Parts for V-115 DFI (2.5L) 2-Stroke DFI Mercury Optimax Outboard Motor Oil Injection Components

Revise Search: Outboard > 2-Stroke DFI Mercury Optimax Outboard > V-115 DFI (2.5L) > 0G960500 - 0T178499 - USA > Oil Injection Components

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Oil Injection Components

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	12335A1	BRACKET KIT (1 required per assembly)
		12335A 1 - Bracket Kit [ More info ] $110.99 Available to Order: Shipping delay up to 10 days.
#2	12323A1	CORD/HOOK KIT (1 required per assembly)
		12323A 1 - Cord/Hook Kit [ More info ] $23.49 Available to Order: Shipping delay up to 10 days.
#3	87421	RESERVOIR-OIL (1 required per assembly)
		1257-8742 1 - Oil Reservoir [ More info ] $90.99 Available to Order: Shipping delay up to 10 days.
#4	43298A2	CAP ASSY (1 required per assembly)
		36-43298A 2 - Cap Assembly [ More info ] $32.77 1 In Stock.
#5	NSS	NOT SOLD SEPARATE INSERT (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#6	11332	O-RING (2.225 X .210) (1 required per assembly)
		25-11332 - O-ring, (2.225 X .210) [ More info ] $4.85 3 In Stock.
#7	816190A4	SENDER ASSY-OIL (NON-DIGITAL) (1 required per assembly)
		816190A 4 - Oil Sender Assembly [ More info ] $201.99 Available to Order: Shipping delay up to 10 days.
#8	816190A5	SENDER ASSY-OIL (DIGITAL) (1 required per assembly) — Replaces: 816190A1
		816190A 5 - Oil Sender Assembly [ More info ] $202.12 Available to Order: Shipping delay up to 10 days.
#9	11332	O-RING (2.225 X .210) (1 required per assembly)
#10	99802	TUBE (1 required per assembly)
		32-99802 - Tube Assembly [ More info ] $16.99 Available to Order: Shipping delay up to 10 days.
#11	99439	HOSE ASY-114 INCH (1 required per assembly)
		32-99439 - Hose - Oil - 114 Inch [ More info ] $89.49 In Stock
#12	8M0063190	OIL TANK ASSY (1 required per assembly) — Replaces: 833069T6, 833069T9
		1200-8M0063190 - Oil Tank [ More info ] $316.99 1 In Stock.
#13	NSS	NOT SOLD SEPARATE OIL RESERVOIR (1 required per assembly)
#14	NSS	NOT SOLD SEPARATE DECAL-RESERVOIR (1 required per assembly)
#15	855362001	GROMMET (3 required per assembly) — Replaces: 855362
		25-855362001 - Grommet, Coolant Reservoir [ More info ] $3.19 Available to Order: Shipping delay up to 10 days.
#16	49436	WASHER (3 required per assembly)
		12-49436 - Washer - Priced Individually [ More info ] $0.90 $0.72 2 In Stock.
#17	60411	SCREW (.312-18 X 1.250) (3 required per assembly)
		10-60411 - Screw - Priced Individually [ More info ] $1.50 $1.20 1 In Stock.
#18	855364	BUSHING (3 required per assembly)
		23-855364 - Bushing [ More info ] $5.99 10+ In Stock.
#19	856156T02	SWITCH ASSEMBLY (1 required per assembly) — Replaces: 856156A2
		87-856156T02 - Switch Assembly [ More info ] $27.39 2 In Stock.
#20	58376	SCREW (.164-18 X .375) (1 required per assembly)
		10-58376 - Screw [ More info ] $1.23 $1.18 9 In Stock.
#21	72761	WASHER (.203 X .562 X .060) STAINLESS STEEL (1 required per assembly)
		12-72761 - Washer, (.203 X .562 X .060) Stainless Steel [ More info ] $1.63 10+ In Stock.
#22	814634	CLAMP (2 required per assembly)
		54-814634 - Clamp [ More info ] $5.09 Available to Order: Shipping delay up to 10 days.
