Kit [ More info ] $234.99 Available to Order: Shipping delay up to 10 days.
#50	79911A1	ROD CLUTCH ACTUATOR (1 required per assembly) — Replaces: 79911, 799111
		79911A 1 - Clutch Rod Kit [ More info ] $186.49 Available to Order: Shipping delay up to 10 days.
#51	79910	SPRING COMPRESSION (2 required per assembly)
		24-79910 - Spring, Compression [ More info ] $8.19 Available to Order: Shipping delay up to 10 days.
#52	78910	WASHER COMPRESSION SPRING (1 required per assembly)
		12-78910 - Washer, Compression Spring [ More info ] $1.99 10+ In Stock.
#53	8M0084245	PIN SPRING LOCATOR SPRING LOCATOR (1 required per assembly) — Replaces: 78906
		178M0084245 - Locator Pin [ More info ] $3.69 Available to Order: Shipping delay up to 10 days.
#54	47397A1	SHIM SET BEARING OUTER RACE (.002-3-5-10) (AR required per assembly)
		15-47397A 1 - Shim Set [ More info ] $16.79 $11.26 10+ In Stock.
		18-2285 - Shim 15-47397A1 [ More info ] $30.99 $27.04 In Stock
#55	78172A1	BEARING ASSEMBLY TAPERED ROLLER (1 required per assembly)
		31-78172A 1 - Tapered Roller Bearing [ More info ] $104.99 $55.22 3 In Stock.
#56	44104T2	GEAR SET (1 required per assembly) — Replaces: 44104A2
		43-44104T 2 - Gear Set [ More info ] $1,153.49 1 In Stock.
		43-02946 - Gear Set 43-44104T2 [ More info ] $799.99 $713.64 In Stock
#57	43999	BEARING ROLLER (1.308 O.D.) (2 required per assembly)
		31-43999 - Roller Bearing - Forward Gear - 1.308 OD [ More info ] Unavailable
#57	73363T	BEARING (1.313 O.D.) (2 required per assembly) — Replaces: 73363
		31-73363T - Bearing [ More info ] $18.60 10+ In Stock.
#58	823174T	CLUTCH SLIDING CLUTCH (1 required per assembly) — Replaces: 78959, 823174
		52-823174T - Clutch [ More info ] Unavailable
		52-8M0100493 - Clutch Kit [ More info ] $116.49 Available to Order: Shipping delay up to 10 days.
#59	8M0084243	PIN CROSS RATCHET TO PROPELLER SHAFT (1 required per assembly) — Replaces: 78905
		178M0084243 - Pin - CROSS [ More info ] $6.99 Available to Order: Shipping delay up to 10 days.
#60	78909	PIN DETENT RATCHET (2 required per assembly)
		17-78909 - Pin, Detent [ More info ] $19.19 $18.40 3 In Stock.
#61	78962	SPRING RETAINING - CROSS PIN (2 required per assembly)
		24-78962 - Spring, Retaining - Cross Pin [ More info ] $11.49 Available to Order: Shipping delay up to 10 days.
#62	94148	PROPELLER SHAFT (1 required per assembly)
		44-94148 - Prop Shaft [ More info ] $649.99 Available to Order: Shipping delay up to 10 days.
		18-2239 - Propeller Shaft, 44-94148 [ More info ] $609.99 $552.64 Available to Order: Shipping delay up to 10 days.
		92-206-05 - Propeller Shaft replaces 44-94148 [ More info ] $317.62 $317.62 Available to Order
#63	N.S.S.	NOT SOLD SEPARATE REVERSE GEAR (PART OF 43-44104A2) (1 required per assembly)
		N.S.S. - Not Sold Separate [ More info ] Unavailable
#64	681001	RING THRUST THRUST - BEARING CARRIER TO GEAR HOUSING (1 required per assembly) — Replaces: 68100
		68100 1 - Ring - Thrust [ More info ] $18.79 $15.04 10+ In Stock.
#65	88957T	BEARING BALL REVERSE GEAR (1 required per assembly) — Replaces: 88957A1, 88957
		30-88957T - Ball Bearing [ More info ] $64.49 Available to Order: Shipping delay up to 10 days.
		18-1155 - Bearing 30-88957T [ More info ] $54.84 1 In Stock.
#66	31534	O-RING BEARING CARRIER (1 required per assembly)
		25-31534 - O-Ring, Bearing Carrier [ More info ] $5.50 1 In Stock.
		25-8M0214920 - Bell Housing O-Ring Note: Priced Individually [ More info ] $6.29 7 In Stock.
#67	43567T1	CARRIER ASSEMBLY BEARING (1 required per assembly) — Replaces: 43567A1
		43567T 1 - Carrier Assembly [ More info ] $311.49 Available to Order: Shipping delay up to 10 days.
