Parts for 135 HP EFI Verado 4 Cyl 4-Stroke Mercury Outboard Motor Electrical Box Components

Revise Search: Outboard > 4-Stroke Mercury Outboard > 135 HP EFI Verado 4 Cyl > 0P464488 - 0P514868 - Belgium > Electrical Box Components

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Electrical Box Components

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	NSS	NOT SOLD SEPARATE RELAY BRACKET ASSEMBLY-COMPLETE (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#-	8M0055433	RM L4 GEN1 VERADO (1 required per assembly) — Replaces: 896499A07
		618M0055433 - RM L4 GEN1 Verado [ More info ] Unavailable
#1	896230T02	BASE (1 required per assembly) — Replaces: 896230T01
		896230T02 - Base [ More info ] $499.49 2 In Stock.
#2	NSS	NOT SOLD SEPARATE COVER (1 required per assembly)
#3	8M0167280	FUSE COVER (1 required per assembly) — Replaces: 888491
		88-8M0167280 - Fuse Cover [ More info ] $9.49 Available to Order: Shipping delay up to 10 days.
#4	885583	SEAL (1 required per assembly)
		25-885583 - Seal [ More info ] $3.09 Available to Order: Shipping delay up to 10 days.
#5	889531	STRAP (2 required per assembly)
		889531 - Strap [ More info ] $2.59 Available to Order: Shipping delay up to 10 days.
#6	895099	EXTRACTOR FUSE (1 required per assembly)
		895099 - Fuse Extractor [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#7	833155	GROMMET (1 required per assembly)
		25-833155 - Grommet [ More info ] $4.49 Available to Order: Shipping delay up to 10 days.
#8	8502341	BUSHING (1 required per assembly)
		23-850234 1 - Bushing [ More info ] $3.09 Available to Order: Shipping delay up to 10 days.
#9	832969T20	FUSE MINI - YELLOW - 20 AMPERE (7 required per assembly) — Replaces: 83296920
		88-832969T20 - Fuse - Yellow - 20 Amp [ More info ] $7.09 10+ In Stock.
#9	8M0207797	FUSE MINI GRAY 2 AMPERE (1 required per assembly) — Replaces: 8329692
		888M0207797 - FUSE-GRAY-2 AMP [ More info ] $7.29 Available to Order: Shipping delay up to 10 days.
#10	892244	STRAP COVER (1 required per assembly)
		892244 - Strap [ More info ] $2.59 Available to Order: Shipping delay up to 10 days.
#11	892448	CLIP (2 required per assembly)
		54-892448 - Clip - Priced Individually [ More info ] $1.10 Available to Order: Shipping delay up to 10 days.
#12	850181	TIE STRAP (11.750 INCHES) (8 required per assembly)
		54-850181 - Cable Tie [ More info ] $0.60 $0.48 9 In Stock.
#13	40011145	SCREW (M8 X 10) STAINLESS STEEL (2 required per assembly)
		10-40011145 - Screw - Priced Individually [ More info ] $3.19 Available to Order: Shipping delay up to 10 days.
#14	843108	WASHER (.330 X .560 X .060) STAINLESS STEEL (1 required per assembly)
		12-843108 - Washer, (.330 X .560 X .060) Stainless Steel [ More info ] $0.69 Available to Order: Shipping delay up to 10 days.
#15	817274	WASHER (.344 X 1.00 X .063) STAINLESS STEEL (1 required per assembly)
		12-817274 - Washer, (.344 X 1.00 X .063) Stainless Steel [ More info ] $1.40 2 In Stock.
#16	400213	NUT (M8) STAINLESS STEEL (1 required per assembly)
		11-40021 3 - Nut - Priced Individually [ More info ] $2.89 1 In Stock.
#17	88924613T	PCM PROPULSION CONTROL MODULE (135) [USA-1B460634] & Up (1 required per assembly) — Replaces: 89790703T, 88924605T
		88924613T - PCM Propulsion Control [ More info ] Unavailable
#17	88924615T	PCM PROPULSION CONTROL MODULE (150) [USA-1B460634] & Up (1 required per assembly) — Replaces: 89790704T, 88924612T
		88924615T - PCM Propulsion Control [ More info ] Unavailable
#17	88924617T	PCM PROPULSION CONTROL MODULE (175) [USA-1B460634] & Up (1 required per assembly) — Replaces: 89790705T, 88924604T
		88924617T - PCM Propulsion Control [ More info ] Unavailable
#17	88924614T	PCM PROPULSION CONTROL MODULE (135 EU) [BEL-0P481105] & Up (1 required per assembly) — Replaces: 89790706T, 88924607T
