Parts for 9.9 HP Carb (209Cc) 4-Stroke Mercury Outboard Motor Gear Housing Propeller Shaft
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 8M0070881 | GC 8/9.9 4S SH Short [0R784558] & Below (1 required per assembly) — Replaces: 895154T02, 895154T12 |
  |
16688M0070881 - Gearcase 8/9.9 4S SH [ More info ] Unavailable |
|
  |
16008M0135929 - GC 8/9.9 4S SHORT [ More info ] Unavailable |
|
  |
|
16008M0158631 - GC 8/9.9 4S SHORT [ More info ]
|
| #- | 8M0158631 | GC 8/9.9 4S SHORT Short [0R784559] & Up (1 required per assembly) — Replaces: 8M0135929 |
| #- | 8M0070883 | GC 8/9.9 4S LG Long [0R784558] & Below (1 required per assembly) — Replaces: 895154T03, 895154T11 |
  |
16688M0070883 - Gear Housing Complete [ More info ] Unavailable |
|
  |
16008M0135931 - GC 8/9.9 4S LONG [ More info ] Unavailable |
|
  |
|
16008M0158633 - GC 8/9.9 4S LONG [ More info ]
|
| #- | 8M0158633 | GC 8/9.9 4S LONG Long [0R784559] & Up (1 required per assembly) — Replaces: 8M0135931 |
| #- | 8M0135933 | GC 8/9.9 4S XLONG XLong [0R784559] & Up (1 required per assembly) |
  |
|
16008M0135933 - GC 8/9.9 4S UL [ More info ]
|
| #- | 804908A02 | GASKET SET [0R784558] & Below (1 required per assembly) — Replaces: 804908A00, 8M0060176 |
  |
27-804908A02 - Gasket Set [ More info ] Unavailable |
|
  |
278M0065830 - Gasket Set [ More info ] Unavailable |
|
  |
|
278M0082883 - Gasket Set [ More info ] Unavailable |
  |
|
27-8M0130156 - Gasket Set [ More info ]
|
| #- | 8M0130156 | GASKET SET [0R784559] & Up (1 required per assembly) |
| #- | 8M0135927 | BUSHING ORING KIT [0R784559] & Up (1 required per assembly) |
  |
|
98-8M0135927 - BUSHING ORING KIT [ More info ] Unavailable |
| #1 | 8M0158623 | GC 8/9.9 4S BASIC (1 required per assembly) — Replaces: 895154T01 |
  |
|
1600-8M0158623 - GC 8/9.9 4S BASIC [ More info ] Unavailable |
| #2 | 8037331 | BEARING BALL (1 required per assembly) |
  |
|
30-803733 1 - Bearing [ More info ]
|
| #3 | 16141 | SHIM (0.1) (AR required per assembly) |
  |
|
|
| #3 | 813277 | SHIM (0.15) (AR required per assembly) |
  |
|
15-813277 - Shim [ More info ]
|
| #4 | 8M0156174 | BEVEL GEAR ASSY (1 required per assembly) — Replaces: 8037391 |
  |
|
438M0156174 - BEVEL Gear [ More info ]
|
| #5 | 16152 | FOLLOWER CAM (1 required per assembly) |
  |
|
16152 - Cam Follower [ More info ]
|
| #6 | 8537642 | RETAINER SPRING (1 required per assembly) |
  |
|
853764 2 - Holder [ More info ]
|
| #7 | 8037451 | CLUTCH (1 required per assembly) |
  |
|
52-803745 1 - Clutch [ More info ]
|
| #8 | 16150 | PIN CLUTCH (1 required per assembly) |
  |
|
17-16150 - Pin, Clutch [ More info ]
|
| #9 | 892777002 | SPRING (58 MM) (1 required per assembly) |
  |
|
24-892777002 - Spring, (58 Mm) [ More info ]
|
| #10 | 8M0070782 | PROP SHAFT (1 required per assembly) — Replaces: 803744002 |
  |
|
448M0070782 - Prop Shaft [ More info ]
|
| #11 | 16140 | WASHER (1 required per assembly) |
  |
|
12-16140 - Washer, Propeller Shaft Gear [ More info ]
|
| #12 | 8M0156178 | BEVEL GEAR C (1 required per assembly) — Replaces: 8037411 |
  |
|
43-8M0156178 - BEVEL GEAR C [ More info ] Unavailable |
| #13 | 8M0070876 | CARRIER-BEARING (1 required per assembly) — Replaces: 803732T03 |
  |
|
8M0070876 - Bearing Carrier [ More info ]
|
| #14 | 16128 | BEARING BALL (1 required per assembly) |
  |
|
30-16128 - Ball Bearing [ More info ]
|
| #15 | 16131 | O-RING (1 required per assembly) |
  |
|
25-16131 - O-ring, Propeller Shaft Housing [ More info ]
|
| #16 | 16130 | SEAL OIL (1 required per assembly) |
  |
|
|
| #17 | 167051 | BOLT (M6 X 20) (2 required per assembly) |
  |
|
10-16705 1 - Bolt [ More info ]
|
| #18 | 8M0131240 | THRUST HOLDER ASY (1 required per assembly) — Replaces: 803743002, 8M0070811 |
  |
|
8M0131240 - Thrust Holder [ More info ]
|
| #19 | 897610A10 | BLKMAX 8.9X6.5 RH (OPT. required per assembly) — Replaces: 895180A10 |
  |
|
48-897610A10 - Black Max Prop 8.9X6.5 Rh [ More info ] Unavailable |
| #19 | 897614A10 | BLKMAX 8.9X7.5 RH 8 Horsepower (1 required per assembly) — Replaces: 895182A10 |
  |
|
48-897614A10 - Black Max Prop 8.9X7.5 Rh [ More info ]
|
| #19 | 897618A10 | BLKMAX 8.9X8.5 RH 9.9 Horsepower (1 required per assembly) — Replaces: 895183A10 |
  |
|
48-897618A10 - Black Max Prop 8.9X8.5 Rh [ More info ]
|
| #19 | 897620A10 | BLKMAX 8.9X9.5 RH (OPT. required per assembly) — Replaces: 895184A10 |
  |
|
48-897620A10 - Black Max Prop 8.9X9.5 Rh [ More info ] Unavailable |
| #20 | 16146 | WASHER (1 required per assembly) |
  |
|
12-16146 - Washer, Propeller Nut [ More info ]
|
| #21 | 16147 | PROP NUT (1 required per assembly) |
  |
|
11-16147 - Prop Nut [ More info ]
|
  |
|
1116147Q - Prop Nut (2) - Priced Individually [ More info ]
|
| #22 | 815026 | PIN-COTTER @5 (1 required per assembly) |
  |
|
18-815026 - Cotter Pin - Priced Individually [ More info ]
|
  |
|
18-815026Q - Pin -cott (3) - Priced Individually [ More info ]
|
