Parts for 50 HP Carb Bigfoot 4-Stroke Mercury Outboard Motor Swivel Bracket
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 19608A14 | STEERING KIT-R/G NON HANDLE (1 required per assembly) — Replaces: 196081 |
  |
|
19608A14 - Engine Steering Attaching Kit [ More info ]
|
| #2 | 823919 | SCREW @5 NON HANDLE (1 required per assembly) |
  |
|
10-823919 - Screw - Priced Individually [ More info ]
|
| #3 | 8M0109680 | WASHER NON HANDLE (1 required per assembly) — Replaces: 71970 |
  |
|
128M0109680 - Washer [ More info ]
|
| #4 | 37828 | WASHER NON HANDLE (2 required per assembly) |
  |
|
12-37828 - Washer, (.390 X .625 X .062) Stainless Steel [ More info ]
|
| #5 | 8M0042636 | NUT-BRASS @3 NON HANDLE (2 required per assembly) — Replaces: 34863, 826709113 |
  |
11-8M0042636 - Nut - Brass , Priced Individually [ More info ] Unavailable |
|
  |
|
118M0204726 - NUT-BRASS Note: Priced Individually [ More info ]
|
| #6 | 822397 | PUCK-CO PILOT (1 required per assembly) |
  |
|
822397 - Co Pilot Puck [ More info ]
|
| #7 | 8217711 | BUSHING (1 required per assembly) |
  |
|
23-821771 1 - Bushing [ More info ]
|
| #8 | 850066T01 | SWIVEL BRACKET ASSEMBLY-PAINT (GRAY) BIGFOOT (1 required per assembly) — Replaces: 850066A1, 850066A2 |
  |
|
1401-850066T01 - Swivel Bracket As [ More info ]
|
| #9 | 19606 | BEARING BIGFOOT (2 required per assembly) |
  |
|
23-19606 - Bearing - Trim Pin [ More info ]
|
| #10 | 8M0169589 | FITTING GREASE BIGFOOT (2 required per assembly) — Replaces: 74036 |
  |
|
228M0169589 - Fitting Note: Priced Individually [ More info ]
|
| #11 | 827402T5 | SWIVEL BRACKET-BL (BLACK-NON-BIGFOOT) [0G438000] & Up (1 required per assembly) — Replaces: 827402A1, 827402T1 |
  |
|
3410-827402T 5 - Swivel Bracket -bl [ More info ] Unavailable |
| #11 | 827402T6 | ORD 3410-827402T5 (GRAY-NON-BIGFOOT) [0G438000] & Up (1 required per assembly) — Replaces: 827402A2, 827402T2 |
  |
|
3410-827402T 6 - ORD3410-827402T, NLA [ More info ] Unavailable |
| #11 | 827402T1 | BRKT-SWIVEL-BLACK (BLACK-NON-BIGFOOT) [0G437999] & Below (1 required per assembly) — Replaces: 827402F1, 827402A1 |
  |
3410-827402T 1 - Swivel Bracket, Black [ More info ] Unavailable |
|
| #11 | 827402T2 | BRKT-SWIVEL-GRAY (GRAY-NON-BIGFOOT) [0G437999] & Below (1 required per assembly) — Replaces: 827402F2, 827402A2 |
  |
3410-827402T 2 - Swivel Bracket, Gray [ More info ] Unavailable |
|
| #12 | 821777 | BUSHING (LOWER) (BIGFOOT) (1 required per assembly) |
  |
|
23-821777 - Bushing [ More info ]
|
| #12 | 821777T1 | BUSHING (LOWER) (NON-BIGFOOT) [0G437999] & Below (1 required per assembly) — Replaces: 8217771 |
  |
|
23-821777T 1 - Bushing,NLA [ More info ] Unavailable |
| #13 | 8M0169589 | FITTING @2 (AR required per assembly) — Replaces: 74036 |
| #14 | 19624A1 | SEAL KIT NON HANDLE (1 required per assembly) |
  |
|
19624A 1 - Seal Kit [ More info ]
|
| #15 | 29619 | O-RING (.583 X .103) NON HANDLE (1 required per assembly) |
  |
|
25-29619 - O-ring, (.583 X .103) [ More info ]
|
| #16 | 78861 | SPACER NON HANDLE (1 required per assembly) |
  |
|
23-78861 - Spacer [ More info ]
|
| #17 | 822404 | SEAL (1 required per assembly) |
  |
26-822404 - Seal [ More info ] Unavailable |
|
  |
|
268M0205512 - SEAL [ More info ]
|
| #18 | 19619 | WASHER (1 required per assembly) |
  |
|
12-19619 - Washer [ More info ]
|
| #19 | 858869 | NUT @5 (1 required per assembly) — Replaces: 30499 |
  |
|
11-858869 - Nut, (.875-14) [ More info ]
|
| #20 | 4008910 | SCREW (HANDLE) (1 required per assembly) |
  |
|
10-40089 10 - Screw [ More info ]
|
| #20 | 40011149 | SCREW NON HANDLE (1 required per assembly) |
  |
|
10-40011149 - Screw [ More info ]
|
| #21 | 8282451 | SEAL NON HANDLE (1 required per assembly) |
  |
|
828245 1 - Seal [ More info ] Unavailable |
| #22 | 19619 | WASHER (1 required per assembly) |
| #23 | 8M0035070 | TILT TUBE (1 required per assembly) — Replaces: 19614, 196141 |
  |
8M0035070 - Tilt Tube [ More info ] Unavailable |
|
  |
|
8M0041938 - Tilt Tube [ More info ]
|
| #24 | 858869 | NUT @5 (1 required per assembly) — Replaces: 30499 |
| #25 | 821539 | PIN-TRILOBE (1 required per assembly) |
  |
|
17-821539 - Pin, Trilobe, Groove [ More info ]
|
| #26 | 823507 | BUSHING NON-BIGFOOT (2 required per assembly) |
  |
|
23-823507 - Bushing [ More info ]
|
| #27 | 822480 | PIN PIVOT (UPPER) NON-BIGFOOT (1 required per assembly) |
  |
|
17-822480 - Pivot Pin [ More info ]
|
| #28 | 822869001 | PIN-TRIM (BIGFOOT) (1 required per assembly) — Replaces: 822869 |
  |
|
17-822869001 - Pin, Upper [ More info ]
|
