Parts for 45 HP Carb Bodensee 4-Stroke Mercury Outboard Motor Carburetor (40 / 50)

Revise Search: Outboard > 4-Stroke Mercury Outboard > 45 HP Carb Bodensee > 0G760300 - 0T178499 - USA > Carburetor (40 / 50)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Carburetor (40 / 50)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	809594A1	REPAIR KIT-CARB (One Kit per Carburetor) (1 required per assembly)
		809594A 1 - Carburetor Repair Kit [ More info ] $139.99 10 In Stock.
#1	825073T11	CARBURETOR (1) (1 required per assembly)
		3319-825073T11 - Carburetor [ More info ] Unavailable
#2	825073T12	CARBURETOR (2) (1 required per assembly)
		3319-825073T12 - Carburetor [ More info ] Unavailable
#3	825073T13	CARBURETOR (3) (1 required per assembly) — Replaces: 825073A13
		3319-825073T13 - Carburetor [ More info ] Unavailable
#4	8M0059473	CARBURETOR (4) (1 required per assembly) — Replaces: 825073A14
		33198M0059473 - Carburetor [ More info ] Unavailable
#5	809571	SCREW (M4 X 10) (8 required per assembly)
		10-809571 - Screw [ More info ] $2.30 $1.96 10 In Stock.
#6	809572	COVER (1) (1 required per assembly)
		809572 - Cover [ More info ] Unavailable
#7	809573	GASKET (4 required per assembly)
		809573 - Gasket [ More info ] Unavailable
#8	826943M	WASHER (1/2/3) (3 required per assembly)
		12-826943M - WASHER,NLA [ More info ] Unavailable
#9	8095791	SPRING (1/2/3) (3 required per assembly)
		24-809579 1 - Spring [ More info ] $5.37 1 In Stock.
#10	8095781	SCREW THROTTLE (1/2/3) (3 required per assembly)
		10-809578 1 - Screw - Throttle [ More info ] $11.70 2 In Stock.
#11	809580	WASHER (4 required per assembly)
		12-809580 - Washer,NLA [ More info ] $1.25 $1.06 2 In Stock.
#12	94722M	RING RETAINING (4 required per assembly)
		53-94722M - Ring - Retaining, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#13	809582	LEVER (1) (1 required per assembly)
		809582 - Lever [ More info ] Unavailable
#14	92515M	LOCKWASHER (1) (1 required per assembly)
		13-92515M - LockWasher, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#15	809581	NUT (1) (1 required per assembly)
		11-809581 - Nut, NLA [ More info ] $1.50 $1.28 10 In Stock.
#16	809570	NEEDLE VALVE (4 required per assembly)
		809570 - Needle Valve [ More info ] $29.19 Available to Order: Shipping delay up to 10 days.
#17	8095711	SCREW (M4 X 5) (4 required per assembly)
		10-809571 1 - Screw, NLA [ More info ] $1.98 $1.68 10+ In Stock.
#18	809574	MAIN NOZZLE (4 required per assembly)
		809574 - Main Nozzle [ More info ] Unavailable
#19	11802M	O-RING (4 required per assembly)
		25-11802M - O-Ring [ More info ] $3.39 9 In Stock.
#20	809577	MAIN NOZZLE (4 required per assembly)
		809577 - Main Nozzle [ More info ] $10.00 $8.47 5 In Stock.
#21	8095761	JET PILOT (#42) (4 required per assembly) — Replaces: 809576
		809576 1 - Jet -Pilot [ More info ] Unavailable
#22	809575	JET MAIN (#112) (4 required per assembly)
		809575 - Main Jet [ More info ] Unavailable
#23	809569	FLOAT (4 required per assembly)
		809569 - Float [ More info ] $29.99 $25.39 1 In Stock.
		18-7380 - Float, 809569 [ More info ] $18.53 In Stock
#24	11794M	PIN (4 required per assembly)
		17-11794M - Pin, Float [ More info ] $6.99 $5.91 10+ In Stock.
#25	809568	GASKET (4 required per assembly)
		27-809568 - Gasket [ More info ] Unavailable
#26	809567	BODY (1/2/3) (3 required per assembly)
		809567 - Body [ More info ] Unavailable
#27	81758M	SCREW (M4 X 12) (16 required per assembly)
		10-81758M - Screw - Priced Individually [ More info ] $2.79 Available to Order: Shipping delay up to 10 days.
#28	8095783	SCREW DRAIN (M5 X 6) (4 required per assembly)
		10-809578 3 - Drain Screw [ More info ] Unavailable
#29	8095681	GASKET (4 required per assembly)
		27-809568 1 - Gasket [ More info ] Unavailable
#30	8095721	COVER (2) (1 required per assembly)
		809572 1 - Cover [ More info ] Unavailable
#31	809584	CLIP (2) (1 required per assembly)
		53-809584 - Clip, NLA [ More info ] $2.04 $1.72 10+ In Stock.
#32	809585	ROLLER (2) (1 required per assembly)
		809585 - Roller [ More info ] Unavailable
#33	8095721	COVER (3) (1 required per assembly)
#34	11829M	RETAINER (4) (1 required per assembly)
		11829M - Retainer - (Black) [ More info ] $16.89 Available to Order: Shipping delay up to 10 days.
#35	809586	ROD STARTER (4) (1 required per assembly)
		809586 - Starter Rod, NLA [ More info ] $4.00 $3.39 10 In Stock.
#36	809587	JOINT (4) (1 required per assembly)
		809587 - Joint - (Blue) [ More info ] $3.59 Available to Order: Shipping delay up to 10 days.
#37	8095781	SCREW THROTTLE (4) (2 required per assembly)
#38	8095791	SPRING (4) (3 required per assembly)
#39	8095721	COVER (4) (1 required per assembly)
#40	8095712	SCREW (4) (1 required per assembly)
		10-809571 2 - Screw, NLA [ More info ] $1.50 $1.28 10+ In Stock.
#41	8095801	WASHER (4) (1 required per assembly)
		12-809580 1 - Washer, NLA [ More info ] $1.50 $1.28 10+ In Stock.
#42	8095821	LEVER (4) (1 required per assembly)
		809582 1 - Lever [ More info ] $4.35 $3.68 10 In Stock.
#43	826931M	SCREW (4) (1 required per assembly)
		10-826931M - Screw -thottle [ More info ] Unavailable
#44	8095671	BODY (4) (1 required per assembly)
		809567 1 - Body [ More info ] Unavailable
#45	855237	PLUG (1 required per assembly) — Replaces: 809583
		19-855237 - Plug , NLA [ More info ] $2.14 10+ In Stock.
