Sailpower / Sailmate Components

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	16074T	ALTERNATOR (1 required per assembly)
		16074T - Alternator [ More info ] $118.99 Available to Order: Shipping delay up to 10 days.
#2	16059	SCREW (2 required per assembly)
		10-16059 - Screw [ More info ] $3.99 Available to Order: Shipping delay up to 10 days.
#3	16060	CLAMP (1 required per assembly)
		54-16060 - Clamp [ More info ] $5.89 Available to Order: Shipping delay up to 10 days.
#4	16821	SCREW (1 required per assembly)
		10-16821 - Screw [ More info ] $2.19 Available to Order: Shipping delay up to 10 days.
#5	16076A1	RECTIFIER KIT (Use with 25MM Screw) (1 required per assembly) — Replaces: 16076
		16076A 1 - Rectifier Kit [ More info ] $75.99 Available to Order: Shipping delay up to 10 days.
#6	16077	FUSE (1 required per assembly)
		89-16077 - Fuse [ More info ] Unavailable
#7	16123	SCREW (25 MM) (25MM) (1 required per assembly)
		10-16123 - Screw [ More info ] $2.39 Available to Order: Shipping delay up to 10 days.
#7	16078	SCREW (20MM) (1 required per assembly)
		10-16078 - Screw, NLA [ More info ] Unavailable
#8	16079	LOCKWASHER (1 required per assembly)
		13-16079 - LockWasher [ More info ] $1.20 Available to Order: Shipping delay up to 10 days.
#9	8M0108373	WASHER (1 required per assembly) — Replaces: 16080
		128M0108373 - Washer [ More info ] $1.50 1 In Stock.
#10	813275	CLAMP (1 required per assembly)
		54-813275 - Clamp [ More info ] $3.99 Available to Order: Shipping delay up to 10 days.
#11	16081	NUT (1 required per assembly)
		11-16081 - Nut, Stainless Steel [ More info ] $5.69 1 In Stock.
#12	16822	HARNESS-EXTENSION (1 required per assembly)
		84-16822 - Extension Harness [ More info ] $19.09 Available to Order: Shipping delay up to 10 days.
#13	16823	GROMMET (1 required per assembly)
		25-16823 - Grommet [ More info ] $15.09 Available to Order: Shipping delay up to 10 days.
#14	16082	HARNESS-BATTERY (1 required per assembly)
		84-16082 - Harness - Battery [ More info ] $43.49 Available to Order: Shipping delay up to 10 days.
#15	823037A04	SWITCH-STOP [0R036272] & Up (1 required per assembly) — Replaces: 823037A1
		87-823037A04 - Stop Switch [ More info ] $74.99 Available to Order: Shipping delay up to 10 days.
#16	823054	LANYARD (1 required per assembly)
		823054 - Lanyard Assembly [ More info ] $26.71 3 In Stock.
		823054Q - Lanyard Assembly - Priced Individually [ More info ] $25.99 Available to Order: Shipping delay up to 10 days.
