Parts for 3.0L DSI (Diesel Spark Ignition) 2-Stroke DFI Mercury Optimax Outboard Motor Driveshaft Housing & Exhaust Tube

Revise Search: Outboard > 2-Stroke DFI Mercury Optimax Outboard > 3.0L DSI (Diesel Spark Ignition) > 1E052967 & Up > Driveshaft Housing & Exhaust Tube

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Driveshaft Housing & Exhaust Tube

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	832938A06	HOUSING-DRIVESHAF (1 required per assembly)
		3519-832938A06 - Drive Shaft Housing [ More info ] Unavailable
#2	8M0070951	STUD (M12 X 1.75 X 52) (4 required per assembly)
		168M0070951 - Stud [ More info ] $12.59 Available to Order: Shipping delay up to 10 days.
#3	892860	SCREW (M12 X 35) INTERNAL HEX (1 required per assembly)
		10-892860 - Screw [ More info ] $5.49 Available to Order: Shipping delay up to 10 days.
#3	857136	SCREW (M12 X 35 MM) EXTERNAL HEX (1 required per assembly)
		10-857136 - Screw [ More info ] $7.39 $5.92 1 In Stock.
#4	8331231	GROMMET (1 required per assembly)
		25-833123 1 - Grommet [ More info ] $9.49 Available to Order: Shipping delay up to 10 days.
#5	4002321	WASHER @4 (4 required per assembly)
		12-40023 21 - Washer, (12.80 Mm X 24.0 Mm X 2.4 Mm) Stainless Steel [ More info ] $4.69 2 In Stock.
#6	896895	NUT @4 (4 required per assembly)
		11-896895 - Nut, (M12) [ More info ] $2.99 2 In Stock.
#7	64649	PLUG @2 (1 required per assembly)
		19-64649 - Plug - Priced Individually [ More info ] $5.29 5 In Stock.
#8	898834	BOLT (2 required per assembly)
		10-898834 - Bolt [ More info ] $25.99 Available to Order: Shipping delay up to 10 days.
#9	88238A10	CABLE ASSY (2 required per assembly)
		88238A10 - Cable Assembly [ More info ] $8.29 2 In Stock.
#10	815432	WASHER (2 required per assembly)
		12-815432 - Washer, (.562 X 2.00 X .125) [ More info ] $11.19 $8.96 2 In Stock.
#11	8154331	WASHER (2 required per assembly)
		12-815433 1 - Washer [ More info ] $6.39 Available to Order: Shipping delay up to 10 days.
#12	8137711	MOUNT (2 required per assembly)
		813771 1 - Mount [ More info ] $191.99 Available to Order: Shipping delay up to 10 days.
#13	825190	WASHER @5 (2 required per assembly)
		12-825190 - Washer [ More info ] $3.69 Available to Order: Shipping delay up to 10 days.
#14	896602	NUT (2 required per assembly)
		11-896602 - Nut, (M14) [ More info ] $5.89 Available to Order: Shipping delay up to 10 days.
#15	8M0084475	SCREW (4 required per assembly)
		108M0084475 - Screw [ More info ] $24.19 Available to Order: Shipping delay up to 10 days.
#16	72521	LOCKWASHER (1 required per assembly)
		13-72521 - LockWasher [ More info ] $1.50 Available to Order: Shipping delay up to 10 days.
#17	8329321	SEAL (1 required per assembly)
		832932 1 - Seal [ More info ] $38.99 Available to Order: Shipping delay up to 10 days.
#18	833116A19	EXHAUST TUBE ASSY (1 required per assembly)
		833116A19 - Exhaust Tube Assembly [ More info ] $995.99 Available to Order: Shipping delay up to 10 days.
#19	8M0026113	STRAINER (1 required per assembly)
		35-8M0026113 - Strainer [ More info ] $69.12 1 In Stock.
#20	81893435	SCREW (4 required per assembly)
		10-818934 35 - Screw [ More info ] $3.99 Available to Order: Shipping delay up to 10 days.
		108M0103814 - Screw (M8 x 35 MM) [ More info ] $4.19 6 In Stock.
#21	8M0042786	TUBE-WATER (1 required per assembly)
		32-8M0042786 - Water Tube [ More info ] $84.49 Available to Order: Shipping delay up to 10 days.
#22	832940001	SEAL (1 required per assembly)
		832940001 - Seal [ More info ] $7.79 Available to Order: Shipping delay up to 10 days.
#23	8329391	CLAMP (1 required per assembly)
		832939 1 - Clamp [ More info ] $12.19 Available to Order: Shipping delay up to 10 days.
#24	41508	SCREW (1 required per assembly)
		10-41508 - Screw [ More info ] $3.79 Available to Order: Shipping delay up to 10 days.
#25	81893435	SCREW (2 required per assembly)
#26	847541	WASHER (4 required per assembly)
		12-847541 - Washer [ More info ] $4.19 Available to Order: Shipping delay up to 10 days.
#27	879150A90	COVER KIT (2 required per assembly)
		879150A90 - Cover Kit [ More info ] $68.49 1 In Stock.
#28	8M0148785	COVER (2 required per assembly) — Replaces: 8M4501006
		100-8M0148785 - Lower Mount Cover [ More info ] $17.79 2 In Stock.
#29	8M4501003	CLAMP (2 required per assembly)
		100-8M4501003 - Clamp [ More info ] $35.99 Available to Order: Shipping delay up to 10 days.
#30	69079	SCREW (#10-16 X .440) (6 required per assembly)
		10-69079 - Screw [ More info ] $1.20 Available to Order: Shipping delay up to 10 days.
