Parts for 300 (3.0L EFI) Promax 2-Stroke EFI Mercury Outboard Motor Instrumentation

Revise Search: Outboard > 2-Stroke EFI Mercury Outboard > 300 (3.0L EFI) Promax > 0G610221 - 0T105297 - USA > Instrumentation

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Instrumentation

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	93953A1	GAUGE-TACH-10000 (1 required per assembly)
		79-93953A 1 - GAUGE-TACH-10000,NLA [ More info ] Unavailable
#2	79101T	BRACKET (1 required per assembly)
		79101T - Mounting Bracket, NLA [ More info ] Unavailable
#3	72729	LIGHT BULB WEDGE BASE (14V - 1.9W) (1 required per assembly)
		88-72729 - Bulb [ More info ] $5.89 10+ In Stock.
#4	79888	SOCKET LIGHT BULB (1 required per assembly)
		88-79888 - Socket [ More info ] $2.00 $1.12 10+ In Stock.
#5	26419	NUT (#8-32) BRASS (5 required per assembly)
		11-26419 - Nut (#8-32) (brass) [ More info ] $1.70 10+ In Stock.
#6	86322A7	WIRE ASSY (1 required per assembly)
		84-86322A 7 - Wire Assembly [ More info ] Unavailable
#6	86323A5	WIRE ASSY (1 required per assembly)
		84-86323A 5 - Wire Assembly [ More info ] Unavailable
#7	895292Q41	GAUGE PWR TRIM (1 required per assembly) — Replaces: 825338A3
		79-895292Q41 - Power Trim Gauge [ More info ] Unavailable
#8	79480	BRACKET (1 required per assembly)
		79480 - Mounting Bracket [ More info ] Unavailable
#9	72729	LIGHT BULB WEDGE BASE (14V - 1.9W) (1 required per assembly)
#10	79888	SOCKET LIGHT BULB (1 required per assembly)
#11	26419	NUT (#8-32) BRASS (5 required per assembly)
#12	68878A6	HORN ASSY (1 required per assembly)
		68878A 6 - Horn Assembly [ More info ] $79.99 7 In Stock.
#13	68879	COVER (1 required per assembly)
		68879 - Cover [ More info ] Unavailable
#14	8M0084588	SPACER (2 required per assembly) — Replaces: 79697
		238M0084588 - Spacer [ More info ] $1.30 Available to Order: Shipping delay up to 10 days.
#15	26427	WASHER (2 required per assembly)
		12-26427 - Washer [ More info ] $1.00 $0.85 10+ In Stock.
#16	35401	SCREW @5 (2 required per assembly)
		10-35401 - Screw - Priced Individually [ More info ] Unavailable
#17	86396A8	HARNESS KIT (1 required per assembly)
		84-86396A 8 - Harness Kit [ More info ] $58.08 7 In Stock.
#18	858654A4	GAUGE-WATER-30PSI (1 required per assembly) — Replaces: 825331A1, 858654A1
		79-858654A 4 - Water Gauge, 30PSI [ More info ] Unavailable
		79-895288Q43 - Gauge Water Pressure Kit [ More info ] Unavailable
#19	72729	LIGHT BULB WEDGE BASE (14V - 1.9W) (1 required per assembly)
#20	825362	SOCKET (1 required per assembly)
		88-825362 - SOCKET,NLA [ More info ] Unavailable
#21	825363	BRACKET (1 required per assembly)
		825363 - Bracket, NLA [ More info ] Unavailable
#22	88532A1	CABLE ASSEMBLY (2.00 FEET) DARK BLUE (1 required per assembly)
		84-88532A 1 - Cable Assembly, NLA [ More info ] Unavailable
#22	86322A16	CABLE ASSEMBLY (2.00 FEET) BLACK (1 required per assembly)
		84-86322A16 - Cable Assembly [ More info ] Unavailable
#23	64088A09	TUBING-50 FT BULK (1 required per assembly) — Replaces: 640886
		32-64088A09 - Tubing - 50 Ft Bulk [ More info ] $69.25 Available to Order: Shipping delay up to 10 days.
#24	816311T	TIE STRAP (8.00 INCHES) (5 required per assembly) — Replaces: 816311
		54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ] $0.60 10+ In Stock.
#25	63670	FITTING (2 required per assembly)
		22-63670 - Fitting [ More info ] $6.45 10+ In Stock.
#26	63651	ELBOW (90 DEGREES) (2 required per assembly)
		22-63651 - Elbow, NLA [ More info ] $6.00 $5.08 10+ In Stock.
#27	77863	FITTING (1 required per assembly)
		22-77863 - Fitting [ More info ] $4.00 $3.39 10+ In Stock.
#28	64706001	FITTING TEE (1 required per assembly) — Replaces: 64706
		22-64706001 - Fitting [ More info ] $35.54 Available to Order: Shipping delay up to 10 days.
#29	36492	BUSHING-REDUCER (1 required per assembly)
		22-36492 - Reducer Bushing [ More info ] $24.49 $23.44 10+ In Stock.
#30	19674A1	SWITCH ASSEMBLY (1 required per assembly)
		87-19674A 1 - Switch Assembly [ More info ] Unavailable
#31	18303	SCREW (2 required per assembly)
		10-18303 - Screw [ More info ] $1.10 Available to Order: Shipping delay up to 10 days.
#32	813679	ADAPTOR (1 required per assembly)
		813679 - Adaptor [ More info ] $11.19 3 In Stock.
#33	15920Q54	ORDER 8M0092850 (1 required per assembly) — Replaces: 15920A54
		15920Q54 - Stop Switch Lanyard- Priced Individually [ More info ] Unavailable
#34	32866	SCREW @5 (2 required per assembly)
		10-32866 - Screw - Priced Individually [ More info ] $1.70 $0.34 10+ In Stock.
#35	18321	CLAMP (1 required per assembly)
		18321 - Clamp [ More info ] $7.19 Available to Order: Shipping delay up to 10 days.
#36	24676	WASHER (2 required per assembly)
		12-24676 - Washer, (.200 X .440 X .032) [ More info ] $1.50 10+ In Stock.
#37	68219	NUT @5 (4 required per assembly)
		11-68219 - Nut (#10-32) [ More info ] $2.99 10+ In Stock.
#38	79146	RETAINER (3 required per assembly)
		79146 - Retainer [ More info ] $5.59 2 In Stock.
#39	816311T	TIE STRAP @100 (AR required per assembly) — Replaces: 816311
#40	898289A72	DIODE KIT-LANYARD (1 required per assembly) — Replaces: 812497A2
		84-898289A72 - Lanyard Diode Kit [ More info ] $65.38 Available to Order: Shipping delay up to 10 days.
#41	11149A2	CABLE ASSY (1 required per assembly)
		84-11149A 2 - Cable Assembly [ More info ] $34.13 5 In Stock.
