Parts for 200XS DFI (2.5L) Ros 2-Stroke DFI Mercury Optimax Outboard Motor Gear Housing Propeller Shaft-Standard-Sportmaster

Revise Search: Outboard > 2-Stroke DFI Mercury Optimax Outboard > 200XS DFI (2.5L) Ros > 1E050852 & Up > Gear Housing Propeller Shaft-Standard-Sportmaster

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Gear Housing Propeller Shaft-Standard-Sportmaster

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	89238A3	SEAL KIT (1 required per assembly)
		26-89238A 3 - Seal Kit [ More info ] $165.68 Available to Order: Shipping delay up to 10 days.
#-	59579	STUD (3 required per assembly)
		16-59579 - Stud [ More info ] $8.69 Available to Order: Shipping delay up to 10 days.
#-	840560A09	G CASE-1.75 15 RH (1 required per assembly)
		1687840560A09 - Gear Housing ASSE [ More info ] Unavailable
#-	840389K06	PROP HUB KIT (1 required per assembly)
		840389K06 - Hub Kit -hd Prop [ More info ] Unavailable
		8M0183487 - HUB KIT-HD PROP [ More info ] $205.54 Available to Order: Shipping delay up to 10 days.
#-	840382A02	SNUBBER STRIP KIT (1 required per assembly)
		840382A02 - Snubber Strip Kit [ More info ] $28.67 1 In Stock.
#1	8M0083306	GEAR HOUSING-SM (DOES NOT INCLUDE STUDS. ORDER THE STUD 16-59579 LISTED BELOW) (1 required per assembly) — Replaces: 849780A2
		16008M0083306 - Gear Housing -SM [ More info ] Unavailable
#2	89594A1	FOLLOWER ASSEMBLY (1 required per assembly)
		89594A 1 - Cam/Follower Kit [ More info ] $234.99 Available to Order: Shipping delay up to 10 days.
#3	789562	SHIFT CAM (1 required per assembly)
		78956 2 - Shift Cam [ More info ] $11.49 3 In Stock.
#4	79911A1	ROD (1 required per assembly)
		79911A 1 - Clutch Rod Kit [ More info ] $186.49 Available to Order: Shipping delay up to 10 days.
#5	79910	SPRING (2 required per assembly)
		24-79910 - Spring, Compression [ More info ] $8.19 2 In Stock.
#6	8M0084245	PIN SPRING LOCATOR (1 required per assembly) — Replaces: 78906
		178M0084245 - Locator Pin [ More info ] $3.69 Available to Order: Shipping delay up to 10 days.
#7	78910	WASHER (2 required per assembly)
		12-78910 - Washer, Compression Spring [ More info ] $1.99 10+ In Stock.
#8	47397A1	SHIM SET (AR required per assembly)
		15-47397A 1 - Shim Set [ More info ] $16.79 $11.26 10+ In Stock.
		18-2285 - Shim 15-47397A1 [ More info ] $30.99 $27.04 In Stock
#9	78172A1	BEARING ASSEMBLY TAPERED ROLLER (1 required per assembly)
		31-78172A 1 - Tapered Roller Bearing [ More info ] $104.99 $55.22 3 In Stock.
#10	NSS	NOT SOLD SEPARATE CUP (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#11	30281	KEY (1 required per assembly)
		28-30281 - Key - Priced Individually [ More info ] $2.99 8 In Stock.
#12	79447	TAB WASHER (1 required per assembly)
		14-79447 - Tab Washer - Priced Individually [ More info ] $13.69 10+ In Stock.
#13	8M0052635	RATCHET (1 required per assembly)
		52-8M0052635 - Clutch [ More info ] $307.72 Available to Order: Shipping delay up to 10 days.
#14	78909	PIN DETENT (2 required per assembly)
		17-78909 - Pin, Detent [ More info ] $19.19 $18.40 9 In Stock.
#15	42671	PIN CROSS (1 required per assembly)
		17-42671 - Pin, Cross [ More info ] $68.52 Available to Order: Shipping delay up to 10 days.
#16	78962	SPRING (2 required per assembly)
		24-78962 - Spring, Retaining - Cross Pin [ More info ] $11.49 6 In Stock.
#17	840451A03	PROPELLER SHAFT (1 required per assembly)
		44-840451A03 - Prop Shaft Kit [ More info ] Unavailable
#18	849189T2	GEAR CONVERSION KIT (1 required per assembly)
		43-849189T 2 - Gear Set -1.75 Rh [ More info ] Unavailable
#19	822823	THRUST RING (1 required per assembly)
		23-822823 - Thrust Ring [ More info ] $66.89 Available to Order: Shipping delay up to 10 days.
#20	88957T	BEARING BALL (1 required per assembly)
