Parts for 40 HP Carb 4 Cyl 4-Stroke Mercury Outboard Motor Swivel Bracket

Revise Search: Outboard > 4-Stroke Mercury Outboard > 40 HP Carb 4 Cyl > 0T178500 - 0T598999 - USA > Swivel Bracket

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Swivel Bracket

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	19608A14	STEERING KIT-R/G (ELECTRIC NON HANDLE) (1 required per assembly)
		19608A14 - Engine Steering Attaching Kit [ More info ] $210.97 Available to Order: Shipping delay up to 10 days.
#2	823919	SCREW (.375-24 X 1.500) (ELECTRIC NON HANDLE) (1 required per assembly)
		10-823919 - Screw - Priced Individually [ More info ] $6.69 2 In Stock.
#3	8M0109680	WASHER (.39 X .546 X.12) (ELECTRIC NON HANDLE) (1 required per assembly) — Replaces: 71970
		128M0109680 - Washer [ More info ] $1.50 Available to Order: Shipping delay up to 10 days.
#4	37828	WASHER (.390 X .625 X .062) STAINLESS STEEL (ELECTRIC NON HANDLE) (2 required per assembly)
		12-37828 - Washer, (.390 X .625 X .062) Stainless Steel [ More info ] $0.80 2 In Stock.
#5	8M0204726	NUT-BRASS @3 (ELECTRIC NON HANDLE) (2 required per assembly) — Replaces: 826709113, 8M0042636
		118M0204726 - NUT-BRASS Note: Priced Individually [ More info ] $1.80 10 In Stock.
#6	822397	PUCK-CO PILOT (ELECTRIC NON HANDLE) (1 required per assembly)
		822397 - Co Pilot Puck [ More info ] $17.69 Available to Order: Shipping delay up to 10 days.
#7	8217711	BUSHING (1 required per assembly)
		23-821771 1 - Bushing [ More info ] $42.49 Available to Order: Shipping delay up to 10 days.
#8	850066T01	SWIVEL BRACKET ASSEMBLY-PAINT (1 required per assembly) — Replaces: 850066A1
		1401-850066T01 - Swivel Bracket As [ More info ] $1,148.99 Available to Order: Shipping delay up to 10 days.
#9	19606	BEARING (2 required per assembly)
		23-19606 - Bearing - Trim Pin [ More info ] Unavailable
#10	8M0169589	FITTING GREASE (QTY. OF 3 REQUIRED ON HANDLE VERSIONS) (2 required per assembly) — Replaces: 74036
		228M0169589 - Fitting Note: Priced Individually [ More info ] $4.79 1 In Stock.
#11	8237011	DECAL-CO PILOT (HANDLE) (1 required per assembly)
		37-823701 1 - Decal -co Pilot [ More info ] $2.59 Available to Order: Shipping delay up to 10 days.
#12	NSS	NOT SOLD SEPARATE DECAL (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#13	821777	BUSHING (LOWER) (1 required per assembly)
		23-821777 - Bushing [ More info ] $28.29 Available to Order: Shipping delay up to 10 days.
#14	822404	SEAL (1 required per assembly)
		26-822404 - Seal [ More info ] Unavailable
		268M0205512 - SEAL [ More info ] $17.29 Available to Order: Shipping delay up to 10 days.
#15	4008910	SCREW (HANDLE) (1 required per assembly)
		10-40089 10 - Screw [ More info ] $4.79 Available to Order: Shipping delay up to 10 days.
#15	40011149	SCREW (NON-HANDLE) (1 required per assembly)
		10-40011149 - Screw [ More info ] $2.69 Available to Order: Shipping delay up to 10 days.
#16	8282451	SEAL (NON-HANDLE) (1 required per assembly)
		828245 1 - Seal [ More info ] Unavailable
