Parts for 4 HP Carb 4-Stroke Mercury Outboard Motor Shift Components

Revise Search: Outboard > 4-Stroke Mercury Outboard > 4 HP Carb > 0R411838 & Up - USA > Shift Components

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Shift Components

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	8M0056380	SHIFT LEVR SHAFT (1 required per assembly)
		8M0056380 - Shift Lever Shaft [ More info ] $44.99 Available to Order: Shipping delay up to 10 days.
#2	812937	BEARING-BALL (1 required per assembly)
		30-812937 - Ball Bearing [ More info ] $17.79 Available to Order: Shipping delay up to 10 days.
#3	8M0056349	SPRING (1 required per assembly)
		248M0056349 - Spring [ More info ] $4.19 Available to Order: Shipping delay up to 10 days.
#4	16181	O RING (2 required per assembly)
		25-16181 - O-ring, Shift Lever [ More info ] $4.99 Available to Order: Shipping delay up to 10 days.
#5	16188	PIN (1 required per assembly)
		17-16188 - Pin, Shift Lever [ More info ] $7.29 Available to Order: Shipping delay up to 10 days.
#6	16189	PIN-COTTER (1 required per assembly)
		18-16189 - Cotter Pin [ More info ] $2.99 Available to Order: Shipping delay up to 10 days.
#7	16185	BOLT (1 required per assembly)
		10-16185 - Bolt [ More info ] $4.59 1 In Stock.
#8	16184	LEVER-SHIFT (1 required per assembly)
		16184 - Shift Lever [ More info ] $17.79 Available to Order: Shipping delay up to 10 days.
#9	16186	ROD-SHIFT-SHORT Short (1 required per assembly)
		16186 - Shift Rod - Short, NLA [ More info ] $33.29 $7.98 3 In Stock.
#9	8M0056348	SHIFT ROD LONG Long or Extra Long (1 required per assembly)
		8M0056348 - Shift Rod LONG [ More info ] $39.99 Available to Order: Shipping delay up to 10 days.
#10	16826	WASHER (1 required per assembly)
		12-16826 - Washer, Stainless Steel [ More info ] $3.29 Available to Order: Shipping delay up to 10 days.
#11	16190	JOINT SET (1 required per assembly)
		16190 - Joint [ More info ] $25.99 Available to Order: Shipping delay up to 10 days.
#12	8248324	SCREW @5 (1 required per assembly)
		10-824832 4 - Screw [ More info ] $1.80 5 In Stock.
#13	8M0085389	SHIFT LVR ROD (1 required per assembly) — Replaces: 8M0056350
		8M0085389 - Shift Lever Rod [ More info ] $32.59 Available to Order: Shipping delay up to 10 days.
#14	8M0021224	CLIP (1 required per assembly)
		54-8M0021224 - Clip [ More info ] $11.39 Available to Order: Shipping delay up to 10 days.
#15	8M0056351	PIN (1 required per assembly)
		178M0056351 - Pin [ More info ] $10.69 Available to Order: Shipping delay up to 10 days.
