Parts for 4 HP Carb 4-Stroke Mercury Outboard Motor Gear Housing Driveshaft

Revise Search: Outboard > 4-Stroke Mercury Outboard > 4 HP Carb > 0P401000 - 0R411837 - Belgium > Gear Housing Driveshaft

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Gear Housing Driveshaft

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	8M0122302	GEAR HOUSING Short (1 required per assembly) — Replaces: 825132T15
		16008M0122302 - Gear Housing [ More info ] Unavailable
		1600-8M0155375 - 1600-8M0155375 - GEAR HOUSING B SH [ More info ] Unavailable Replaced by -8M0188404
		8M0188404 - 8M0188404 - GC 4-5-6 4S B S NLA [ More info ] Unavailable Replaced by -8M0188406
		1600-8M0188406 - 1600-8M0188406 - ->8M0188408 [ More info ] Unavailable Replaced by -8M0188408
		1600-8M0188408 - GC 4-5-6 4S B S [ More info ] Unavailable
#-	8M0155373	GEAR HOUSING B L Long (1 required per assembly) — Replaces: 825132T16, 8M0122307
		16008M0155373 - Gear Housing B L [ More info ] $564.30 Available to Order: Shipping delay up to 10 days.
#-	8M0122308	GEAR HOUSING Sailpower/Sailmate (1 required per assembly) — Replaces: 9621T5
		16008M0122308 - Gear Housing [ More info ] $564.30 Available to Order: Shipping delay up to 10 days.
#-	8M0155395	REPAIR KIT W/P (1 required per assembly) — Replaces: 16159A1, 16159A03
		8M0155395 - Water Pump Repair Kit [ More info ] $59.49 3 In Stock.
#-	8M0134073	GASKET SET (1 required per assembly) — Replaces: 95220A2, 8M0082882
		278M0134073 - Gasket Set [ More info ] Unavailable
		27-8M0155392 - Gasket Set [ More info ] Unavailable
		278M0188431 - Gasket SET [ More info ] $60.49 Available to Order: Shipping delay up to 10 days.
#1	825132T30	GEAR HOUSING ASSEMBLY BASIC (1 required per assembly) — Replaces: 825132T17
		1668-825132T30 - Gear Housing Basic [ More info ] $300.99 Available to Order: Shipping delay up to 10 days.
#1	9621T6	GEAR HOUSING ASSEMBLY BASIC Sailpower/Sailmate (1 required per assembly)
		1668-9621T 6 - Gear Housing Assembly [ More info ] $207.15 Available to Order: Shipping delay up to 10 days.
#2	16124	BUSHING (1 required per assembly)
		23-16124 - Bushing [ More info ] $13.89 Available to Order: Shipping delay up to 10 days.
#3	953683	PLUG (2 required per assembly)
		22-95368 3 - Oil Plug [ More info ] Unavailable
		22-8M0229353 - PLUG [ More info ] $10.89 1 In Stock.
#4	8M0082880	SEAL KIT DRAIN PLUG (2 required per assembly) — Replaces: 95220
		8M0082880 - Seal - Priced Individually [ More info ] $6.09 10+ In Stock.
		18-60103 - Gasket, Drain Plug 332600060M [ More info ] $1.99 $1.70 Available to Order: Shipping delay up to 10 days.
#5	8M0063198	BOLT (1 required per assembly) — Replaces: 161251
		108M0063198 - Bolt [ More info ] $7.09 Available to Order: Shipping delay up to 10 days.
#6	16826	WASHER STAINLESS STEEL (1 required per assembly)
		12-16826 - Washer, Stainless Steel [ More info ] $3.29 Available to Order: Shipping delay up to 10 days.
#7	8M0122680	GEAR ASSEMBLY (1 required per assembly) — Replaces: 16138
		438M0122680 - Gear Set, Three Gears [ More info ] $167.49 Available to Order: Shipping delay up to 10 days.
#8	16133	STRAINER WATER (1 required per assembly)
		16133 - Water Strainer [ More info ] $20.79 Available to Order: Shipping delay up to 10 days.
#9	16134	SCREW (1 required per assembly)
		10-16134 - Screw [ More info ] $2.19 1 In Stock.
#10	16126	BOLT (1 required per assembly)
		10-16126 - Bolt [ More info ] $9.69 Available to Order: Shipping delay up to 10 days.
#11	16192	WASHER (1 required per assembly)
		12-16192 - Washer [ More info ] $3.59 3 In Stock.
#12	8M0076367	DRIVESHAFT Short (1 required per assembly) — Replaces: 161351
		458M0076367 - Drive Shaft [ More info ] $233.99 Available to Order: Shipping delay up to 10 days.
#12	8M0076368	DRIVESHAFT Long (1 required per assembly) — Replaces: 161361
		45-8M0076368 - Drive Shaft [ More info ] $232.49 Available to Order: Shipping delay up to 10 days.
#13	95347	BEARING (1 required per assembly)
		30-95347 - Ball Bearing [ More info ] $28.09 Available to Order: Shipping delay up to 10 days.
