Parts for 100 HP EFI 4-Stroke Mercury Outboard Motor Alternator / Starboard Cylinder Block Components
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 897534A07 | GASKET SET (1 required per assembly) |
  |
|
27-897534A07 - Powerhead Gasket Set [ More info ]
|
| #- | 8M8033014 | PH L4NA 4S (1 required per assembly) — Replaces: 897148A09 |
  |
|
8M8033014 - PH L4NA 4S [ More info ] Unavailable |
| #- | 897148A08 | PH L4NA 4S (1 required per assembly) |
  |
|
61-897148A08 - Powerhead L4NA 4S [ More info ] Unavailable |
| #1 | 8M0063970 | ALTERNATOR (1 required per assembly) — Replaces: 897755T |
  |
8M0063970 - Alternator [ More info ] Unavailable |
|
  |
|
8M6013463 - ALTERNATOR [ More info ] Unavailable |
  |
|
20852 - Alternator for Mercury Outboard Engines [ More info ]
|
  |
|
20851 - ALT F/OUTBOARD MERCURY ENGINES [ More info ]
|
  |
|
20850 - Alternator [ More info ]
|
| #2 | 897568T01 | BRACKET (1 required per assembly) |
  |
|
897568T01 - Bracket [ More info ]
|
| #3 | 82130145 | SCREW (3 required per assembly) |
  |
|
10-821301 45 - Screw [ More info ]
|
| #4 | 845998 | WASHER (6 required per assembly) |
  |
|
12-845998 - Washer, (.406 X 1.250 X .089) [ More info ]
|
| #5 | 899019 | MOUNT (3 required per assembly) |
  |
|
|
| #6 | 897574Q01 | BELT (1 required per assembly) — Replaces: 897574001 |
  |
|
57-897574Q01 - Belt [ More info ]
|
| #7 | 82446155 | SCREW @2 (2 required per assembly) |
  |
|
10-824461 55 - Screw - Priced Individually [ More info ]
|
| #8 | 4002319 | WASHER @3 (1 required per assembly) |
  |
|
12-40023 19 - Washer (M10) [ More info ]
|
| #9 | 826292 | NUT (1 required per assembly) |
  |
|
11-826292 - Nut (M10) [ More info ]
|
| #10 | 897559153 | CLIP (1 required per assembly) |
  |
|
54-897559153 - Clip [ More info ]
|
| #11 | 856583T12 | CABLE ASSY (1 required per assembly) |
  |
|
84-856583T12 - Cable Assembly [ More info ]
|
| #12 | 8M0007202 | TAB WASHER USE WHERE APPLICABLE (1 required per assembly) |
  |
|
14-8M0007202 - WASHER-TAB,NLA [ More info ] Unavailable |
| #13 | 8M0103805 | SCREW @2 (1 required per assembly) — Replaces: 88552516 |
  |
|
108M0103805 - Screw (M6 x 16MM) Stain [ More info ]
|
| #14 | 8M6000634 | SENSOR (1 required per assembly) — Replaces: 897447002 |
  |
8M6000634 - Sensor [ More info ] Unavailable |
|
  |
|
718M0142688 - PRESSURE Sensor [ More info ]
|
| #15 | 8M0001051 | DIPSTICK (1 required per assembly) |
  |
|
8M0001051 - Dipstick [ More info ] Unavailable |
| #16 | 8M0090819 | THERMOSTAT ASSY (1 required per assembly) — Replaces: 892864T06 |
  |
|
8M0090819 - Thermostat [ More info ]
|
  |
|
18-3635 - Thermostat [ More info ]
|
  |
|
18-3633 - Thermostat [ More info ]
|
  |
|
75-75517 - Thermostat 8M0090819, 120 Degree [ More info ]
|
| #17 | 8M0005958 | O-RING (1 required per assembly) |
  |
|
25-8M0005958 - O-Ring [ More info ]
|
| #18 | 8M0204719 | CLAMP @5 (1 required per assembly) — Replaces: 888988001 |
  |
|
548M0204719 - CLAMP Note: Priced Individually [ More info ]
|
| #19 | 897668 | HOSE (1 required per assembly) |
  |
|
32-897668 - Hose - Thermostat Dump [ More info ]
|
| #20 | 850896 | CLAMP (1 required per assembly) |
  |
|
54-850896 - Clamp [ More info ]
|
| #21 | 897670A01 | FITTING ASSY-DUMP (1 required per assembly) |
  |
|
22-897670A01 - Fitting Assembly -dump [ More info ]
|
| #22 | 8M0103805 | SCREW @2 (1 required per assembly) — Replaces: 88552516 |
| #23 | 877761K01 | FILTER-OIL (1 required per assembly) |
  |
|
35-877761K01 - Oil Filter [ More info ]
|
  |
|
18-7758 - Oil Filter, 35-877761K01 [ More info ]
|
  |
|
35-877761Q01 - Oil Filter [ More info ]
|
  |
|
35-57822 - OIL FILTER MERCURY [ More info ]
|
| #23 | 877761Q01 | FILTER-OIL (1 required per assembly) |
| #24 | 8M0073011 | FITTING OIL FILTER (1 required per assembly) — Replaces: 897672 |
  |
|
228M0073011 - Fitting [ More info ]
|
| #25 | 897126A01 | BRACKET ASSY (1 required per assembly) |
  |
|
897126A01 - Bracket Assembly [ More info ]
|
| #26 | 834985 | GROMMET (2 required per assembly) |
  |
|
25-834985 - Grommet [ More info ]
|
  |
|
25-8M0190980 - GROMMET Note: Must be ordered in multiples of 5 [ More info ]
|
| #27 | 822003 | BUSHING (2 required per assembly) |
  |
|
23-822003 - Bushing [ More info ]
|
| #28 | 8M0103807 | SCREW @2 (2 required per assembly) — Replaces: 88552525 |
  |
|
108M0103807 - Screw (M6 x 25 MM) Stainless Steel [ More info ]
|
| #29 | 858779 | WASHER @5 (2 required per assembly) |
  |
|
12-858779 - Washer, (.265 X .750 X .048) [ More info ]
|
| #30 | 897559 | CLIP (1 required per assembly) |
  |
|
54-897559 - Clip [ More info ]
|
| #31 | 897642T01 | COVER-FLYWEEHL (1 required per assembly) |
  |
|
897642T01 - Flywheel Cover [ More info ]
|
| #32 | 8M0153609 | GROMMET (3 required per assembly) — Replaces: 821555001 |
  |
|
25-8M0153609 - Grommet - Priced Individually [ More info ]
|
| #33 | 401386 | NUT @5 (1 required per assembly) |
  |
|
11-40138 6 - Nut - Priced Individually [ More info ]
|
| #34 | 897757 | PIN @2 (1 required per assembly) |
  |
|
17-897757 - Pin - Priced Individually [ More info ] Unavailable |
| #35 | 8M0087447 | PLUG @2 (1 required per assembly) — Replaces: 897674, 8M0048146 |
  |
|
198M0087447 - Plug (10MM) [ More info ]
|
| #36 | 8M0103807 | SCREW @2 (2 required per assembly) — Replaces: 88552525 |
| #37 | 8M0153609 | GROMMET @4 (1 required per assembly) — Replaces: 821555001 |
