Parts for 250 (3.0L EFI) 2-Stroke EFI Mercury Outboard Motor Gear Housing Propeller Shaft - Counter Rotation

Revise Search: Outboard > 2-Stroke EFI Mercury Outboard > 250 (3.0L EFI) > 0T801000 - 1B417701 - USA > Gear Housing Propeller Shaft - Counter Rotation

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Gear Housing Propeller Shaft - Counter Rotation

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	859399T16	GC COMP 3.0L CXL (X-Long) (1 required per assembly)
		1623-859399T16 - Gear Housing Assembly [ More info ] Unavailable
		90-218-A25 - SE218 Lower Unit Mercury 3.0L, 1.75 to 1, 25 inch, Counter Rotation [ More info ] $1395.00 $1395.00 Available to Order
		1600-8M0236248 - GC COMP 3.0L CXL [ More info ] Unavailable
#-	859399T17	GC COMP 3.0L CXXL (XX-Long) (1 required per assembly)
		1623-859399T17 - Gear Housing Assembly [ More info ] Unavailable
		90-218-A30 - SE218 Lower Unit Mercury 3.0L, 1.75 to 1, 30 inch, Counter Rotation [ More info ] $1395.00 $1395.00 Available to Order
#-	816575A4	SEAL KIT (1 required per assembly)
		26-816575A 4 - Seal Kit [ More info ] $48.49 In Stock
		26-00835 - Lower Unit Seal Kit, 26-816575A 4 [ More info ] $35.84 2 In Stock.
#1	859399T18	GEAR HOUSING ASSEMBLY BASIC (1 required per assembly)
		1623-859399T18 - Gear Housing Assembly [ More info ] $2,994.49 Available to Order: Shipping delay up to 10 days.
#2	859403	PLUG (1 required per assembly)
		22-859403 - Plug [ More info ] $30.49 Available to Order: Shipping delay up to 10 days.
#3	823903	SHIFT CRANK (1 required per assembly)
		823903 - Crank [ More info ] Unavailable
		8M0226861 - CRANK-SHIFTER [ More info ] Unavailable
#4	19755T7	SPOOL ASSEMBLY (1 required per assembly)
		19755T 7 - Spool Assembly [ More info ] Unavailable
#5	NSS	NOT SOLD SEPARATE SPOOL (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#6	NSS	NOT SOLD SEPARATE SLEEVE (1 required per assembly)
#7	469501	COTTER PIN (1 required per assembly)
		18-46950 1 - Cotter Pin [ More info ] $4.49 7 In Stock.
#8	8M0063266	SHIM SET (AR required per assembly) — Replaces: 44491A1
		15-8M0063266 - Shim Set [ More info ] $52.99 $50.80 10+ In Stock.
#9	828830A2	ADAPTER ASSEMBLY BEARING (1 required per assembly)
		828830A 2 - Adaptor Assembly [ More info ] $79.99 1 In Stock.
#10	814653T	BEARING ASSEMBLY NEEDLE ROLLERS (1 required per assembly)
		31-814653T - Bearing - Needle Rollers [ More info ] $103.99 $24.96 10+ In Stock.
#11	815481	THRUST WASHER (1 required per assembly)
		12-815481 - Thrust Washer [ More info ] $24.09 $23.12 10 In Stock.
#12	815480	BEARING THRUST (1 required per assembly)
		31-815480 - Thrust Bearing [ More info ] $32.49 $7.81 10+ In Stock.
#13	828696T2	GEAR REVERSE (12/21) (1 required per assembly)
		43-828696T 2 - Reverse Gear Assembly [ More info ] $538.49 Available to Order: Shipping delay up to 10 days.
#14	15844	BEARING ASSEMBLY ROLLER (1 required per assembly)
		31-15844 - Roller Bearing [ More info ] $21.29 $11.22 10+ In Stock.
#15	30893	SPRING (1 required per assembly)
		24-30893 - Spring, Reatiner - Cross Pin [ More info ] $2.69 1 In Stock.
#16	859340T	CLUTCH (1 required per assembly)
		52-859340T - Clutch [ More info ] $303.49 Available to Order: Shipping delay up to 10 days.
#17	8M0084681	PIN CROSS (1 required per assembly) — Replaces: 30632, 8M0020941
		17-8M0084681 - Pin - Priced Individually [ More info ] Unavailable
		17-8M0100263 - Pin - Priced Individually [ More info ] $4.49 2 In Stock.
#18	828356	PIN DETENT (1 required per assembly)
		17-828356 - Pin, Detent [ More info ] $9.89 Available to Order: Shipping delay up to 10 days.
#19	8M0140448	PROP SHAFT LH (1 required per assembly) — Replaces: 824111
		44-8M0140448 - PROP Shaft LH [ More info ] $721.49 Available to Order: Shipping delay up to 10 days.
#20	828695A1	GEAR SET FORWARD/PINION (12/21) (1 required per assembly)
		43-828695A 1 - Forward Gear [ More info ] $843.49 Available to Order: Shipping delay up to 10 days.
#21	1761514	SPACER SHIM (.206) (AR required per assembly)
		23-17615 14 - Spacer - Shim - .206 Inch [ More info ] $37.47 1 In Stock.
#21	1761515	SPACER SHIM (.208) (AR required per assembly)
		23-17615 15 - Spacer Shim - .208 Inch [ More info ] $65.63 1 In Stock.
#21	1761516	SPACER SHIM (.210) (AR required per assembly)
		23-17615 16 - Spacer Shim - .210 Inch [ More info ] $44.99 Available to Order: Shipping delay up to 10 days.
