Parts for 250 (DFI) 3.0L 2-Stroke DFI Mercury Optimax Outboard Motor Electrical Plate Components S/N# 1B884208 & Up

Revise Search: Outboard > 2-Stroke DFI Mercury Optimax Outboard > 250 (DFI) 3.0L > 1B528615 - 2B535086 - USA > Electrical Plate Components S/N# 1B884208 & Up

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Electrical Plate Components S/N# 1B884208 & Up

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	NSS	NOT SOLD SEPARATE ELECTRICAL PLATE ASSEMBLY-COMPLETE (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#-	832969T20	FUSE MINI - YELLOW - 20 AMPERE (3 required per assembly) — Replaces: 83296920
		88-832969T20 - Fuse - Yellow - 20 Amp [ More info ] $7.09 10+ In Stock.
#-	8M0207797	FUSE MINI GRAY 2 AMPERE (1 required per assembly) — Replaces: 8329692
		888M0207797 - FUSE-GRAY-2 AMP [ More info ] $7.29 Available to Order: Shipping delay up to 10 days.
#-	832969T05	FUSE MINI - TAN - 5 AMPERE (1 required per assembly) — Replaces: 8329695
		88-832969T05 - Fuse -TAN-5 AMP [ More info ] $6.69 5 In Stock.
#-	879346A49	HARNESS REPAIR KIT DIRECT INJECTOR (1 required per assembly)
		879346A49 - Harness Repair Kit - Direct Inject [ More info ] $26.99 Available to Order: Shipping delay up to 10 days.
#-	879346A50	HARNESS REPAIR KIT FUEL INJECTOR (1 required per assembly)
		879346A50 - Fuel Injection Harness Kit [ More info ] $28.59 Available to Order: Shipping delay up to 10 days.
#-	881262A2	HARNESS ASSEMBLY ALTERNATOR (1 required per assembly)
		84-881262A 2 - Harness Assembly [ More info ] $44.49 $42.32 5 In Stock.
		18-6500 - Harness Assembly Delco [ More info ] $35.99 $35.23 1 In Stock.
#-	879346A41	HARNESS REPAIR KIT THROTTLE POSITION SENSOR (1 required per assembly) — Replaces: 878073A2
		879346A41 - KT-3 Pin Delphi [ More info ] $19.89 Available to Order: Shipping delay up to 10 days.
#1	899071T01	PLATE (1 required per assembly)
		899071T01 - Plate [ More info ] $18.89 Available to Order: Shipping delay up to 10 days.
#2	899145	CLIP TIE STRAP (2 required per assembly)
		54-899145 - Clip [ More info ] $3.39 Available to Order: Shipping delay up to 10 days.
#3	82129114	SCREW (M6 X 14) (2 required per assembly)
		10-821291 14 - Screw [ More info ] $2.49 Available to Order: Shipping delay up to 10 days.
#4	8M0204649	WASHER @10 (2 required per assembly) — Replaces: 29245
		12-8M0204649 - WASHER Note: Priced Individually [ More info ] $1.20 10+ In Stock.
#5	882751A1	RELAY ASSEMBLY (3 required per assembly)
		882751A 1 - Relay - 8M0207773 [ More info ] Unavailable
		18-5849 - Relay, 882751A1 [ More info ] $20.16 10+ In Stock.
		300-01562 - Power Trim Relay, 882751A1 [ More info ] $16.99 10 In Stock.
		R151 - Relay [ More info ] $20.40 $19.55 In Stock
#6	8M0207771	BRACKET (3 required per assembly) — Replaces: 828102
		8M0207771 - BRACKET [ More info ] Unavailable
#7	8M0207785	GROMMET (3 required per assembly) — Replaces: 818967
		258M0207785 - Grommet [ More info ] $9.89 Available to Order: Shipping delay up to 10 days.
#8	818968	BUSHING (3 required per assembly)
		23-818968 - Bushing [ More info ] Unavailable
		238M0214955 - Bushing [ More info ] $2.89 Available to Order: Shipping delay up to 10 days.
#9	82129125	SCREW (M6 X 25 MM) (5 required per assembly)
		10-821291 25 - Screw [ More info ] Unavailable
#10	8M0065142	HARNESS ASSEMBLY ENGINE (1 required per assembly)
		848M0065142 - Engine Harness [ More info ] $994.99 Available to Order: Shipping delay up to 10 days.
#11	875302A1	HOT STUD ASSEMBLY (1 required per assembly)
		85-875302A 1 - Hot Stud Assembly [ More info ] $27.79 Available to Order: Shipping delay up to 10 days.
#12	816311T	TIE STRAP (8.00 INCHES) (AR required per assembly)
		54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ] $0.60 10+ In Stock.
#13	85172	WASHER (1 required per assembly)
		12-85172 - Washer,rubber-upper Mount Screw [ More info ] $5.89 Available to Order: Shipping delay up to 10 days.
#14	93388T22	CABLE ASSEMBLY BLACK (1 required per assembly)
		84-93388T22 - Cable [ More info ] $25.25 1 In Stock.
#15	93388A17	CABLE ASSEMBLY (8.50 INCHES) (1 required per assembly)
		84-93388A17 - Starter Cable [ More info ] $22.09 Available to Order: Shipping delay up to 10 days.
#16	878231A6	HARNESS ASSEMBLY FUSE - 100 AMPERE (1 required per assembly)
		84-878231A 6 - Harness Assembly [ More info ] $99.99 Available to Order: Shipping delay up to 10 days.
#17	8M0204647	LOCKWASHER @5 (1 required per assembly) — Replaces: 26993
		138M0204647 - LOCKWASHER, Priced Individually [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#18	400213	NUT (M8) STAINLESS STEEL (1 required per assembly)
		11-40021 3 - Nut - Priced Individually [ More info ] $2.89 1 In Stock.
#19	88439A46	CABLE ASSEMBLY BATTERY - POSITIVE (1 required per assembly)
		84-88439A46 - Battery Cable Pos [ More info ] $79.99 Available to Order: Shipping delay up to 10 days.
#20	8M0098898	RELAY (1 required per assembly) — Replaces: 825096T01
		89-8M0098898 - Relay Assembly [ More info ] $45.99 2 In Stock.
#21	82129110	SCREW (M6 X 10) (3 required per assembly)
		10-821291 10 - Screw [ More info ] $1.10 1 In Stock.
#22	8M0010250	BRACKET (1 required per assembly)
		8M0010250 - Bracket [ More info ] $22.99 Available to Order: Shipping delay up to 10 days.
#23	8M0024801	BRACKET SOLENOID (1 required per assembly)
		8M0024801 - BRACKET [ More info ] Unavailable
#24	858953	BRACKET (2 required per assembly)
		858953 - Bracket [ More info ] $3.89 Available to Order: Shipping delay up to 10 days.
#25	401386	NUT (M6) STAINLESS STEEL (2 required per assembly)
		11-40138 6 - Nut - Priced Individually [ More info ] $5.09 9 In Stock.
#26	8M0065143	HARNESS ASSEMBLY TRIM (1 required per assembly)
		848M0065143 - Trim Harness Assembly [ More info ] $137.99 Available to Order: Shipping delay up to 10 days.