#14	NSS	NOT SOLD SEPARATE Spacer (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#15	16155	KEY (1 required per assembly)
		28-16155 - Key [ More info ] $3.99 2 In Stock.
#16	16164003	GASKET (1 required per assembly)
		27-16164003 - Water Pump Housing Gasket [ More info ] $6.79 3 In Stock.
#17	161631	SHIM (0.1) (AR required per assembly)
		[ More info ] Unavailable
#17	8132761	SHIM (0.15) (AR required per assembly)
		15-813276 1 - Shim [ More info ] $8.79 Available to Order: Shipping delay up to 10 days.
#18	16162	SEAL OIL (1 required per assembly)
		26-16162 - Seal [ More info ] $19.79 3 In Stock.
#19	826053T	HOUSING (1 required per assembly)
		46-826053T - Water Pump Housing [ More info ] $53.49 Available to Order: Shipping delay up to 10 days.
#20	16160004	GASKET (1 required per assembly)
		27-16160004 - Water Pump Housing Plate Gasket [ More info ] $5.39 1 In Stock.
#21	16159	PLATE (1 required per assembly)
		16159 - Water Pump Housing Guide Plate [ More info ] $12.79 Available to Order: Shipping delay up to 10 days.
#22	8M0155369	GASKET (1 required per assembly) — Replaces: 16158009
		27-8M0155369 - Gasket [ More info ] $3.39 1 In Stock.
#23	8M0204676	IMPELLER (1 required per assembly) — Replaces: 161543
		47-8M0204676 - Water Pump Impeller, Outboard, 2.5 - 6HP [ More info ] $28.09 3 In Stock.
		47-02170 - Mercury and Tohatsu Impeller [ More info ] $20.99 $20.46 3 In Stock.
#24	16157	LINER (1 required per assembly)
		16157 - Upper Water Pump Housing Liner [ More info ] $23.69 Available to Order: Shipping delay up to 10 days.
#25	16156	HOUSING UPPER WATER PUMP (1 required per assembly)
		46-16156 - New # 8M0188429 [ More info ] Unavailable
#26	16168	SEAL (2 required per assembly)
		26-16168 - Seal [ More info ] $7.59 3 In Stock.
#27	16167	HOSE (1 required per assembly)
		32-16167 - Hose, Water Pump [ More info ] Unavailable
		32-8M0188428 - WATER PIPE LOWER [ More info ] Unavailable
#28	8M0063198	BOLT (4 required per assembly) — Replaces: 161251
#29	16826	WASHER STAINLESS STEEL (4 required per assembly)
#30	16171	SEAL (1 required per assembly)
		26-16171 - Seal [ More info ] $5.99 Available to Order: Shipping delay up to 10 days.
#31	16169	TUBE WATER Short (1 required per assembly)
		32-16169 - Tubing [ More info ] $62.99 Available to Order: Shipping delay up to 10 days.
#31	16170	TUBE WATER Long (1 required per assembly)
		32-16170 - Tubing [ More info ] $51.99 Available to Order: Shipping delay up to 10 days.
#32	18876	GROMMET (1 required per assembly)
		25-18876 - Grommet, Water Tube [ More info ] $11.89 Available to Order: Shipping delay up to 10 days.
#33	8M0044705	SHIFT ROD Short (1 required per assembly) — Replaces: 16173
		8M0044705 - Cam Rod-Short [ More info ] $25.89 Available to Order: Shipping delay up to 10 days.
#33	8M0058365	SHIFT ROD Long (1 required per assembly) — Replaces: 16174
		8M0058365 - Cam Rod-LONG [ More info ] $43.49 Available to Order: Shipping delay up to 10 days.
#34	16179	PIN (1 required per assembly)
		17-16179 - Pin [ More info ] $2.69 Available to Order: Shipping delay up to 10 days.
#35	16165	RETAINER (1 required per assembly)
		16165 - Retainer [ More info ] $6.99 Available to Order: Shipping delay up to 10 days.
#36	823042	BOLT (1 required per assembly)
		10-823042 - Bolt [ More info ] $3.79 Available to Order: Shipping delay up to 10 days.
#37	161771	O-RING (1 required per assembly)
		0161771 - Part (161771) [ More info ] $53.90 2 In Stock.
#38	8M0135927	BUSHING ORING KIT (1 required per assembly) — Replaces: 16176
		98-8M0135927 - BUSHING ORING KIT [ More info ] Unavailable
#39	16178	O-RING (1 required per assembly)
		25-16178 - O-ring, Lower Cam Rod [ More info ] $5.19 1 In Stock.
#40	8M0090459	CLUTCH CAM (1 required per assembly) — Replaces: 16172
		8M0090459 - CAM-Clutch [ More info ] $39.99 Available to Order: Shipping delay up to 10 days.
#41	16175	PIN (1 required per assembly)
		17-16175 - Pin, Clutch Cam [ More info ] $2.49 Available to Order: Shipping delay up to 10 days.
