Parts for 80 HP EFI 4-Stroke Mercury Outboard Motor Oil Sump

Revise Search: Outboard > 4-Stroke Mercury Outboard > 80 HP EFI > 2B095049 & Up > Oil Sump

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Oil Sump

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	821327	PIN-DOWEL (2 required per assembly)
		17-821327 - Pin -Dowel [ More info ] $3.59 Available to Order: Shipping delay up to 10 days.
#2	8M0078540	GASKET,DSH/ADPTR (1 required per assembly)
		278M0078540 - Gasket,DSH/ADPTR [ More info ] $35.99 Available to Order: Shipping delay up to 10 days.
#3	8M0091528	SUMP-OIL (1 required per assembly)
		8M0091528 - SUMP-OIL [ More info ] $229.99 Available to Order: Shipping delay up to 10 days.
#4	8M0103809	SCREW @2 (10 required per assembly) — Replaces: 88552540
		108M0103809 - Screw - Priced Individually [ More info ] $2.49 Available to Order: Shipping delay up to 10 days.
#5	8M0112869	OIL PLUG ASSEMBLY (1 required per assembly) — Replaces: 8M0064964
		198M0112869 - OIL Plug Assembly [ More info ] $33.29 Available to Order: Shipping delay up to 10 days.
#6	85045	O-RING (.551 X .070) (1 required per assembly)
		25-85045 - O-ring, (.551 X .070) [ More info ] $4.09 Available to Order: Shipping delay up to 10 days.
#7	62706	O-RING (.426 X .070) (1 required per assembly)
		25-62706 - O-ring, (.426 X .070) [ More info ] $2.39 10+ In Stock.
#8	8M0036228	O-RING (8.1 X 1.6) (1 required per assembly)
		258M0036228 - O-Ring [ More info ] $5.70 2 In Stock.
#9	8M0068703	GROMMET, OIL SUMP (1 required per assembly)
		8M0068703 - Grommet, OIL SUMP [ More info ] $4.49 1 In Stock.
