Parts for 25 HP Carb 4-Stroke Mercury Outboard Motor Electrical Components (S/N 0G960500 & Up)

Revise Search: Outboard > 4-Stroke Mercury Outboard > 25 HP Carb > 0P017000 - 0P153499 - Belgium > Electrical Components (S/N 0G960500 & Up)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Electrical Components (S/N 0G960500 & Up)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	854236T00	PH 25 4S (1 required per assembly)
		61-854236T00 - Powerhead 25HP 4 Stroke [ More info ] $645.72 2 In Stock.
#1	8M0185146	SOLENOID ASSEMBLY Electric (1 required per assembly) — Replaces: 850187T1
		89-8M0185146 - Solenoid, Starter or Trim [ More info ] $62.49 2 In Stock.
#2	818968	BUSHING Electric (2 required per assembly)
		23-818968 - Bushing [ More info ] Unavailable
		238M0214955 - Bushing [ More info ] $2.89 Available to Order: Shipping delay up to 10 days.
#3	8M0207785	GROMMET Electric (2 required per assembly) — Replaces: 818967
		258M0207785 - Grommet [ More info ] $9.89 Available to Order: Shipping delay up to 10 days.
#4	26419	NUT @5 Electric (2 required per assembly)
		11-26419 - Nut (#8-32) (brass) [ More info ] $1.70 10+ In Stock.
#5	94330	NUT @2 Electric (3 required per assembly)
		11-94330 - Nut, Brass (1/4-20) [ More info ] $1.70 Available to Order: Shipping delay up to 10 days.
#6	88439A9	CABLE ASSY-POS Electric (1 required per assembly)
		84-88439A 9 - Battery Cable, Positive [ More info ] $44.99 Available to Order: Shipping delay up to 10 days.
#7	8500671	BOOT (RED) Electric (1 required per assembly)
		85-850067 1 - Boot-RED, NLA [ More info ] Unavailable
#8	93388A13	CABLE ASSY Electric (1 required per assembly)
		84-93388A13 - Cable Assembly [ More info ] Unavailable
#9	88439A4	CABLE ASSY-NEG Electric (1 required per assembly)
		84-88439A 4 - Cable Assembly -neg [ More info ] $48.89 2 In Stock.
#10	893886T	STARTER MOTOR Electric (1 required per assembly) — Replaces: 859169T, 888151T
		50-893886T - Starter Motor [ More info ] $356.99 Available to Order: Shipping delay up to 10 days.
		18-6437 - Starter [ More info ] $199.99 $199.19 1 In Stock.
		5364 - Starter, 50-830308-1 [ More info ] $252.99 5 In Stock.
#11	40011153	SCREW Electric (3 required per assembly)
		10-40011153 - Screw [ More info ] $5.39 Available to Order: Shipping delay up to 10 days.
#11	40011149	SCREW Manual (1 required per assembly)
		10-40011149 - Screw [ More info ] $2.69 Available to Order: Shipping delay up to 10 days.
#12	82684430	SCREW @5 Electric (2 required per assembly)
		10-826844 30 - Screw - Priced Individually [ More info ] $2.69 6 In Stock.
#12	8248324	SCREW @5 Manual (1 required per assembly)
		10-824832 4 - Screw [ More info ] $1.80 5 In Stock.
#13	54457	J CLIP Manual (1 required per assembly)
		54-54457 - J Clip [ More info ] $4.79 Available to Order: Shipping delay up to 10 days.
#14	55098	J CLIP @5 Manual (1 required per assembly)
		54-55098 - J Clip - Priced Individually [ More info ] $4.90 5 In Stock.
		54-8M0024808 - J-CLIP [ More info ] Unavailable
#15	8M0070107	SWTICH-PRESSURE (1 required per assembly) — Replaces: 828040F, 8280401
		878M0070107 - 878M0098207 [ More info ] Unavailable
		87-8M0098207 - Pressure Switch [ More info ] $36.27 2 In Stock.
#16	8M0030022	SENSOR ASSY (1 required per assembly) — Replaces: 828358, 8283582
		8M0030022 - Sensor Assembly [ More info ] Unavailable
		8M0082988 - Sensor Assembly [ More info ] $120.49 $115.99 In Stock
#17	40011107	SCREW @5 (2 required per assembly)
		10-40011107 - SCREW [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#18	856040	BRACKET Electric (1 required per assembly)
		856040 - Bracket [ More info ] $21.25 Available to Order: Shipping delay up to 10 days.
#19	856836001	RETAINER Electric (1 required per assembly) — Replaces: 856836
		856836001 - Retainer [ More info ] Unavailable
#20	92753	RETAINER Electric (1 required per assembly)
		92753 - Harness Retainer [ More info ] $3.69 Available to Order: Shipping delay up to 10 days.
#21	82129125	SCREW (3 required per assembly)
		10-821291 25 - Screw [ More info ] Unavailable
#22	4002316	WASHER @5 (3 required per assembly)
		12-40023 16 - Washer - Priced Individually [ More info ] $1.17 2 In Stock.
		128M0214930 - WASHER Note: Must be ordered in multiples of 5 [ More info ] $1.00 1 In Stock.
#23	856837	PLATE-ECU MOUNT (1 required per assembly)
		856837 - Plate -ecu Mount [ More info ] Unavailable
#24	826618	BUSHING @5 (3 required per assembly)
		23-826618 - Bushing - Priced Individually [ More info ] $9.49 Available to Order: Shipping delay up to 10 days.
