Parts for 80 HP EFI 4-Stroke Mercury Outboard Motor Fuel Hose Routings

Revise Search: Outboard > 4-Stroke Mercury Outboard > 80 HP EFI > 1B227000 - 1B366822 - USA > Fuel Hose Routings

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Fuel Hose Routings

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	852776018	BOLT @2 (3 required per assembly)
		10-852776018 - Bolt - Priced Individually [ More info ] $1.50 $1.28 2 In Stock.
#2	56762	TIE STRAP @5 (2 required per assembly)
		56762 - Tie Strap - Priced Individually [ More info ] $0.50 3 In Stock.
#3	881530005	CLAMP (2 required per assembly)
		54-881530005 - Clamp [ More info ] $2.00 $1.69 2 In Stock.
#4	804162005	TUBING (1 required per assembly)
		32-804162005 - Tubing [ More info ] Unavailable
#5	56762	TIE STRAP @5 (2 required per assembly) — Replaces: 879650
#6	804162002	TUBING [1B226999] & Below (1 required per assembly)
		32-804162002 - Tubing [ More info ] Unavailable
#6	804162018	TUBING [1B227000] & Up (1 required per assembly)
		32-804162018 - Tubing [ More info ] Unavailable
#7	896354	CANISTER (1 required per assembly)
		896354 - Canister [ More info ] Unavailable
#8	881542004	HOLDER (1 required per assembly)
		881542004 - Holder [ More info ] $6.00 $5.08 2 In Stock.
#9	826957M	BOLT (1 required per assembly)
		10-826957M - Bolt, NLA [ More info ] $5.19 10+ In Stock.
#10	82214M	WASHER @5 (1 required per assembly)
		12-82214M - Washer - Priced Individually [ More info ] $5.28 10+ In Stock.
#11	881542005	BRACKET (1 required per assembly)
		881542005 - Bracket [ More info ] $8.00 $6.78 2 In Stock.
#12	804304	GROMMET (2 required per assembly)
		25-804304 - Grommet, NLA [ More info ] Unavailable
#13	811078M	COLLAR (2 required per assembly)
		23-811078M - Collar, NLA [ More info ] $2.00 $1.69 3 In Stock.
#14	804270	BOLT (2 required per assembly)
		10-804270 - Bolt [ More info ] Unavailable
#15	56762	TIE STRAP @5 (2 required per assembly)
#16	804162003	TUBING (1 required per assembly)
		32-804162003 - Tubing [ More info ] Unavailable
#17	8M0059039	CLAMP (1 required per assembly) — Replaces: 881530007
		548M0059039 - Clamp [ More info ] Unavailable
#18	84088M	BOLT (1 required per assembly)
		10-84088M - Bolt [ More info ] $3.40 5 In Stock.
#19	82214M	WASHER @5 (1 required per assembly)
#20	888279001	FILTER-FUEL (1 required per assembly)
		35-888279001 - Fuel Filter [ More info ] $91.49 Available to Order: Shipping delay up to 10 days.
#21	8M0059043	BRACKET (1 required per assembly) — Replaces: 881542003
		8M0059043 - Bracket [ More info ] $5.00 $4.24 3 In Stock.
#22	91772M	BOLT (1 required per assembly)
		10-91772M - Bolt [ More info ] $5.42 $4.59 10+ In Stock.
#23	82214M	WASHER @5 (1 required per assembly)
