Parts for 225 Sport XS 2-Stroke DFI Mercury Optimax Outboard Motor Transom Brackets

Revise Search: Outboard > 2-Stroke DFI Mercury Optimax Outboard > 225 Sport XS > 1E002584 & Up > Transom Brackets

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Transom Brackets

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	828333A09	BRACKET KIT-TRANS Must Order Starboard and Port Bracket Below (1 required per assembly)
		3425-828333A09 - Bracket Kit -trans [ More info ] Unavailable
#1	8M0142801	BRACKET TRANSOM, STARBOARD (1 required per assembly)
		14008M0142801 - Transom Bracket S [ More info ] $164.49 Available to Order: Shipping delay up to 10 days.
#2	8M0142800	BRACKET TRANSOM, PORT (1 required per assembly)
		14008M0142800 - Transom Bracket P [ More info ] $167.49 Available to Order: Shipping delay up to 10 days.
#3	8M0169588	FITTING PORT (1 required per assembly) — Replaces: 98727
		22-8M0169588 - FITTING [ More info ] Unavailable
#4	826125A1	TILT TUBE KIT (1 required per assembly)
		826125A 1 - Tilt Tube Kit [ More info ] $294.39 1 In Stock.
#5	826135	NUT (1.00-14) NYLON INSERT (1 required per assembly)
		11-826135 - Nut (1.0-14) [ More info ] $26.03 10+ In Stock.
#6	45711	O-RING (.612 X .103) (1 required per assembly)
		25-45711 - Valve Cover O-Ring, Priced Individually [ More info ] $1.80 8 In Stock.
#7	88750	WASHER (2 required per assembly)
		13-88750 - Wave Washer - Priced Individually [ More info ] $6.79 10+ In Stock.
#8	826164	NUT (.875-14) (1 required per assembly)
		11-826164 - Nut (7/8-14) [ More info ] Unavailable
		11-8M0231351 - NUT @2 [ More info ] Unavailable
#9	8M0149747	SCREW (4 required per assembly) — Replaces: 677551
		108M0149747 - SCREW [ More info ] $18.19 Available to Order: Shipping delay up to 10 days.
#9	8M0204730	SCREW (4 required per assembly) — Replaces: 8M0033366, 8M0071543
		10-8M0204730 - SCREW [ More info ] Unavailable
#10	8M0204665	WASHER @10 (4 required per assembly) — Replaces: 54012
		12-8M0204665 - WASHER Note: Priced Individually [ More info ] $3.59 10+ In Stock.
#11	8M0204648	WASHER @5 (4 required per assembly) — Replaces: 28421
		12-8M0204648 - ENGINE MOUNTING WASHER Note: Must be ordered in multiples of 5 O/B [ More info ] $3.99 Available to Order: Shipping delay up to 10 days.
#12	82671117	NUT (4 required per assembly)
		11-826711 17 - Nut, (.500-20) [ More info ] $8.99 10+ In Stock.
#13	8M0115104	LEVER ASSY (1 required per assembly) — Replaces: 99629T2, 8M0115103
		8M0115104 - Lever [ More info ] $57.99 Available to Order: Shipping delay up to 10 days.
#14	830899	SPRING (1 required per assembly)
		24-830899 - Spring, Tension, Tilt Lock [ More info ] $6.89 Available to Order: Shipping delay up to 10 days.
#15	65830	NYLINER (2 required per assembly)
		23-65830 - NyLiner [ More info ] $5.69 1 In Stock.
#16	830900	SPRING (1 required per assembly)
		24-830900 - Spring, Compression [ More info ] $2.99 Available to Order: Shipping delay up to 10 days.
#17	99633	KNOB (1 required per assembly)
		99633 - Tilt Lock Lever Knob [ More info ] $4.59 Available to Order: Shipping delay up to 10 days.
#18	99615	PIN-GROOVE (1 required per assembly)
		17-99615 - Pin, Groove [ More info ] $4.69 Available to Order: Shipping delay up to 10 days.
#19	893709	PIN-GROOVED (1 required per assembly)
		17-893709 - Pin -grooved [ More info ] $3.69 Available to Order: Shipping delay up to 10 days.
#20	8M0043059	DECAL-WARNING (1 required per assembly)
		37-8M0043059 - Decal - Warning [ More info ] $1.10 Available to Order: Shipping delay up to 10 days.