#68	30956T	BEARING NEEDLE BEARING CARRIER (1 required per assembly) — Replaces: 30956
		31-30956T - Roller Bearing [ More info ] $19.88 1 In Stock.
#69	8M0204670	SEAL @5 BEARING CARRIER (2 required per assembly) — Replaces: 76868
		26-8M0204670 - Gearcase Seal, Priced Individually [ More info ] $19.19 6 In Stock.
#70	30281	KEY LOCATING - BEARING CARRIER (1 required per assembly)
		28-30281 - Key - Priced Individually [ More info ] $2.99 10+ In Stock.
#71	79447	TAB WASHER GEAR HOUSING COVER (1 required per assembly)
		14-79447 - Tab Washer - Priced Individually [ More info ] $13.69 10+ In Stock.
#72	8M2000347	RETAINER GEAR HOUSING (1 required per assembly) — Replaces: 79448, 8M2011027
		8M2000347 - Retainer [ More info ] Unavailable
		8M0168577 - Bearing Carrier Retaining Nut [ More info ] $43.49 In Stock
#73	316404	TRIM TAB GEAR HOUSING (1 required per assembly) — Replaces: 31640A1, 316403
		0316404 - L/P 167.90 [ More info ] Unavailable
#74	66024	SCREW (.437-14 X 1.75) TRIM TAB TO GEAR HOUSING (1 required per assembly)
		10-66024 - Screw - Priced Individually [ More info ] $9.69 7 In Stock.
#75	45176	WASHER (.453 X .812 X .105) STAINLESS STEEL DRIVESHAFT HOUSING STUDS (2 required per assembly)
		12-45176 - Washer, (.453 X .812 X .105) [ More info ] $1.50 6 In Stock.
#76	8M0204653	NUT @10 DRIVESHAFT HOUSING STUDS (2 required per assembly) — Replaces: 34933
		11-8M0204653 - Prop Lock Nut 7/16-20 , Priced Individually [ More info ] $5.29 10 In Stock.
		11-00118 - Nut, Sold Individually [ More info ] $3.59 $2.95 7 In Stock.
#77	65210	SCREW (.375-16 X 1.00) GEAR HOUSING (LONG) (1 required per assembly)
		10-65210 - Screw - Priced Individually [ More info ] $2.89 3 In Stock.
#77	74727	SCREW (.375-16 X 6.00) GEAR HOUSING (EXTRA LONG) (1 required per assembly)
		10-74727 - Screw [ More info ] $12.89 Available to Order: Shipping delay up to 10 days.
#78	8354671	THRUST WASHER (1 required per assembly) — Replaces: 13171, 835467
		12-835467 1 - Thrust Washer [ More info ] $19.99 10+ In Stock.
		12-835467Q01 - Thrust Washer - Priced Individually [ More info ] $41.60 10 In Stock.
		18-4220 - Washer, 12-835467 1 [ More info ] $39.19 In Stock
		12-835467K01 - Thrust Washer - Priced Individually [ More info ] $41.60 Available to Order: Shipping delay up to 10 days.
#79	31211Q03	WASHER ASSEMBLY PROPELLER NUT (1 required per assembly) — Replaces: 31211A2, 31211A3
		12-31211Q03 - Washer - Priced Individually [ More info ] $15.17 2 In Stock.
		18-3714 - Washer, 12-31211A2 [ More info ] $11.54 7 In Stock.
#80	816629Q	TAB WASHER PROPELLER NUT (1 required per assembly) — Replaces: 31210, 816629
		14-816629Q - Tab Washer - Priced Individually [ More info ] $6.04 10+ In Stock.
		18-3200-9 - Washer, 14-816629, 10PK [ More info ] $78.72 4 In Stock.
		14-816629K - Tab Washer - Priced Individually [ More info ] $6.08 10+ In Stock.
#81	52707Q1	PROP NUT KIT@2 (1 required per assembly) — Replaces: 52707A1
		11-52707Q 1 - Prop Nut Kit - Priced Individually [ More info ] $16.81 4 In Stock.
		18-3701 - Nut Kit, 11-52707A1 [ More info ] $24.71 10+ In Stock.
		18-3700 - Prop Nut Only, 11-52707 [ More info ] $15.31 In Stock
		11-52707T 1 - Prop Nut Kit - Priced Individually [ More info ] $16.81 2 In Stock.
		11-00122 - Prop Nut Kit [ More info ] $13.99 $12.60 2 In Stock.
#82	423511	LOCKWASHER TOOTHED PROPELLER SHAFT (1 required per assembly)
		13-42351 1 - Washer - Priced Individually [ More info ] $3.05 10+ In Stock.
