Parts for 50 HP EFI 4 Cyl 4-Stroke Mercury Outboard Motor Gear Housing Propeller Shaft - 2.33:1 Gear Ratio

Revise Search: Outboard > 4-Stroke Mercury Outboard > 50 HP EFI 4 Cyl > 1C050252 - 1C453839 - USA > Gear Housing Propeller Shaft - 2.33:1 Gear Ratio

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Gear Housing Propeller Shaft - 2.33:1 Gear Ratio

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	8M0118186	GC 40-60 LG (1 required per assembly) — Replaces: 893681T02
		16008M0118186 - GC 40-60 LG [ More info ] Unavailable
#-	8M0118188	GC SEAPRO X LONG (1 required per assembly) — Replaces: 8M0053765
		16008M0118188 - GC SEAPRO X LONG [ More info ] Unavailable
#-	43035A05	SEAL KIT-G/H (1 required per assembly)
		26-43035A05 - Gear Housing Seal Kit [ More info ] $113.99 Available to Order: Shipping delay up to 10 days.
#-	882813A3	GEAR KIT-FORWARD (1 required per assembly)
		43-882813A 3 - Forward Gear Kit [ More info ] $770.99 Available to Order: Shipping delay up to 10 days.
#-	803496T2	REPAIR KIT (1 required per assembly)
		31-803496T 2 - Repair Kit [ More info ] $249.49 Available to Order: Shipping delay up to 10 days.
#-	888805A00	CLUTCH/CAMFOLLOW (1 required per assembly)
		52-888805A00 - Clutch/Camfollow [ More info ] $277.49 Available to Order: Shipping delay up to 10 days.
#1	8M0118594	GEAR HOUSING ASSEMBLY BASIC (1 required per assembly) — Replaces: 893681T04
		16008M0118594 - Gearcase BASIC ASSY - N [ More info ] $1,569.49 Available to Order: Shipping delay up to 10 days.
#2	8227731	INSERT THREADED (2 required per assembly)
		822773 1 - Insert [ More info ] $4.59 Available to Order: Shipping delay up to 10 days.
#3	899070	FOLLOWER CAM (1 required per assembly)
		899070 - Cam Follower [ More info ] $44.49 Available to Order: Shipping delay up to 10 days.
#4	8M4504018	CAM SHIFT (1 required per assembly) — Replaces: 19917
		8M4504018 - CAM-SHIFT [ More info ] $26.99 Available to Order: Shipping delay up to 10 days.
#5	888806	ROD CLUTCH ACTUATOR (1 required per assembly)
		888806 - Clutch Actuator Rod [ More info ] $45.99 Available to Order: Shipping delay up to 10 days.
#6	8M0084243	PIN CROSS (1 required per assembly) — Replaces: 78905
		178M0084243 - Pin - CROSS [ More info ] $6.99 Available to Order: Shipping delay up to 10 days.
#7	8M0084245	PIN SPRING LOCATOR SPRING LOCATOR (1 required per assembly) — Replaces: 78906
		178M0084245 - Locator Pin [ More info ] $3.69 Available to Order: Shipping delay up to 10 days.
#8	79910	SPRING (1 required per assembly)
		24-79910 - Spring, Compression [ More info ] $8.19 Available to Order: Shipping delay up to 10 days.
#9	78910	WASHER (1 required per assembly)
		12-78910 - Washer, Compression Spring [ More info ] $1.99 10+ In Stock.
#10	8M0063266	SHIM SET (1 required per assembly) — Replaces: 44491A1
		15-8M0063266 - Shim Set [ More info ] $52.99 $50.80 10+ In Stock.
#11	30894A1	BEARING SET CUP AND CONE (1 required per assembly)
		31-30894A 1 - Tapered Roller Bearing [ More info ] $60.49 Available to Order: Shipping delay up to 10 days.
		18-1156 - Bearing 31-30894A1 [ More info ] $52.99 $50.19 In Stock
		31-01906 - Bearing, Mercury 30894A1, Honda 91051-ZW1-003 [ More info ] $43.99 $40.77 In Stock
#12	NSS	NOT SOLD SEPARATE CUP (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#13	882813A3	GEAR KIT FORWARD AND PINION 28 TEETH (1 required per assembly)
#14	30895T	BEARING NEEDLE (1 required per assembly)
		31-30895T - Bearing - Roller [ More info ] $20.79 Available to Order: Shipping delay up to 10 days.
#15	856823	RING RETAINING (1 required per assembly)
		53-856823 - Ring - Retaining [ More info ] $10.99 2 In Stock.
#16	888805T	CLUTCH (1 required per assembly)
		52-888805T - Clutch [ More info ] $341.99 Available to Order: Shipping delay up to 10 days.
#17	8M0140444	SHAFT PROPELLER (1 required per assembly) — Replaces: 888804
		448M0140444 - Prop Shaft [ More info ] $738.49 Available to Order: Shipping delay up to 10 days.
#18	30893	SPRING (1 required per assembly)
		24-30893 - Spring, Reatiner - Cross Pin [ More info ] $2.69 3 In Stock.
#19	889990T	GEAR REVERSE (1 required per assembly)
		43-889990T - Reverse Gear [ More info ] $366.99 Available to Order: Shipping delay up to 10 days.
#20	8M0168901	CARRIER ASSY. (1 required per assembly) — Replaces: 12596T2
		8M0168901 - Carrier Bearing [ More info ] $311.99 Available to Order: Shipping delay up to 10 days.
#21	861844	O-RING (1 required per assembly)
		25-861844 - O-Ring [ More info ] Unavailable
		18-7961 - O-Ring 25-97386 [ More info ] $4.41 1 In Stock.
		25-8M0214974 - O-Ring [ More info ] $8.19 3 In Stock.
#22	30956T	BEARING NEEDLE (1 required per assembly)
		31-30956T - Roller Bearing [ More info ] $19.88 1 In Stock.
#23	8M0205728	SEAL INNER (1 required per assembly) — Replaces: 70080
		26-8M0205728 - Seal [ More info ] $20.83 2 In Stock.
#24	8M0205729	SEAL OUTER (1 required per assembly) — Replaces: 70081
		26-8M0205729 - Gear Housing Outer Oil Seal, Outboard [ More info ] $22.96 3 In Stock.
#25	12578T	BEARING ROLLER (1 required per assembly)
		31-12578T - Roller Bearing [ More info ] $33.99 Available to Order: Shipping delay up to 10 days.
		18-1113 - Bearing 31-12578 [ More info ] $27.49 In Stock
#26	12577	THRUST WASHER (1 required per assembly)
		12-12577 - Washer, Thrust [ More info ] $13.39 Available to Order: Shipping delay up to 10 days.
#27	12576	BEARING THRUST (1 required per assembly)
		31-12576 - Thrust Bearing [ More info ] $27.29 Available to Order: Shipping delay up to 10 days.
#28	8M0034456	STUD (M8 X 1.25 X 48) (2 required per assembly) — Replaces: 429172
		16-8M0034456 - Stud [ More info ] $6.39 Available to Order: Shipping delay up to 10 days.
#29	855941	WASHER (.323 X .590 X .112) STAINLESS STEEL (2 required per assembly)
		12-855941 - Washer, (.323 X .590 X .112) Stainless Steel [ More info ] $1.50 Available to Order: Shipping delay up to 10 days.
#30	401378	NUT (M8) (2 required per assembly)
		11-40137 8 - Nut [ More info ] $10.39 Available to Order: Shipping delay up to 10 days.
#31	NSS	NOT SOLD SEPARATE DECAL-GEARCASE PINION IDENTIFICATION (1 required per assembly)