#25	834985	GROMMET @5 (3 required per assembly)
		25-834985 - Grommet [ More info ] $3.00 2 In Stock.
		25-8M0190980 - GROMMET Note: Must be ordered in multiples of 5 [ More info ] $3.89 Available to Order: Shipping delay up to 10 days.
#26	87843301S	ECM F25 (1 required per assembly) — Replaces: 878433A1
		87843301S - ORD 8M0096530 [ More info ] Unavailable
#27	881865	DECAL CAUTION-START IN GEAR START IN GEAR (1 required per assembly) — Replaces: 825064
		37-881865 - Decal -Caution [ More info ] $8.19 Available to Order: Shipping delay up to 10 days.
#28	8539201	BUSHING (3 required per assembly)
		23-853920 1 - Bushing [ More info ] $1.10 Available to Order: Shipping delay up to 10 days.
#29	82129140	SCREW (3 required per assembly)
		10-821291 40 - Screw [ More info ] $3.09 Available to Order: Shipping delay up to 10 days.
#30	827858Q	PG DPR6EA-9 @10 (2 required per assembly) — Replaces: 827858
		33-827858Q - DPR6EA-9 - Priced Individually [ More info ] Unavailable
		DPR6EA-9 - NGK Spark Plug, 5531 [ More info ] $4.99 $4.84 10+ In Stock.
#31	NSS	NOT SOLD SEPARATE DECAL-COIL IDENTIFICATION (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#32	859738T1	COIL-IGNITION [0T178500] & Up (1 required per assembly)
		339-859738T 1 - Ignition Coil [ More info ] $179.99 Available to Order: Shipping delay up to 10 days.
#33	859738T1	COIL-IGNITION [0T178499] & Below (1 required per assembly) — Replaces: 825101A2
#34	82069M	GROMMET [0T178499] & Below (2 required per assembly)
		25-82069M - Grommet, Plug Wire,NLA [ More info ] $3.00 6 In Stock.
#35	825102A1	HIGH TENSION LEAD [0T178499] & Below (2 required per assembly)
		84-825102A 1 - Boot - High Tension [ More info ] Unavailable
#36	82684430	SCREW @5 (2 required per assembly)
#37	28700	CLAMP (1 required per assembly)
		54-28700 - Clamp [ More info ] $2.99 $2.53 4 In Stock.
#38	859201T1	HARNESS ASSY Manual (1 required per assembly)
		84-859201T 1 - Harness Assembly [ More info ] $295.99 Available to Order: Shipping delay up to 10 days.
#39	859202T2	HARNESS-ENGINE [0T178500] & Up (1 required per assembly)
		84-859202T 2 - Engine Harness [ More info ] $353.75 Available to Order: Shipping delay up to 10 days.
#39	859202T1	HARNESS ASSY [0T178499] & Below (1 required per assembly)
		84-859202T 1 - Harness Assembly, NLA [ More info ] $80.00 $67.76 4 In Stock.
#40	812619	FUSE YELLOW - 20 AMPERE Electric (1 required per assembly)
		88-812619 - Fuse - Yellow - 20 Amp [ More info ] $4.69 10+ In Stock.
#41	828054	COVER FUSE Electric (1 required per assembly)
		828054 - Fuse Cover [ More info ] $5.89 Available to Order: Shipping delay up to 10 days.
#42	82129110	SCREW Electric (1 required per assembly)
		10-821291 10 - Screw [ More info ] $1.10 1 In Stock.
#43	852375A6	HARNESS ASSY-EXT Electric Handle (1 required per assembly)
		84-852375A 6 - Extension Harness Assembly [ More info ] $26.09 Available to Order: Shipping delay up to 10 days.
#44	816311T	TIE STRAP @100 (AR required per assembly)
		54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ] $0.60 10+ In Stock.
#45	883071T1	REF SOB 05-09 Electric (1 required per assembly) — Replaces: 854514T1
		883071T 1 - CALL FOR OPTIONS #SB2005-09 [ More info ] Unavailable
		18-5743-1 - Voltage Regulator, Mercury [ More info ] $199.66 $184.76 Available to Order: Shipping delay up to 10 days.
#46	8308971	PAD-FOAM Electric (1 required per assembly)
		830897 1 - Pad -foam [ More info ] $5.29 Available to Order: Shipping delay up to 10 days.
#47	893771	BRACKET Electric (1 required per assembly) — Replaces: 858413
		893771 - Bracket [ More info ] $21.79 Available to Order: Shipping delay up to 10 days.
#48	8248329	SCREW Electric (2 required per assembly)
		10-824832 9 - Screw [ More info ] $7.49 Available to Order: Shipping delay up to 10 days.
#49	889575	SENSOR ASSY-TEMP (1 required per assembly) — Replaces: 858535
		889575 - Temperature Sensor Assembly [ More info ] Unavailable
		8M0214984 - Exhaust Temperature Sensor [ More info ] $62.49 1 In Stock.
#50	627021	O-RING (.301 X .070) (1 required per assembly) — Replaces: 62702
		25-62702 1 - O-Ring [ More info ] $1.70 10+ In Stock.
#51	13541	PLUG (AR required per assembly)
		13541 - Plug [ More info ] $3.19 Available to Order: Shipping delay up to 10 days.
#52	877860T1	CABLE ASSY Use where Applicable (1 required per assembly)
		84-877860T 1 - Cable Assembly [ More info ] $24.89 $23.84 10 In Stock.