		88924614T - PCM Propulsion Control [ More info ] Unavailable
#17	88924616T	PCM PROPULSION CONTROL MODULE (150 EU) [BEL-0P481105] & Up (1 required per assembly) — Replaces: 89790707T, 88924611T
		88924616T - PCM [ More info ] Unavailable
#17	88924618T	PCM PROPULSION CONTROL MODULE (175 EU) [BEL-0P481105] & Up (1 required per assembly)
		88924618T - PCM Propulsion Control [ More info ] Unavailable
#18	891520001	CLIP (1 required per assembly)
		54-891520001 - Clip [ More info ] $5.39 Available to Order: Shipping delay up to 10 days.
#19	82129114	SCREW (M6 X 14) (1 required per assembly)
		10-821291 14 - Screw [ More info ] $2.49 Available to Order: Shipping delay up to 10 days.
#20	882751A04	RELAY ASSEMBLY (5 required per assembly)
		882751A04 - Relay Assembly [ More info ] $23.99 $23.49 In Stock
		18-5850 - Relay, 882751A04 [ More info ] $28.43 6 In Stock.
#21	NSS	NOT SOLD SEPARATE DECAL-TRIM RELAY (5 required per assembly)
#22	889532	BRACKET (1 required per assembly)
		889532 - Bracket [ More info ] $18.49 Available to Order: Shipping delay up to 10 days.
#23	40007103	SCREW (M5 X 6) (2 required per assembly)
		10-40007103 - Screw - Priced Individually [ More info ] $2.29 Available to Order: Shipping delay up to 10 days.
#24	819514A23	HARNESS ASSEMBLY TRIM (1 required per assembly)
		84-819514A23 - Trim Harness [ More info ] $72.49 Available to Order: Shipping delay up to 10 days.
#25	892137T03	HARNESS ASSEMBLY FUSE (1 required per assembly)
		84-892137T03 - Harness Assembly [ More info ] $112.49 Available to Order: Shipping delay up to 10 days.
#26	93388A19	CABLE ASSEMBLY (1 required per assembly)
		84-93388A19 - Starter Cable [ More info ] $24.19 Available to Order: Shipping delay up to 10 days.
#27	8M0132704	HARNESS ASSY-ENG (1 required per assembly) — Replaces: 892579A05
		848M0132704 - Engine Harness [ More info ] $1,079.49 Available to Order: Shipping delay up to 10 days.
#28	8M0113732	HARNESS-CLEAN PWR (1 required per assembly) — Replaces: 888416T03, 888416T04
		848M0113732 - Harness, Clean Power [ More info ] $105.85 Available to Order: Shipping delay up to 10 days.
#29	862646	FUSE TAN - 5 AMPERE (1 required per assembly)
		862646 - Fuse, Tan, 5 Amp [ More info ] $4.09 Available to Order: Shipping delay up to 10 days.
#30	877613A02	CONNECTOR (1 required per assembly)
		877613A02 - Connector [ More info ] $8.19 Available to Order: Shipping delay up to 10 days.
#31	879962	CLIP (1 required per assembly)
		54-879962 - Clip [ More info ] $1.99 4 In Stock.
#32	816311T	TIE STRAP @100 (AR required per assembly)
		54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ] $0.60 10+ In Stock.
#33	8M0103814	SCREW @2 (1 required per assembly) — Replaces: 88552635
		108M0103814 - Screw (M8 x 35 MM) [ More info ] $4.19 6 In Stock.
#34	817274	WASHER (1 required per assembly)
#35	88439A25	CABLE ASSY-POS (1 required per assembly)
		84-88439A25 - Cable Assembly -pos [ More info ] $61.36 1 In Stock.
#36	401388	NUT @5 (2 required per assembly)
		11-40138 8 - Nut - Priced Individually [ More info ] $3.11 3 In Stock.
#37	8M0204671	NUT BATTERY CABLE-POSITIVE (1 required per assembly) — Replaces: 86226
		11-8M0204671 - NUT [ More info ] Unavailable
#38	88439A26	CABLE ASSY-NEG (1 required per assembly)
		84-88439A26 - Cable Assembly -neg [ More info ] $70.99 Available to Order: Shipping delay up to 10 days.
#39	8M0204668	NUT (.312-18) BATTERY CABLE-NEGATIVE (1 required per assembly) — Replaces: 68292
		11-8M0204668 - NUT @5 [ More info ] Unavailable
#40	8502341	BUSHING (2 required per assembly)
#41	833155	GROMMET @5 (2 required per assembly)
#42	817274	WASHER (2 required per assembly)
#43	8M0103814	SCREW @2 (2 required per assembly) — Replaces: 88552635
