Parts for 80 HP EFI 4-Stroke Mercury Outboard Motor Cylinder Block

Revise Search: Outboard > 4-Stroke Mercury Outboard > 80 HP EFI > 0P459572 - 2B094995 - Belgium > Cylinder Block

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Cylinder Block

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	897534A07	GASKET SET (1 required per assembly)
		27-897534A07 - Powerhead Gasket Set [ More info ] $365.99 Available to Order: Shipping delay up to 10 days.
#-	8M8033014	PH L4NA 4S (1 required per assembly) — Replaces: 897148A09
		8M8033014 - PH L4NA 4S [ More info ] Unavailable
#-	897148A08	PH L4NA 4S (1 required per assembly)
		61-897148A08 - Powerhead L4NA 4S [ More info ] Unavailable
#1	880504A12	CYLINDER BLOCK (1 required per assembly)
		800-880504A12 - Cylinder Block [ More info ] Unavailable
#2	8M0007889	BRACKET [1B759587] & Below (2 required per assembly)
		8M0007889 - Bracket [ More info ] $86.44 1 In Stock.
#3	8M0103815	SCREW NOTE:NO LONGER INCLUDED WITH LONGBLOCK [1B759587] & Below (4 required per assembly) — Replaces: 88552640
		108M0103815 - Screw - Priced Individually [ More info ] $4.09 1 In Stock.
#4	43044	PIN DOWEL - WITHOUT HOLE (.375 X .625) (2 required per assembly)
		17-43044 - Pin -Dowel-solid [ More info ] $2.49 1 In Stock.
#5	893392001	DAMPER (10 required per assembly)
		23-893392001 - Bushing [ More info ] $4.19 4 In Stock.
#6	8M0087448	PLUG @2 (5 required per assembly) — Replaces: 8M0047994
		198M0087448 - PLUG - Priced Individually [ More info ] $5.09 Available to Order: Shipping delay up to 10 days.
#7	896951	PLUG (24 MM) (2 required per assembly)
		19-896951 - Plug [ More info ] $16.39 1 In Stock.
#8	8M0087449	PLUG 14 MM (1 required per assembly) — Replaces: 8M0010474, 8M0048160
		198M0087449 - PLUG [ More info ] $4.29 Available to Order: Shipping delay up to 10 days.
#9	892573001	WASHER (10 required per assembly)
		12-892573001 - Washer - Priced Individually [ More info ] $2.39 Available to Order: Shipping delay up to 10 days.
#10	8M4501000	SCREW (M10 X 342) (10 required per assembly) — Replaces: 896923, 8M0021876
		108M4501000 - Screw [ More info ] $37.99 $36.16 6 In Stock.
#11	8M0000275	STUD (2 required per assembly) — Replaces: 897599
		16-8M0000275 - Stud [ More info ] $17.59 Available to Order: Shipping delay up to 10 days.
#12	826365	NUT (M8) (2 required per assembly)
		11-826365 - Nut (M8) [ More info ] $5.89 10+ In Stock.
#13	8M0010471	STUD @2 (6 required per assembly) — Replaces: 897677
		16-8M0010471 - Stud - Priced Individually [ More info ] $13.79 Available to Order: Shipping delay up to 10 days.
#14	856774	WASHER (.406 X .750 X .105) STAINLESS STEEL (6 required per assembly)
		12-856774 - Washer, (.406 X .750 X .105) Stainless Steel [ More info ] Unavailable
		128M0214963 - WASHER Note: Priced Individually [ More info ] $2.59 10+ In Stock.
#15	884412	NUT (6 required per assembly)
		11-884412 - Nut - Priced Individually [ More info ] $4.79 1 In Stock.
#16	8M0103829	SCREW (2 required per assembly) — Replaces: 892086120
		108M0103829 - Screw [ More info ] $17.89 Available to Order: Shipping delay up to 10 days.
#17	8M0193659	SCREW (2 required per assembly) — Replaces: 895810050
		10-8M0193659 - SCREW [ More info ] Unavailable
#18	8M0082988	SENSOR ASSY (1 required per assembly) — Replaces: 8283582, 8M0030022
		8M0082988 - Sensor Assembly [ More info ] $120.49 $115.99 In Stock
#19	40011106	SCREW (2 required per assembly)
		10-40011106 - Screw [ More info ] $1.70 Available to Order: Shipping delay up to 10 days.
#20	8M0148668	SENSOR-TEMP (1 required per assembly) — Replaces: 885342002
		8M0148668 - Temperature Sensor [ More info ] $48.39 In Stock
#21	896699	O-RING (1.78 MM X .08 MM) (1 required per assembly)
		25-896699 - O-ring, (1.78 Mm X .08 Mm) [ More info ] $12.49 Available to Order: Shipping delay up to 10 days.
#22	8M0024565	GASKET-HEAD [1B494360] & Up (1 required per assembly) — Replaces: 896277006
		27-8M0024565 - Cylinder Head To Block Gasket [ More info ] $230.99 Available to Order: Shipping delay up to 10 days.
#23	880559	GUIDE FIXED (1 required per assembly)
		880559 - Guide -fixed [ More info ] $46.49 Available to Order: Shipping delay up to 10 days.
#24	880557	GUIDE MOVEABLE (1 required per assembly)
		880557 - Guide -moveable [ More info ] $56.99 Available to Order: Shipping delay up to 10 days.
#25	892456045	SCREW @2 (2 required per assembly)
		10-892456045 - Screw - Priced Individually [ More info ] $2.79 Available to Order: Shipping delay up to 10 days.
#26	8M0024563	GASKET BLOCK TO ADAPTER [1B500084] & Up (1 required per assembly) — Replaces: 897534
		27-8M0024563 - Block To Adaptor Gasket [ More info ] $56.99 Available to Order: Shipping delay up to 10 days.
#27	891953	PLUG (1 required per assembly)
		19-891953 - Plug [ More info ] $19.99 Available to Order: Shipping delay up to 10 days.
#28	895810070	SCREW @2 (2 required per assembly)
		10-895810070 - Screw - Priced Individually [ More info ] $2.39 Available to Order: Shipping delay up to 10 days.
#29	895810090	SCREW @2 (8 required per assembly)
		10-895810090 - Screw - Priced Individually [ More info ] $4.09 Available to Order: Shipping delay up to 10 days.
