Parts for 13.5 HP Carb (International) 4-Stroke Mercury Outboard Motor Cylinder Head
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 802733A98 | PH 15 4S (Electric) (1 required per assembly) |
  |
|
802733A98 - Powerhead, 4-stroke [ More info ] Unavailable |
| #- | 879783A01 | PH 9.9/15 4S (Manual) (1 required per assembly) |
  |
|
879783A01 - Powerhead, 9.9 and 15HP 4 Stroke [ More info ] Unavailable |
| #- | 835427A00 | GASKET SET (1 required per assembly) |
  |
|
27-835427A00 - Gasket Set [ More info ] Unavailable |
| #1 | 835430A1 | HEAD-CYLINDER (Electric)(Use with 32mm Camshaft) (1 required per assembly) |
  |
|
900-835430A 1 - Cylinder Head [ More info ] Unavailable |
| #1 | 835430A2 | HEAD-CYLINDER (Manual)(Use with 32mm Camshaft) (1 required per assembly) |
  |
|
900-835430A 2 - Cylinder Head, See Detail Page for Complete Powerhead [ More info ] Unavailable |
| #1 | 835430T08 | CYLINDER HEAD (Electric/Manual)(Use with 35mm Camshaft) (1 required per assembly) |
  |
|
835430T08 - Cylinder Head, See Detail Page for Complete Powerhead [ More info ] Unavailable |
| #2 | 850835 | GUIDE INTAKE (4 required per assembly) |
  |
|
850835 - Guide [ More info ] Unavailable |
| #3 | 825038 | CIRCLIP (4 required per assembly) |
  |
|
53-825038 - E Ring [ More info ]
|
| #4 | 822644 | PIPE PLUG (3 required per assembly) |
  |
|
22-822644 - Pipe Plug [ More info ]
|
| #5 | 855677 | BOLT (6 required per assembly) |
  |
|
10-855677 - Bolt [ More info ] Unavailable |
| #6 | 825689 | PIN-DOWEL (2 required per assembly) |
  |
|
17-825689 - Pin -Dowel [ More info ]
|
| #7 | 893745025 | SCREW-HEX HD SEMS M6X1X25 (3 required per assembly) — Replaces: 82500925 |
  |
|
10893745025 - Screw (M6 x 25) [ More info ]
|
| #8 | 8M0052705 | GASKET (1 required per assembly) — Replaces: 850836 |
  |
|
27-8M0052705 - Gasket [ More info ]
|
| #9 | 834954 | COVER (1 required per assembly) |
  |
|
834954 - Cover [ More info ] Unavailable |
| #10 | 850837 | SEAL (1 required per assembly) |
  |
|
850837 - Cylinder Head Seal [ More info ] Unavailable |
| #11 | 8257021 | BOLT (4 required per assembly) |
  |
|
10-825702 1 - Bolt [ More info ]
|
| #12 | 827858Q | PG DPR6EA-9 @10 (2 required per assembly) — Replaces: 827858 |
  |
|
33-827858Q - DPR6EA-9 - Priced Individually [ More info ] Unavailable |
  |
|
DPR6EA-9 - NGK Spark Plug, 5531 [ More info ]
|
| #13 | 859578A1 | PLUG ASSY-OIL (1 required per assembly) |
  |
|
859578A 1 - Oil Plug Assembly [ More info ]
|
| #14 | NSS | NOT SOLD SEPARATE O-RING (1 required per assembly) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #15 | NSS | NOT SOLD SEPARATE DECAL-RECOMM. ENG. OIL/VALVE CLE. (1 required per assembly) |
