Parts for 2.5L (EFI) / (EFI-offshore) 2-Stroke EFI Mercury Outboard Motor Trim Switch Kit
Tap to zoom. Scroll down to order.
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 18286A17 | SWITCH KIT (1 required per assembly) |
  |
|
87-18286A17 - Switch Kit [ More info ]
|
| #1 | 18861 | RETAINER (1 required per assembly) |
  |
|
18861 - Retainer [ More info ]
|
| #2 | 814820 | ADAPTER (1 required per assembly) |
  |
|
814820 - Adaptor [ More info ] Unavailable |
| #3 | 18286A28 | SWITCH (1 required per assembly) |
  |
|
87-18286A28 - Switch Assembly [ More info ] Unavailable |
| #4 | 19209 | SCREW (#10-32 X 2.25) (2 required per assembly) |
  |
|
10-19209 - Screw [ More info ] Unavailable |
| #5 | 813523 | SCREW (#10-16 X 2.25) (2 required per assembly) |
  |
|
10-813523 - Screw [ More info ] Unavailable |
| #6 | 848017T3 | HARNESS ASSY (1 required per assembly) |
  |
|
84-848017T 3 - Harness Assembly, NLA [ More info ]
|
