Parts for 75 HP Carb 4-Stroke Mercury Outboard Motor Flywheel

Revise Search: Outboard > 4-Stroke Mercury Outboard > 75 HP Carb > 0G960500 - 0T800999 - USA > Flywheel

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Flywheel

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	804070T03	PH 75/90 4S [0T178500] & Up (1 required per assembly) — Replaces: 804070T2, 804070T02
		804070T03 - PH 75/90 4S [ More info ] Unavailable
		804070T04 - PH 75/90 4S [ More info ] Unavailable
		804070T05 - Powerhead 75/90 4S [ More info ] Unavailable
#-	883548T02	PH 75/904SBACKFIT [0T178499] & Below (1 required per assembly)
		883548T02 - 75/90 Crankcase & Cylinder Block Assembly [ More info ] Unavailable
#1	881343T1	COVER-FLYWHEEL (1 required per assembly) — Replaces: 804268T
		881343T 1 - Flywheel Cover [ More info ] Unavailable
#2	NSS	NOT SOLD SEPARATE DECAL-WARNING-SPINNING FLYWHEEL (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#3	NSS	NOT SOLD SEPARATE DECAL-SERVICING REFERRAL (1 required per assembly)
#4	NSS	NOT SOLD SEPARATE DECAL-ENGINE OIL/VALVE (1 required per assembly)
#5	804656A00	REF SOB 09-18 (2000) (1 required per assembly)
		37-804656A00 - REF OB SB 09-18,NLA [ More info ] Unavailable
#5	804656A01	REF SOB 09-18 (2001) (1 required per assembly)
		37-804656A01 - REF OB SB 09-18,NLA [ More info ] Unavailable
#5	804656A02	REF SOB 09-18 (2002) (1 required per assembly)
		37-804656A02 - REF OB SB 09-18,NLA [ More info ] Unavailable
#5	804656A03	REF SOB 09-18 (2003) (1 required per assembly)
		37-804656A03 - REF OB SB 09-18,NLA [ More info ] Unavailable
#6	NSS	NOT SOLD SEPARATE DECAL-EMERGENCY (1 required per assembly)
#7	804348	BOLT (2 required per assembly)
		10-804348 - Bolt [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#8	825665	COLLAR (4 required per assembly)
		825665 - Collar [ More info ] $5.00 $4.24 2 In Stock.
#9	11416T	GROMMET (2 required per assembly) — Replaces: 11416M
		25-11416T - Grommet [ More info ] $5.99 Available to Order: Shipping delay up to 10 days.
#10	804265A1	NUT/WASHER KIT [0T599000] & Up (1 required per assembly) — Replaces: 804265
		11-804265A 1 - Nut/Washer Kit [ More info ] Unavailable
#11	8042641	WASHER PLATE [0T599000] & Up (1 required per assembly)
		12-804264 1 - Washer [ More info ] $11.89 Available to Order: Shipping delay up to 10 days.
#11	804265A1	NUT/WASHER KIT [0T598999] & Below (1 required per assembly) — Replaces: 804264
#12	804261T	FLYWHEEL (1 required per assembly)
		280-804261T - Flywheel [ More info ] Unavailable
#13	NSS	NOT SOLD SEPARATE DECAL-WARNING NEUTRAL (1 required per assembly)
#14	804262T	STATOR KIT (1 required per assembly)
		398-804262T - Stator Kit [ More info ] Unavailable
#15	825010	PIN-DOWEL (2 required per assembly)
		17-825010 - Pin -Dowel [ More info ] $4.19 2 In Stock.
#16	804124	BOLT (4 required per assembly)
		10-804124 - Bolt, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#17	82212M	LOCKWASHER @5 (4 required per assembly)
		13-82212M - LockWasher - Priced Individually [ More info ] $1.10 10+ In Stock.
#18	82214M	WASHER @5 (4 required per assembly)
		12-82214M - Washer - Priced Individually [ More info ] $5.28 10+ In Stock.
#19	804267	SCREW (1 required per assembly)
		10-804267 - Screw [ More info ] $1.10 $0.94 10+ In Stock.
#20	804266001	PLATE-TIMING (1 required per assembly) — Replaces: 804266
		804266001 - Timing Plate [ More info ] $1.50 $1.28 10 In Stock.
#21	804263	ROTOR (1 required per assembly)
		804263 - Rotor [ More info ] Unavailable
