Parts for 2.5XS 2.5L DFI 2-Stroke DFI Mercury Optimax Outboard Motor Air Handler Components / Flywheel Cover

Revise Search: Outboard > 2-Stroke DFI Mercury Optimax Outboard > 2.5XS 2.5L DFI > 0T997974 - 1E000796 > Air Handler Components / Flywheel Cover

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Air Handler Components / Flywheel Cover

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	843151A05	GASKET SET (1 required per assembly)
		27-843151A05 - Gasket Set [ More info ] Unavailable
#0	855633T31	AIR HANDLER (1 required per assembly) — Replaces: 855633T24
		855633T31 - AIR HANDLER [ More info ] Unavailable
#1	858708T02	PLENUM KIT AIR (1 required per assembly)
		858708T02 - Air Plenum Kit [ More info ] $103.99 $88.07 5 In Stock.
#2	840484	GASKET (1 required per assembly)
		27-840484 - Adaptor Plate Gasket [ More info ] $48.49 Available to Order: Shipping delay up to 10 days.
#3	840485	GASKET (1 required per assembly)
		27-840485 - Adaptor Plate Gasket [ More info ] $36.49 Available to Order: Shipping delay up to 10 days.
#4	843228A01	ADAPTER PLATE KIT (1 required per assembly)
		843228A01 - Plate Kit - Adaptor [ More info ] Unavailable
#5	840805T03	REED BLOCK ASSEMBLY (6 required per assembly)
		840805T03 - Reed Block Assembly [ More info ] $230.72 Available to Order: Shipping delay up to 10 days.
#6	843223A01	REED PETAL KIT (1 required per assembly)
		34-843223A01 - Reed Petal Kit [ More info ] Unavailable
#7	8M0101629	PUMP ASSEMBLY OIL (1 required per assembly) — Replaces: 857149T2, 857149T05
		8M0101629 - Oil Pump Assembly [ More info ] Unavailable
		8M0128080 - Oil Pump [ More info ] Unavailable
		8M0185614 - OIL PUMP [ More info ] $642.99 $627.79 Available to Order: Shipping delay up to 10 days.
#8	855364	BUSHING (3 required per assembly)
		23-855364 - Bushing [ More info ] $5.99 10+ In Stock.
#9	855362001	GROMMET (3 required per assembly)
		25-855362001 - Grommet, Coolant Reservoir [ More info ] $3.19 Available to Order: Shipping delay up to 10 days.
#10	817274	WASHER (.344 X 1.00 X .063) STAINLESS STEEL (3 required per assembly)
		12-817274 - Washer, (.344 X 1.00 X .063) Stainless Steel [ More info ] $1.40 2 In Stock.
#11	891529	BRACKET (1 required per assembly)
		891529 - Bracket [ More info ] Unavailable
#12	81893430	SCREW (M8 X 30) (3 required per assembly)
		10-818934 30 - Screw - Priced Individually [ More info ] $9.40 1 In Stock.
#13	55715	SCREW (.250-20 X .880) (12 required per assembly)
		10-55715 - Screw - Priced Individually [ More info ] $2.79 $2.24 10+ In Stock.
#14	891527	CLIP (1 required per assembly)
		54-891527 - Clip [ More info ] Unavailable
#15	883942	SCREW (M4 X 16) (2 required per assembly)
		10-883942 - Screw [ More info ] $3.59 1 In Stock.
#16	883312T01	THROTTLE BODY KIT (1 required per assembly)
		883312T01 - Throttle Body Kit [ More info ] $119.99 $101.62 4 In Stock.
#17	855423	O-RING (1 required per assembly)
		25-855423 - O-Ring [ More info ] $25.99 Available to Order: Shipping delay up to 10 days.
#18	82130040	SCREW (M6 X 40) (4 required per assembly)
		10-821300 40 - Screw [ More info ] $7.89 $4.43 10+ In Stock.
#19	1993716	SCREW (M6 X 16) (1 required per assembly)
		10-19937 16 - Screw [ More info ] $2.99 Available to Order: Shipping delay up to 10 days.
#20	854445	SENSOR MAP (1 required per assembly)
		854445 - MAP Sensor Manifold Absolute Pressure [ More info ] $132.61 6 In Stock.
		8M0237529 - SENSOR MAP [ More info ] Unavailable
#21	884522	BRACKET MAP SENSOR (1 required per assembly)
		884522 - Bracket [ More info ] $13.59 Available to Order: Shipping delay up to 10 days.
#22	8M0148668	SENSOR ASSEMBLY (1 required per assembly) — Replaces: 885342001, 885342002
		8M0148668 - Temperature Sensor [ More info ] $47.49 1 In Stock.
#23	896699	O-RING (1.78 MM X .08 MM) (1 required per assembly) — Replaces: 888814
		25-896699 - O-ring, (1.78 Mm X .08 Mm) [ More info ] $12.49 Available to Order: Shipping delay up to 10 days.
#24	879962	CLIP (3 required per assembly)
		54-879962 - Clip [ More info ] $1.99 4 In Stock.
#25	883080	J CLIP (2 required per assembly)
		54-883080 - J Clip [ More info ] $3.09 Available to Order: Shipping delay up to 10 days.
#26	817504	SCREW (12 required per assembly)
		10-817504 - Screw [ More info ] $4.79 2 In Stock.
#27	843182T01	COVER-FLYWHEEL (1 required per assembly)
		843182T01 - Flywheel Cover [ More info ] Unavailable
#28	840525	GROMMET (2 required per assembly)
		25-840525 - Grommet [ More info ] Unavailable
#29	20116	GROMMET (1 required per assembly)
		25-20116 - Grommet - Priced Individually [ More info ] $4.79 10+ In Stock.
#30	842775	GROMMET (1 required per assembly)
		25-842775 - Grommet [ More info ] Unavailable
#31	855613	GROMMET (1 required per assembly)
		25-855613 - Grommet, Throttle Body [ More info ] $23.79 Available to Order: Shipping delay up to 10 days.