#21	1761517	SPACER SHIM (.212) (AR required per assembly)
		23-17615 17 - Spacer Shim - .212 Inch [ More info ] $51.99 $49.84 2 In Stock.
#21	1761518	SPACER SHIM (.214) (AR required per assembly)
		23-17615 18 - Spacer Shim - .214 Inch [ More info ] $62.47 3 In Stock.
#21	1761519	SPACER SHIM (.216) (AR required per assembly)
		23-17615 19 - Spacer Shim - .216 Inch [ More info ] $62.55 1 In Stock.
#21	1761520	SPACER SHIM (.218) (AR required per assembly)
		23-17615 20 - Spacer Shim - .218 [ More info ] $66.98 1 In Stock.
#21	1761521	SPACER SHIM (.220) (AR required per assembly)
		23-17615 21 - Spacer Shim - .220 Inch [ More info ] $44.99 Available to Order: Shipping delay up to 10 days.
#21	1761522	SPACER SHIM (.222) (AR required per assembly)
		23-17615 22 - Spacer Shim - .222 Inch [ More info ] $33.29 $31.92 2 In Stock.
#21	1761523	SPACER SHIM (.224) (AR required per assembly)
		23-17615 23 - Spacer Shim - .224 Inch [ More info ] $34.05 1 In Stock.
#21	1761524	SPACER SHIM (.226) (AR required per assembly)
		23-17615 24 - Spacer Shim - .226 Inch [ More info ] $19.89 1 In Stock.
#21	1761525	SPACER SHIM (.228) (AR required per assembly)
		23-17615 25 - Spacer Shim - .228 Inch [ More info ] $27.23 1 In Stock.
#21	1761526	SPACER SHIM (.230) (AR required per assembly)
		23-17615 26 - Spacer Shim - .230 Inch [ More info ] $63.65 1 In Stock.
#22	815480	BEARING THRUST (1 required per assembly)
#23	815481	THRUST WASHER (1 required per assembly)
#24	828831A3	ADAPTER ASSEMBLY BEARING (1 required per assembly)
		828831A 3 - Adaptor Assembly [ More info ] $307.99 Available to Order: Shipping delay up to 10 days.
#25	814653T	BEARING ASSEMBLY NEEDLE ROLLERS (1 required per assembly)
#26	18448	THRUST WASHER (2 required per assembly)
		12-18448 - Thrust Washer [ More info ] $10.19 $2.05 7 In Stock.
#27	15842	BEARING THRUST (2 required per assembly)
		31-15842 - Thrust Bearing [ More info ] $42.07 10+ In Stock.
#28	8182911	RACE THRUST (2 required per assembly)
		818291 1 - Race - Thrust [ More info ] $115.62 10+ In Stock.
#29	814605	KEEPER (2 required per assembly)
		814605 - Keeper - Priced Individually [ More info ] $12.49 $2.50 10+ In Stock.
#30	31534	O-RING (Orange) (1 required per assembly)
		25-31534 - O-Ring, Bearing Carrier [ More info ] Unavailable
		25-8M0214920 - Bell Housing O-Ring Note: Priced Individually [ More info ] $6.29 6 In Stock.
#30	8M0142840	O-RING (3.85 X 0.210) (Black) (1 required per assembly) — Replaces: 896524
		258M0142840 - O-Ring [ More info ] $1.70 Available to Order: Shipping delay up to 10 days.
#31	818290T8	CARRIER ASSEMBLY BEARING (1 required per assembly)
		818290T 8 - Bearing Carrier [ More info ] $253.99 Available to Order: Shipping delay up to 10 days.
#32	30956T	BEARING NEEDLE (1 required per assembly)
		31-30956T - Roller Bearing [ More info ] $19.49 In Stock
#33	14077	SEAL OIL (INSIDE) (1 required per assembly)
		26-14077 - Seal [ More info ] $19.49 5 In Stock.
		18-2077 - Seal 26-14077 [ More info ] $18.06 1 In Stock.
#34	8M0204670	SEAL @5 (OUTSIDE) (1 required per assembly) — Replaces: 76868
		26-8M0204670 - Gearcase Seal, Priced Individually [ More info ] $19.19 5 In Stock.
#35	18323	TAB WASHER (1 required per assembly)
		14-18323 - Tab Washer, Keyed [ More info ] $24.89 10+ In Stock.
		18-2298 - Washer, 14-18323 [ More info ] $19.99 $16.05 In Stock
#36	8M2000347	RETAINER (1 required per assembly) — Replaces: 79448, 8M2011027
		8M2000347 - Retainer [ More info ] Unavailable
		8M0168577 - Bearing Carrier Retaining Nut [ More info ] $43.49 In Stock
#37	76214Q5	ANODE KIT (1 required per assembly)
		97-76214Q 5 - Anode, Outboard & MCM Aluminum - Priced Individually [ More info ] Unavailable
		18-6244 - Anode, Magnesium, Plate Only - No Fin, 76214 [ More info ] $25.59 $24.49 6 In Stock.
		18-6016A - Anode, Aluminum, Plate Only - No Fin [ More info ] $29.75 In Stock
		18-6016 - Anodic Plate, Zinc, Plate Only - No Fin 76214 [ More info ] $26.41 3 In Stock.
		97-8M0059339 - Anode, Aluminum, BULK-10PC 76214A 6 QS [ More info ] $194.99 $192.22 Available to Order: Shipping delay up to 10 days.
#38	8M0204686	SCREW (1 required per assembly) — Replaces: 806327
		10-8M0204686 - Trim Tab Anode Screw, Outboard [ More info ] $6.99 Available to Order: Shipping delay up to 10 days.
#39	NSS	NOT SOLD SEPARATE DECAL- COUNTER ROTATION (1 required per assembly)