		30-88957T - Ball Bearing [ More info ] $64.49 Available to Order: Shipping delay up to 10 days.
#21	681001	RING THRUST (1 required per assembly)
		68100 1 - Ring - Thrust [ More info ] $18.79 $15.04 10+ In Stock.
#22	NSS	NOT SOLD SEPARATE REVERSE GEAR, 1.75 (1 required per assembly)
#23	549281	BEARING ROLLER (1 required per assembly)
		31-54928 1 - Bearing [ More info ] $25.39 Available to Order: Shipping delay up to 10 days.
#24	848840A1	CARRIER ASSEMBLY BEARING (1 required per assembly)
		848840A 1 - Bearing Carrier [ More info ] $414.04 Available to Order: Shipping delay up to 10 days.
#25	817071	RING SNAP (2 required per assembly)
		53-817071 - Ring - Retaining [ More info ] $3.99 Available to Order: Shipping delay up to 10 days.
#26	815565	SEAL OIL (2 required per assembly)
		26-815565 - Seal [ More info ] $36.77 2 In Stock.
#27	817072	BEARING ROLLER (1 required per assembly)
		31-817072 - Roller Bearing [ More info ] $90.49 Available to Order: Shipping delay up to 10 days.
#28	8M0058389	SCREW KIT DRAIN (1 required per assembly) — Replaces: 67892A06
		22-8M0058389 - Screw Kit - Priced Individually [ More info ] $11.69 6 In Stock.
		18-23751-9 - Drain Screw , Package of 50 [ More info ] $346.09 In Stock
		18-2375 - Plug, 22-67892A1 [ More info ] $7.16 10+ In Stock.
		10-02683 - Drain Screw [ More info ] $6.39 $6.03 2 In Stock.
#29	191833	SEAL (1 required per assembly)
		12-19183 3 - Seal -Blue - Priced Individually [ More info ] Unavailable
		18-2945-9 - Gasket 12-19183 2-Pack [ More info ] $2.41 10+ In Stock.
		12-19183Q02 - Seals, Pack of 4 (yes this is actually a pack of 4) [ More info ] $6.69 5 In Stock.
		12-19183K02 - Seal, Pack of 4 [ More info ] $7.29 8 In Stock.
		12-8M0187157 - SEAL-BLUE, Sold Individually [ More info ] $1.49 10+ In Stock.
		12-02108-1 - Drain Gasket (1 piece) [ More info ] $1.20 $0.85 10+ In Stock.
#30	8M0168577	RETAINER BEARING CARRIER (1 required per assembly) — Replaces: 8M2011027, 8M2000347
		8M0168577 - Bearing Carrier Retaining Nut [ More info ] $43.49 In Stock
#31	31534	O-RING (1 required per assembly)
		25-31534 - O-Ring, Bearing Carrier [ More info ] Unavailable
		25-8M0214920 - Bell Housing O-Ring Note: Priced Individually [ More info ] $6.29 6 In Stock.
#32	85344	WASHER (1 required per assembly)
		12-85344 - Washer, (.750 Inside Diameter) [ More info ] $2.79 Available to Order: Shipping delay up to 10 days.
#33	52707Q1	PROP NUT KIT@2 (1 required per assembly)
		11-52707Q 1 - Prop Nut Kit - Priced Individually [ More info ] $16.81 3 In Stock.
		18-3701 - Nut Kit, 11-52707A1 [ More info ] $24.71 10+ In Stock.
		18-3700 - Prop Nut Only, 11-52707 [ More info ] $15.31 In Stock
		11-52707T 1 - Prop Nut Kit - Priced Individually [ More info ] $16.81 2 In Stock.
		11-00122 - Prop Nut Kit [ More info ] $13.99 $11.16 Available to Order: Shipping delay up to 10 days.
#34	41350	SCREW (Short) (1 required per assembly)
		10-41350 - Screw [ More info ] $27.49 Available to Order: Shipping delay up to 10 days.
#35	76214T3	PLATE-ANODIC (Short) (1 required per assembly)
		76214T 3 - Anodic Plate [ More info ] $47.82 1 In Stock.
		18-6244 - Anode, Magnesium, Plate Only - No Fin, 76214 [ More info ] $25.59 $24.49 6 In Stock.
		18-6016A - Anode, Aluminum, Plate Only - No Fin [ More info ] $29.75 In Stock
		18-6016 - Anodic Plate, Zinc, Plate Only - No Fin 76214 [ More info ] $26.41 3 In Stock.
#36	822836	WASHER (3 required per assembly)
		12-822836 - Washer, (.445 X .805 X .108) [ More info ] Unavailable
#37	859116	NUT @5 (3 required per assembly)
		11-859116 - Nut, (.437-20), Sold Individually [ More info ] $5.09 10+ In Stock.
#38	30206	SCREW @2 (1 required per assembly)
		10-30206 - Screw - Priced Individually [ More info ] $4.19 $0.85 10+ In Stock.
		18-2361-9 - Screw, 10-30206, 2PK [ More info ] $3.69 Available to Order: Shipping delay up to 10 days.
